Generac Power Systems 005210-0 Owner's Manual page 31

1 0F1823A 1
2 0F3078 1
3 0F2606 1
4 036261 6
5 043181 4
6 052777 7
7 0F4245F 1
8 0F1262 4
9 0F1263 1
10 0F1264 1
11 0F1725C 1
12 067680 1
13 0E6875A 2
14 055911 1
16 0F5459 1
17 0F5462 1
18 0A5062J 4
19 029673 1
20 049350 1
21 0F1958 1
22 082573 1
23 0E4494 1
24 0F3215 1
25 0F5886 3
26 051713 14
27 049226 14
28 0F5752B 1
29 0F5884 2
30 0F5896 2
31 0C2265 4
32 0C3990 2
33 091526 8
34 051716 7
36 043182 7
37 051714 7
38 0F3192 1
39 0E7403C 1
40 0F4416 1
41 0F6305 2
42 0F6305A 1
43 0F2627 1
COMPONENTS INSTALLED PER OF7380D
A 056739 1
B 022287 2
C 022473 4
D 022097 2
E 022127 2
F 0F6145 A/R
ENCL HSB CONTROL PANEL
COVER CONTROL PANEL
HINGE CONTINUOUS H-PNL
RIVET POP .125 X .275 SS
SCREW PHM M3-0.5 X 10MM
WASHER FLAT M3
ASSY PCB CPL CTRLR 3600 RPM
HOLDER FUSE WICKMANN 178.6150
ADPTR RH SIDE WICKMAN 178.6191
ADPTR LH SIDE WICKMAN 178.6192
ASSY PCB 2AMP 12V UL BATT CHGR
ASSY VOLTAGE REGULATOR 60HZ
RELAY 12VDC C FORM W/DIODE
BLOCK TERM 20A 12 X 6 X 1100V
DECAL CPL CONTROL PANEL FUSES
DECAL CPL 3.9L TB1
SPACER 9.5H 3.2 ID
DIO BRIDGE 25A 600V
CB 4 X 1 ETA 46-500-P
PLATE HARNESS CLAMP
SWITCH RKR DPST 125V SPD
SWITCH RKR DPDT ON-OFF-ON
DECAL CONTROL HSB
SCREW HHPM M5-0.8 X 12
WASHER FLAT M5
WASHER LOCK M5
RES WW 25R 5% 25W QK CONN
SCREW PHTT M3.5-0.6 X 10
SCREW PHTT M3.5-0.6 X 16
SCREW PHTT M4-0.7 X 12 ZYC
SCREW PHTT M4-0.7 X 10 ZYC
SCREW PPHM M5-0.8 X 12 ZNC
NUT HEX M5-0.8 G8 CLEAR ZINC
WASHER LOCK M3
NUT HEX M3-0.5 G8 YEL CHR
SUPPORT ANGLE PCB
FUSE ATO TYPE 15 AMP (BLUE)
HARN 1800RPM R-100 CONTROL PNL (NOT SHOWN)
SEAL COVER 3.18 X 12.7 X 382
SEAL COVER 3.18 X 12.7 X 283
PLATE COVER H PANEL
RELAY SOLENOID 12VDC PNL MNT
SCREW HHC 1/4-20 X 3/4 G5
WASHER FLAT 1/4-M6 ZINC
WASHER LOCK M6-1/4
NUT HEX 1/4-20 STEEL
SEAL WEATHER .45" DIA
