- Page 1 User Manual...
-
Page 2: Table Of Contents
3-CH Mode ........................................ 12 5. APPENDIX .................................... 13 ..............................13 ENERAL ROUBLESHOOTING ................................13 ENERAL AINTENANCE ................................14 ETURN ROCEDURE ....................................14 LAIMS TECHNICAL SPECIFICATIONS ............................. 15 CONTACT US ................................... 15 Page 2 of 15 SlimPAR™ 38 User Manual Rev. 3... -
Page 3: Before You Begin
In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Manual Conventions CHAUVET® manuals use the following conventions to differentiate certain types of information from the regular text. EANING... -
Page 4: Safety Instructions
Never disconnect the power cord by pulling or tugging on the cord. · Never carry the fixture directly from the cord. Always use the hanging/mounting bracket. · Avoid direct eye exposure to the light source while it is on. Page 4 of 15 SlimPAR™ 38 User Manual Rev. 3... -
Page 5: Introduction
· Power linking: max 43 units · Double-bracket yoke doubles as floor stand Product Overview Control Panel Microphone Sensitivity Adjustment Knob Microphone DMX In DMX Out Power In Power Out SlimPAR™ 38 User Manual Rev. 3 Page 5 of 15... -
Page 6: Setup
Fixture #2 Fixture #3 The power linking shown in this document is for the Chauvet® North American version ONLY! Therefore, it is the customer’s responsibility to check with the Dealer/Distributor regarding power linking on the local version of the product. Connections and availability may change, depending on the power requirements and/or regulations of each country/region. -
Page 7: Mounting
Mounting Orientation The SlimPAR™ 38 may be mounted in any safe position. Rigging Be sure that the structure can support the weight of the fixture. Please see the “Technical Specifications” section of this manual for a detailed weight listing. Mount the fixture securely. This may be done with a screw, nut and bolt, or a hanging clamp. -
Page 8: Signal Linking
In order to use this fixture in a DMX or master/slave operation, you must daisy chain, using DMX cables to link from one fixture to another. DMX controller (only in DMX operation) Fixture #1 Fixture #2 Fixture #3 Additional signal link out Page 8 of 15 SlimPAR™ 38 User Manual Rev. 3... -
Page 9: Operating Instructions
S001~S100 (the default range is S050) the 4 switching and fading built-in programs r--- Combine red, green, and g--- Green 000~100 blue to create a custom, static color B--- Blue SlimPAR™ 38 User Manual Rev. 3 Page 9 of 15... -
Page 10: Configuring The Starting Address
In addition, you should note the starting address selected for future reference. The SlimPAR™ 38 uses seven or three DMX channels. If this is your first time using DMX, we recommend reading the “DMX Primer” section in the “Appendix”. -
Page 11: Standalone Operation
This will move the selection to the following color; however, this is necessary to save the modification. The colors are represented by the following in the menu map: r--- = Red ( G--- = Green ( b--- = Blue ( SlimPAR™ 38 User Manual Rev. 3 Page 11 of 15... -
Page 12: Dmx Channel Values
Dimmer 000 ó 255 Intensity: 0%~100% (RGB/Macro modes) 3-CH Mode HANNEL ALUE UNCTION 000 ó 255 Dimmer: 0%~100% Green 000 ó 255 Dimmer: 0%~100% Blue 000 ó 255 Dimmer: 0%~100% Page 12 of 15 SlimPAR™ 38 User Manual Rev. 3... -
Page 13: Appendix
Keep DMX cables separated from power Interference from AC wires cables or black lights. If you still have a problem after trying the above solutions, please contact CHAUVET® Technical Support. General Maintenance To maintain optimum performance and minimize wear, fixtures should be cleaned frequently. Usage and environment are contributing factors in determining frequency. -
Page 14: Return Procedure
Package must be clearly labeled with a Return Merchandize Authorization Number (RMA #). Products returned without the RMA # will be refused. Call CHAUVET® and request an RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 15: Technical Specifications
Sunrise, FL 33351 voice: 954.577.4455 fax: 954.929.5560 toll free: 800.762.1084 Technical Support CHAUVET® 5200 NW 108 Sunrise, FL 33351 voice: 954.577.4455 (Press 4) fax: 954.929.5560 (Attention: Service) World Wide Web www.chauvetlighting.com SlimPAR™ 38 User Manual Rev. 3 Page 15 of 15...
