Standby Power Rating
25 kW 60 Hz
STANDARD EQUIPMENT
• All input connections in one single area
• High coolant temperature shutdown
• Low oil pressure shutdown
• Low coolant level automatic shutdown
• Overspeed automatic shutdown
• Crank timer
• Exercise timer
• Oil drain extension
• Cool flow radiator
• Closed coolant recovery system
FEATURES
• Innovative design and fully prototype tested
• UL 2200 Listed
• Solid state frequency compensated
voltage regulator
• Dynamic and static battery charger
• Sound attenuated acoustically designed enclosure
• Whisper-Test™ for low noise level exercise
• Acoustically designed engine cooling system
• High flow low noise factory engineered exhaust system
Transfer Switch is sold separately
• Watertight state of the art electrical connectors
• Mainline circuit breaker
• Radiator drain extension
• Battery charge alternator
• 2 Amp static battery charger
• Battery rack and battery cables
• Fan and belt guards
• Isochronous governor
• UV/Ozone resistant hoses
• Flex fuel line pigtail
• State of the art control system with R-Series digital control panel
• Watertight electrical connectors
• Rodent proof construction
• High efficiency, low distortion Generac designed alternator
• Vibration isolated from mounting base
• Matching Generac transfer switches engineered and tested to work
as a system
• All components easily accessible for maintenance
• Electrostatically applied powder paint
COMMERCIAL SERIES
Liquid Cooled
Gas Engine
Generator Sets
WHISPER-TEST™
Low Speed Exercise
62 dB(A) at 23 feet
GENERAC 1.6L ENGINE
Naturally Aspirated
Gaseous Fueled
UL 2200 Listed
Advertisement
Related Manuals for Generac Power Systems Guardian Elite QT02516
Summary of Contents for Generac Power Systems Guardian Elite QT02516
- Page 1 Standby Power Rating 25 kW 60 Hz STANDARD EQUIPMENT • All input connections in one single area • High coolant temperature shutdown • Low oil pressure shutdown • Low coolant level automatic shutdown • Overspeed automatic shutdown • Crank timer •...
-
Page 2: Engine Specifications
APPLICATION & ENGINEERING DATA GENERATOR SPECIFICATIONS TYPE ...Synchronous ROTOR INSULATION ...Class F STATOR INSULATION ...Class F TOTAL HARMONIC DISTORTION ...<5% TELEPHONE INTERFERENCE FACTOR (TIF) ... <50 ALTERNATOR OUTPUT LEADS 3 PHASE ...4 wire BEARINGS...Sealed Ball COUPLING ... Flexible Disc LOAD CAPACITY (STANDBY RATING) ... 25 kW EXCITATION SYSTEM ... - Page 3 COMMERCIAL 25 kW OPERATING DATA KW RATING ENGINE SIZE GENERATOR OUTPUT VOLTAGE/KW - 60Hz 120/208V, 3-phase, 0.8 pf 120/240V, 3-phase, 0.8 pf GENERATOR LOCKED ROTOR KVA AVAILABLE @ VOLTAGE DIP OF 35% 208 or 240V 3-phase ENGINE FUEL CONSUMPTION (Natural Gas) (Propane) Exercise cycle 25% of rated load 50% of rated load...
-
Page 4: Installation Layout
RIGHT SIDE VIEW CONCRETE BASE FUEL LINE CONNECTION 3/4" NPT FEMALE COUPLING © 2007 Generac Power Systems, Inc. All rights reserved. All specifications are subject to change without notice. COMMERCIAL 25 kW CIRCUIT BREAKER SIZE VOLTS / AMPS LUG SIZE 208 3ø...
