Generac Power Systems QT 5.4L Owner's Manual page 55

1 033212 4
2 065908 1
3 0F6261H 1
0F6261J 1
0F6261K 1
0F6261L 1
0F6261M 1
4 052617 2
5 022304 2
6 022129 4
7 045773 2
8 064346 1
9 0A8064 2
10 030131 1
11 031015 1
088963 1
12 026915 2
13 057823 4
14 059057 2
15 0D2698 1
16 0D1509 1
17 050280 1
18 0D2696B 1
0F2756A 1
19 0E4390 1
20 0E4392 1
21 0F0960 1
22 0F3885 1
23 0F3694 2
24 0F3691B 1
0F3691D 1
0F3691E 1
0F3691F 1
0F3691J 1
25 022195 2
26 0F6279 1
27 081017 1
28 046580 4
29 039294 2
30 022097 4
31 047290 1
32 040173 2
33 039130 1
SCREW HHC 5/16-18 X 1-1/4 G5
SUPPORT NAT GAS SOLENOID
REGULATOR ASSM 5.4L 80KW LPV (5.4L 80KW)
REGULATOR ASSM 5.4L 100KW LPV (5.4L 100KW)
REGULATOR ASSM 6.8L 100KW LPG (6.8L 100KW)
REGULATOR ASSM 6.8L 130KW LPV (6.8L 130KW)
REGULATOR ASSM 6.8L 150KW LPV (6.8L 150KW)
SCREW HHC M12-1.75 X 20 G8.8
WASHER FLAT 1/2 ZINC
WASHER LOCK M8-5/16
NUT HEX M12-1.75 G8 YEL CHR
PIPE TEE 1-1/4 NPT
BSHG RDCR HEX 1-1/4-3/4
ELBOW 90D 1-1/4 NPT
NIPPLE PIPE 1-1/4 NPT X 3
NIPPLE PIPE 1.25 NPT X 5.5 BL IRN (6.8L 150KW ONLY)
NIPPLE CLOSE 3/4 X 1.375
CLAMP HOSE #10 .56-1.06
HOSE 3/4 ID SAE-30R2 (45" LG)
GASKET ADAPTER THROT BODY
DECAL INLET PRESSURE
DECAL FUEL INLET LPG (LP VAPOR APPLICATION)
ADAPTOR THROTTLE BODY (BOSCH) (6.8L)
MACHINING INTAKE ADAPTOR 60MM (5.4L)
GASKET GOVERNOR ACTUATOR
ACTUATOR BOSCH 60 GOVERNOR
REDUCER 3.0" TO 2.75" TURBO
MIXER 40/60MM ACTUATOR ASSY
O-RING 2-7/8 X 3-1/16 X 3/32
VENTURI THROTTLE 36MM (5.4L 80KW)
VENTURI THROTTLE 40MM (5.4L 100KW)
VENTURI THROTTLE 42MM (6.8L 100KW)
VENTURI THROTTLE 44MM (6.8L 130KW)
VENTURI THROTTLE 50MM (6.8L 150KW)
WASHER LOCK 1/2
HARNESS FUEL JUMPER DUAL REG
BARBED STR 1/4 NPT X 1/2
SCREW SHC M6-1.0 X 45 G12.9
CLAMP HOSE #44 2.31-3.25
WASHER LOCK M6-1/4
HOSE 3/8 ID SINGLE BRAID (42" LG)
CLAMP HOSE #5.5 .62-.62
NIPPLE CLOSE 1.25 NPT X 1.625
