Page 2: Table Of Contents
Guide to use the Instruction Book The symbols you will see on some paragraphs of this booklet have the following meaning: The warning triangle and/or the key words (Warning!, Caution!) emphasize information that is particularly important for your safety or correct functioning of the appliance. The information marked with this symbol provides additional instructions and practical tips on the use of the appliance. -
Page 3: Warnings
Dear customer, Transport damages Please read these operating instructions carefully When unpacking the appliance, check that it is not and pay particular attention to the safety notes damaged. If in doubt, do not use it and contact the indicated below. We recommend that you keep this Service Centre. -
Page 4: Disposal
Disposal Packaging materials Machine The materials marked with the symbol Use authorised disposal sites for your old appliance. recyclable. Help to keep your country tidy! >PE<=polyethylene >PS<=polystyrene >PP<=polypropylene This means that they can be recycled by disposing of them properly in appropriate collection containers. Tips for environmental protection To save water, energy and to help protect the •... -
Page 5: Installation
Installation Unpacking 5. Set the machine upright and remove the remaining rear screw. Slide out the relevant pin. 6. Plug all the holes with the plugs which you will All transit bolts and packing must be removed find in the envelope containing the instruction before using the appliance. -
Page 6: Water Drainage
The inlet hose must not be lengthened. If it is too Electrical connection short and you do not wish to move the tap, you will This machine is designed to operate on a 220-230 V, have to purchase a new, longer hose specially single-phase, 50 Hz supply. -
Page 7: Your New Washer-Dryer
Your new washer-dryer This new machine, which is fitted with the Direct Spray system, patented Electrolux, meets all modern needs for effective treatment of laundry with low water, energy and detergent consumption. Further savings are achieved by washing small loads of laundry, since water and electricity consumption is proportional to the quantity and type of laundry being washed. -
Page 8: Use
Control panel 1 Programme chart Position E corresponds to the ENERGY SAVING programme, position to “cold wash” and position A programme chart in Finnish is in the interior part of to “drying” . the detergent dispenser drawer. The programme At the end of the programme the selector dial chart in Russian is supplied with the instruction must be turned to position O. - Page 9 8 Extra rinse button Spin speed Can be used with all programmes except the wool The following speeds are available for the different programme. The machine performs 4 rinses instead fabrics. of 3. • Cotton, linen: This option is recommended for people who are 700/900/1200 max 1600 r.p.m.
- Page 10 When the programme has finished a flashing zero Altering the delayed start is displayed. If you have selected the Anti-crease option , the • Depress START/PAUSE button zero will not flash. • Depress DELAY START button until the required time is displayed. Drying time If you wish to cancel the delay, depress the button The selected drying time is displayed in minutes or...
-
Page 11: Functions
Alarm codes Draining of water In the event of operating problems, some alarm By depressing the Start/Pause button codes can be displayed, for example E20 (see • The water of programme “A” (Soak) is emptied out paragraph “Something not working”). •... -
Page 12: Programme Information
Cancelling a programme Turn first the programme selector dial to O, then select the programme and depress the Turn the selector dial to O to cancel a programme START/PAUSE button. which is running: three flashing dashes appear on the display. Now you can select a new programme. B = Rinses Opening the door after the programme With this programme it is possible to rinse and spin... -
Page 13: Washing Hints
Delicate fabrics and woollens: drum no more than Washing hints one third full. Washing a maximum load makes the most efficient Sorting the laundry use of water and energy. For heavily soiled laundry, reduce the load size. Follow the wash code symbols on each garment label and the manufacturer’s washing instructions. -
Page 14: Detergents And Additives
Ball point pen and glue: moisten with acetone (*), Any fabric softener or starching additives must be lay the garment on a soft cloth and dab the stain. poured into the compartment marked before starting the wash programme. Lipstick: moisten with acetone as above, then treat stains with methylated spirits. -
Page 15: Drying Hints
Drying symbols on garment labels Drying hints Always look at the garment label to check whether As a dryer, the machine works on the condensation garments can be machine dried. principle. The following symbols refer to drying: Therefore, the water tap must be open and the Machine drying is usually possible drain hose must drain water into a sink or into the drain pipe, even during the drying cycle. -
Page 16: Operating Sequence
4. Switch the machine on Operating sequence To switch the machine on, press the ON/OFF button : the mains-on light comes on. Washing only Before washing your first load of laundry, we recommend that you run a cotton cycle at 60°C, with the machine empty, in order to remove any manufacturing residue from the drum and tub. - Page 17 7. Select the required options 9. Start the programme The light corresponding to the depressed button To start the selected programme, press the illuminates. START/PAUSE button; the corresponding light stops flashing. Only the pilot light corresponding to the wash phase which is running stays on.
-
Page 18: Drying Only
Drying only Automatic washing and drying (NON-STOP programme) Warning! Do not exceed the maximum laundry loads: Warning! For NON-STOP programmes, it is also - 2.75 kg for linen and cottons essential not to exceed the maximum load sizes of 2.75 kg for cotton and 2 kg for synthetics. kg for synthetics. -
Page 19: Washing Programmes
Programme chart Washing programmes Consumption* Type of Programme Additional Section Temp. Load fabric description functions Energy Water Time min. light blue 95° White Wash at 95°C 5.5 kg cotton 3 rinses Normal spin light blue White cotton Wash at 60°C 5.5 kg 60°... -
Page 20: Special Programmes
Programme chart Special programmes Consumption* Selector Programme Additional Section dial Programme Load description functions Energy Water Time position min. blue Soak Soak at 30°C 5.5 kg stop with water in tub. To drain, depress START/PAUSE button The machine automatically empties itself after 18 hours. -
Page 21: Timed Dryings
Programme table Timed drying Degree of Drying time Type of fabric Max. load Spin speed drying mins 2.75 kg 1600 Extra dry Cotton and linen Ideal for (bathrobes, bath towelling towels, etc.) 1.5 kg 1600 materials 2.75 kg 1600 Cotton and linen (towels, T-shirts, bathrobes) Store dry (*) -
Page 22: International Wash Code Symbols
International wash code symbols These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry. Energetic wash Max. wash Max. wash Max. wash Max. wash temperature temperature temperature temperature 95°C 60°C 40°C 30°C Hand wash Do not... -
Page 23: Maintenance
Maintenance Bodywork Drain pump Clean the outside of the machine with warm water The pump should be inspected regularly and and a detergent used to handwash dishes. Rinse particularly if with clean water and dry with a soft cloth. • the machine does not empty and/or spin Important: do not use methylated spirits, solvents or •... -
Page 24: Water Inlet Filter
• Put the cap back on the emergency emptying hose Emergency emptying out and place the latter back in its seat. If the water is not discharged, proceed as follows to empty out the machine: • pull out the plug from the power socket; •... -
Page 25: Something Not Working
Something not working? Problems which you can resolve yourself. During machine operation it is possible that one of the following alarm codes appears on the display: - E10 : problem with the water supply - E20 : problem with water draining - E40 : door open Once the problem has been eliminated, press the START/PAUSE button to restart the programme. - Page 26 Problem Possible cause • The door will not open: • The water level is above the bottom edge of the door. • The machine is heating the water or drying clothes. • The drum is turning. The door can only be opened when the door locked light is off.
