- Page 1 ..................... EWW 167443 W EN WASHER DRYER USER MANUAL...
-
Page 2: Table Of Contents
2 electrolux Electrolux. Thinking of you. Share more of our thinking at www.electrolux.com CONTENTS Safety information Washing programmes Product description Drying Programmes Control panel Care and cleaning First use What to do if… Personalisation Technical data Daily use Consumption values... - Page 3 3 may cause injury or serious malfunction- wired bras must NOT be machine wash- ing. Contact your local Service Centre. Always insist on genuine spare parts. • Garments which have been in contact with volatile petroleum products should INSTALLATION not be machine washed.
-
Page 4: Product Description
4 electrolux • Keep all detergents in a safe place out of children’s reach. • Make sure that children or pets do not climb into the drum. To prevent children and pets becoming trapped inside the drum the machine incorporates a special feature. -
Page 5: Control Panel
5 DETERGENT DISPENSER DRAWER Compartment for detergent used for prewash and soak phase or for stain re- mover used during the stain action phase (if available). The prewash and soak detergent is added at the beginning of the wash pro- gramme. - Page 6 6 electrolux PROGRAMME SELECTOR DIAL time you want appears on the display ac- cording to the fabrics (cottons, synthetics It allows you to switch the appliance on/off or wool) you have to dry. and/or to select a programme. For Cottons you can select a drying time TEMPERATURE from 10 minutes to 250 minutes.
- Page 7 7 DISPLAY The display shows the following informa- of the display for a few seconds and the tion: integrated red light of button 8 start flash- 7.1: ing. • Duration of the selected programme • End of programme After selecting a programme, the duration...
-
Page 8: First Use
8 electrolux of soiling automatically proposed by the 7.4: Child safety lock (see «Child Safe- machine. ty Lock» paragraph). TABLE OF SYMBOLS Programmes Selector dial = Time manager programmes = Rinse = Drain = Spin Buttons and lights = Cold... -
Page 9: Daily Use
9 DAILY USE Load the laundry Open the door by carefully pulling the door handle outwards. Place the laundry in the drum, one item at a time, shaking them out as much as possible. Close the door. Make sure that no laundry stays between the seal and the door. - Page 10 10 electrolux SELECT THE TEMPERATURE BY The selected delay time value (up to 20 PRESSING BUTTON 2 hours) will appear on the display a few sec- onds, then the duration of the programme By selecting a programme, the appliance will appear again.
- Page 11 11 SELECT THE TIME MANAGER OPTION INTERRUPTING A PROGRAMME BY PRESSING BUTTONS 10 Press the button 8 to interrupt a pro- By pressing these buttons repeatedly, the gramme which is running, the correspond- duration of the washing cycle can be in- ing green pilot light starts blinking.
-
Page 12: Use - Drying
12 electrolux 3. Reduce the spin speed if needed, by Remove the laundry from the drum and pressing the relevant button. carefully check that the drum is empty. If 4. Press button 8. you do not intend to carry out another At the end of the programme, the door is wash, close the water tap. -
Page 13: Use - Washing & Drying
13 If you set only 10 minutes of drying phase with the drying time button (5), the appli- ance performs only a cooling phase. USE - WASHING & DRYING NON-STOP PROGRAMME - WASHING Caution! Do not use a dosing... -
Page 14: Helpful Hints And Tips
14 electrolux FLUFF IN THE GARMENTS (new sponge, wool, sweatshirt especially) and vice versa. During the WASHING AND/OR DRYING • To air-dry this type of fabrics when they PHASE, certain types of fabric, as sponge- are washed the first time. - Page 15 15 Blood: treat fresh stains with cold water. etc.), the colour, washing temperature and For dried stains, soak overnight in water degree of soiling. with a special detergent then rub in the All commonly available washing machine soap and water.
-
Page 16: Drying Hints
16 electrolux DRYING HINTS PREPARING THE DRYING CYCLE If using liquid detergents, a programme without prewash must be selected. As a dryer, the appliance works on the con- Your appliance incorporates a re-circulation densation principle. system which allows an optimal use of the Therefore, the water tap must be open concentrated detergent. -
Page 17: Washing Programmes
17 WASHING PROGRAMMES Programme - Maximum and Minimum Tempera- Detergent Com- ture - Cycle Description - Maximum Spin Speed - Options partment Maximum Fabrics Load - Type of Laundry Katoen SPIN REDUCTION 90° - Cold RINSE HOLD Main wash - Rinses... - Page 18 18 electrolux Programme - Maximum and Minimum Tempera- Detergent Com- ture - Cycle Description - Maximum Spin Speed - Options partment Maximum Fabrics Load - Type of Laundry Rinse SPIN REDUCTION Rinse - Long spin RINSE HOLD Spin at the maximum speed EXTRA RINSE Max.
-
Page 19: Drying Programmes
19 Programme - Maximum and Minimum Tempera- Detergent Com- ture - Cycle Description - Maximum Spin Speed - Options partment Maximum Fabrics Load - Type of Laundry O = Off For cancelling the programme which is running or to switch the machine off . -
Page 20: Care And Cleaning
20 electrolux CARE AND CLEANING Warning! You must disconnect the appliance from the electricity supply, before you can carry out any cleaning or maintenance work. DESCALING The water we use normally contains lime. It is a good idea to periodically use a water softening powder in the machine. - Page 21 21 2. Run a washing cycle without any wash- 1. Open the pump door. ing to clean off any cleaning agent resi- dues. Programme: Short Cotton Programme at maximum temperature and add ap- prox. 1/4 measuring cup of detergent.
- Page 22 22 electrolux 7. Remove fluff and objects from the curely re-tightened so as to stop leaks and pump. young children being able to remove it. CLEANING THE WATER INLET FILTERS If you notice that the machine is taking lon- ger to fill, check that the filter in the water inlet hose is not blocked.
-
Page 23: What To Do If
23 6. press the two levers and pull forward move the remaining water from the inlet the drainage duct to let the water flow hose and the drain pump. out; 1. disconnect the mains plug from the 7. when the container is full of water, put mains socket. - Page 24 24 electrolux Problem Possible cause/Solution The water tap is closed. • Open the water tap. The inlet hose is squashed or kinked. • Check the inlet hose connection. The filter in the inlet hose or in the inlet valve filter are blocked.
- Page 25 25 Problem Possible cause/Solution The electronic unbalance detection device has cut in because the laundry is not evenly distributed in the drum. The laundry is redis- tributed by reverse rotation of the drum. This may happen several times before the unbalance disappears and normal spinning can resume.
-
Page 26: Technical Data
26 electrolux TECHNICAL DATA Dimensions Width 60 cm Height 85 cm Depth 63 cm Electrical connection Information on the electrical connection is given on the rating Voltage - Overall power - Fuse plate, on the inner edge of the appliance door. - Page 27 27 2. Remove the power supply cable and 6. Fill the smaller upper hole and the two the draining and inlet hose from the large ones with the corresponding plas- hose holders on the rear of the appli- tic plug caps supplied in the bag con- ance.
- Page 28 28 electrolux The rubber feet are particularly recommen- 4. Connect the hose to a tap with a 3/4” ded on floating, slippery and wooden floors. thread. Always use the hose supplied Mount the rubber feet to prevent vibration, with the appliance.
-
Page 29: Electrical Connection
29 chine is emptying. This could be done by • In a sink drain pipe branch. This tying it to the tap with a piece of string or branch must be above the trap so that attaching it to the wall. - Page 30 30 electrolux PACKAGING MATERIALS • Normally soiled laundry may be washed without prewashing in order to save de- The materials marked with the symbol tergent, water and time (the environment are recyclable. is protected too!). >PE<=polyethylene • The machine works more economically if >PS<=polystyrene...
- Page 31 31...
- Page 32 132930370-B-472011...
