Coolant - Yamaha MAJESTY YP125E Owner's Manual

1
1. Final transmission oil filler cap
5. Install the final transmission oil
drain bolt, and then tighten it to
the specified torque.
1
1. Final transmission oil drain bolt
Tightening torque:
Final transmission oil drain bolt:
22 Nm (2.2 m•kgf, 15.9 ft•lbf)
PERIODIC MAINTENANCE AND ADJUSTMENT
6. Refill with the specified amount
of the recommended final trans-
mission oil, and then install and
tighten the oil filler cap. WAR-
NING! Make sure that no
foreign material enters the final
transmission case. Make sure
that no oil gets on the tire or
wheel.
[EWA11311]
Recommended final transmission
oil:
See page 8-1
Oil quantity:
0.15 L (0.16 US qt, 0.13 Imp.qt)
7. Check the final transmission case
for oil leakage. If oil is leaking,
check for the cause.
6-12

Coolant

The coolant level should be checked
before each ride. In addition, the coo-
lant must be changed at the intervals
specified in the periodic maintenance
and lubrication chart.
To check the coolant level
1. Place the vehicle on the centers-
tand.
TIP
●
The coolant level must be chec-
ked on a cold engine since the
level varies with engine tempera-
ture.
●
Make sure that the vehicle is
positioned straight up when
checking the coolant level. A
slight tilt to the side can result in
a false reading.
2. Check the coolant level in the
coolant reservoir.
TIP
The coolant should be between the
minimum and maximum level marks.
EAU20070
EAU20103
6
