- Page 1 PLL1900W LED LCD Monitor USER'S GUIDE www.planar.com...
-
Page 2: Table Of Contents
Front View of the Product.............................4 Rear View of the Product...............................5 Quick Installation ................................6 Basic Operation.................................7 Advanced Operation—OSD Menu..........................9 Supporting Timing Modes ............................12 Technical Information ..............................13 Wall-mount instruction............................... 14 Care and Maintenance..............................15 Troubleshooting................................15 Planar Support ................................15... -
Page 3: Operation Instructions
Operation Instructions Thank you for purchasing this edge-lit LED LCD monitor, a high-resolution multi-scan color LED LCD monitor.Please read this guide thoroughly before installation. FCC RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: (FOR FCC CERTIFIED MODELS) This LED LCD monitor has been tested and found compliant with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 4: Safety Precautions
Safety Precautions This LED LCD monitor is manufactured and tested on a ground principle that a user’s safety comes first. However, improper use or installation may result danger to the LED LCD monitor as well as to the user. Carefully go over the following WARNINGS before installation and keep this guide handy. -
Page 5: First Setup
First Setup Congratulations on your purchase of this high performance edge lit LED LCD monitor. This LED LCD monitor comes with the following accessories : LED LCD monitor Power Cable User’s Guide VGA Cable Installing the Stand Base 1. -
Page 6: Front View Of The Product
Front View of the Product OSD Menu On/Off Contrast/Brightness /Scroll Down/Adjust Decrease Preset Mode/Scroll Up/ Adjust Increase Confirm Select/ Auto adjust Power ON/OFF LED Indicator... -
Page 7: Rear View Of The Product
Rear View of the Product Power input (AC input) VGA input (D-Sub 15 pin) -
Page 8: Quick Installation
Quick Installation 1. Connect the VGA video cable from the monitor to the computer. Make sure both monitor and computer are powered OFF. 2. Connect the power cord to a properly grounded AC outlet, then to the monitor. 3. Power-ON computer and then POWER-ON the monitor. Set the timing mode on your computer. -
Page 9: Basic Operation
Basic Operation Before using the LED LCD monitor: Connect external equipments properly. Insert the power plug, and the power LED indicator will light orange. Power On/Off To turn the LED LCD monitor on/off: Press POWER button on the front of LED LCD monitor. The power LED indicator lights green when the LED LCD monitor is on. - Page 10 Option 2: OSD & Power button lock – all 5 buttons including the “POWER” button are locked. Press and hold the 1 button and the ▼ button for 3 seconds to lock all 5 buttons. The LED LCD monitor will show an “Lock Out” message for 5~10 seconds and the message will disappear automatically.
-
Page 11: Advanced Operation-Osd Menu
Advanced Operation—OSD Menu You can use the OSD menu to adjust various settings for your LED LCD monitor . Press the 1 button to display the OSD Menu, and use ▲▼ to select the desired OSD menu. Short Cuts Function from the button(s) Auto Image Adjust: To auto adjust Horizontal Position, Vertical Position, Phase (Fine Tune) and Clock (H. - Page 12 5400K: Adds green to screen image for a darker color. User Color: Individual adjustments for red (R), green (G), blue (B). 1. Press button 2 to select the desired color. 2. Press ▼ or ▲ button to adjust selected color. Information: To display the information, regarding the current input signal coming from the graphic card in your computer.
- Page 13 H. Position: To horizontally adjust the OSD position. ▲: move OSD to the right, ▼: move OSD to the left. V. Position: To vertically adjust the OSD position. ▲: move OSD up, ▼: move OSD down. OSD Time Out: To automatically turn off On Screen Display (OSD) after a preset period of time.
-
Page 14: Supporting Timing Modes
Supporting Timing Modes STANDARD RESOLUTION 720 x 400 @ 70Hz 640 x 480 @ 60Hz 640 x 480 @ 67Hz VESA 640 x 480 @ 72Hz VESA 640 x 480 @ 75Hz VESA 800 x 600 @ 56Hz VESA 800 x 600 @ 60Hz VESA 800 x 600 @ 72Hz VESA... -
Page 15: Technical Information
Technical Information Technical Specification Panel 18.5” TFT (with LED backlight) Power Management On: 18 Watts (typical), 25 Watts (maximum) Standby Mode: < 0.5 Watt Off: < 0.5 Watt Displayable Resolution WXGA 1366 x 768 max. Vertical Frequency 60Hz max. Pixel Dimension 0.3 x 0.3 mm Display Color 16.7M... -
Page 16: Wall-Mount Instruction
Wall-mount instruction Preparing To Install The Optional Wall Mount Arm (not included) This LED LCD monitor can be attached to a wall mounting arm you can purchase separately. Turn the power OFF then disconnect the cables from the LED LCD monitor before performing the procedure below. -
Page 17: Care And Maintenance
If any colors (red, green, blue) are missing, check the video cable to make sure it is securely connected. Loose or broken pins in the cable connector could cause an improper connection. Connect the LED LCD monitor to another computer. Planar Support Planar Support Tel: 1-866-PLANAR1 (866-752-6271) or +1 503-748-5799 outside the US. - Page 18 2013 P/N:2001171356T...
