Generac Power Systems 005210-0 Owner's Manual page 41

1 0A4531 REF ENGINE-1.5L
2 022473 2 WASHER FLAT 1/4 ZINC
3 * 055934C 1 CLAMP VINYL .5 X .406 Z
4 0A45310258 REF. GASKET-EXHAUST MANIFOLD
5 0A4355 1 MANIFOLD-EXHAUST
6 0E2632 1 HEAT SHIELD EXH 1.5L
7 022097 4 WASHER LOCK M6-1/4
8 022507 2 SCREW HHC 1/4-20 X 1/2 G5
9 052212 4 SCREW HHC M10-1.25 X 25 G8.8
10 046526 4 WASHER-LOCK-M10
11 022131 20 WASHER FLAT 3/8 ZINC
12 0C2499 2 STAMPING ENG FOOT
13 055993 1 SPACER .41 X .75 X .12 STL/ZNC
14 045772 1 NUT HEX M10-1.5 G8 YEL CHR
15 023586 2 SCREW SHC 5/16-18 X 2 G8.8 NZ
16 020692 1 STARTER-12V
17 0A7005 2 SPACER .56 X 1 X .37 ST/ZNC
18 052243 1 SCREW HHC M10-1.5 X 60 G8.8
19 0A4772 1 ENGINE PLATE
20 070901 2 SLEEVE DOWEL BLHSG
21 051735 3 SCREW HHC M10-1.5 X 70 G8.8
22 056768 3 SCREW HHC M10-1.5 X 90 G8.8
23 022145 12 WASHER FLAT 5/16 ZINC
24 022129 19 WASHER LOCK M8-5/16
25 022259 2 NUT HEX 5/16-18 STEEL
26 052213 11 SCREW HHC M10-1.25 X 20 G8.8
27 047411 2 SCREW HHC M6-1.0 X 16 G8.8
28 052830 1 SCREW HHC M10-1.25 X 45 G8.8
30 045771 12 NUT HEX M8-1.25 G8 YEL CHR
31 058306 5 SCREW SHC M8-1.25 X 25 G12.9
32 030795 2 SCREW HHC 5/16-18 X 1 G5
33 0A2711A 1 ADAPTER-THERMOSTAT
34 048665 1 GASKET THERMOSTAT
35 075885 1 THERMOSTAT 195 DEG
36 0A45310257 REF. GASKET INLET MANIFOLD
37 0E1100 1 MANIFOLD INTAKE MACHINED
38 0E0561 1 ASSY WATER LEVEL SENSOR C/E PL
39 0A6751 1 SW-TMP 245 DEG 3/8 NPT
41 026925 2 PLUG STD PIPE 3/8 STEEL SQ HD
42 061012 1 PLUG STD PIPE 1/8 SCKT HD
43 039253 5 SCREW HHC M8-1.25 X 20 G8.8
44 0A5110 1 PIPE WATER-INLET
45 0A7006 1 O-RING 1-1/16 X 1-5/16 X 1/8
46 025507 2 WASHER SHAKEPROOF EXT 7/16 STL
47 022500B 2 SPACER .41 X .75 X .25 ST/ZNC
48 0A8584 1 SWITCH OIL PRESSURE
49 036277 1 ELBOW 90D STREET 1/8
50 042574 1 ADAPTOR 1/8 NPTF TO 1/8-28
51 026073A 1 PLUG STD PIPE 1/4 STEEL SQ HD
52 0A6701 1 SCREW HHC M10-1.5 X 110 G8.8
53 039414 1 SCREW HHC M8-1.25 X 35 G8.8
55 051769 1 WASHER LOCK M12
56 0A4800A 1 PULLEY-CRANKSHAFT (3600 RPM)
57 0A5839 1 BRACKET - ALT SUPPRT
58 0A1354B 1 DC ALTERNATOR-12V
59 0A4839 1 ARM ADJUST ALTERNATOR
60 069860C 1 HOSE ASM.-OIL DRAIN
61 0F3856 1 GUARD CRANKSHAFT 1.5L
62 058443 2 SCREW CRIMPTITE 1/4-20 X 5/8
63 0A2628 1 PULLEY - FAN 95 DIA
64 0A5586 1 V-BELT 3/8 X 28.9D
65 0A4814 1 SPACER PULLEY
66 0A45310244 REF. FILTER OIL
67 0C1852 1 ADAPTER DRAIN OIL
68 0912970066 1 GROUND WIRE (STARTER)
69 070928 1 CLAMP HOSE - OIL DRAIN
70 069860C 1 HOSE OIL DRAIN ASSY 21"
71 035473 1 CLAMP HOSE #12 .50-1.25
72 077996 1 CAP ANTIFREEZE RUBBER
73 069811 1 CAP HEX 1/4 NPT BRASS
74 ** 0A1354A 1 REGULATOR - DC ALT
75 ** 042568 2 SCREW HHC M6-1.0 X 20 G8.8
76 ** 022473 2 WASHER FLAT 1/4-M6 ZINC
77 ** 022097 2 WASHER LOCK M6-1/4
78 ** 049813 2 NUT HEX M6 X 1.0 G8 YEL CHR
79 0D2244M 1 ASSY MAGPICKUP (3/8-24 MALE)
* CLAMP FOR WIRING HARNESS (NOT SHOWN)
** NOT SHOWN
