- Page 1 PT3285PW Touch Screen Edge-lit LED LCD Monitor USER’S GUIDE www.planar.com...
- Page 2 The information contained in this document is subject to change without notice. This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be reproduced,translated to another language or stored in a retrieval system, or transmitted by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission.
-
Page 3: Table Of Contents
Table of Contents Usage Notice Precautions..........................1 Introduction About PT3285PW ........................2 Touch Screen for PT3285PW ....................2 Package Overview ...................... 3 Installation Product Overview ......................4 Front View ......................4 Bottom View ......................4 VESA Mount for Your Monitor ..................5 Start Your Installation .................... -
Page 4: Usage Notice
Usage Notice Warning - To prevent the risk of fi re or shock hazards, do not expose this product to rain or moisture. Warning - Please do not open or disassemble the product as this may cause electric shock. Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit. -
Page 5: Introduction
Introduction About PT3285PW The PT3285PW is a 31.5" fl at panel screen with an active matrix, thin-fi lm transistor (TFT) edge-lit LED LCD. Features include: • Direct Analog signal input • Direct Digital signal input • Active matrix TFT edge-lit LED LCD technology •... -
Page 6: Package Overview
Package Overview Display Power Cord VGA Signal Cable USB Cable (A to B) Audio-in Cable DVI-D Cable User’s Guide Touch Screen Driver Landing Strip Installation CD-ROM Cable Cover Screw... -
Page 7: Installation
Installation Product Overview • Front View • Bottom View AC IN COM OUT DVI IN COM IN VGA IN Remote Key AUDIO IN AUDIO OUT... -
Page 8: Vesa Mount For Your Monitor
VESA Mount for Your Monitor This monitor conforms to the VESA Flat Panel Mounting Physical Mounting Interface standard which defi nes a physical mounting interface for fl at panel monitors, and corresponding with the standards of fl at panel monitor mounting devices, such as wall and table arms. -
Page 9: Start Your Installation
Start Your Installation Please follow these instructions so that you can hook up the cables to associated connectors. 1. Lay the display fl at on an even surface and take off cable cover as seen in thestep 1 diagram. 2. Connect the cables to the appropriate connectors as seen in the step 2 diagram. 3. -
Page 10: Connecting The Display (Figure 8.1)
Connecting the Display (Figure 8.1) To setup this display, please refer to the following fi gure and procedures. Be sure all equipment is turned off. 2. Connect the AC power cord to the power connector on the monitor and the other end into an electrical outlet (8.1). -
Page 11: (Figure 8.1)
(Figure 8.1) Controlling the PT3285PW monitor via RS-232 C Remote Control (Optional) The PT3285PW monitor can be controlled by connecting a PC with a RS-232C terminal diagramed below: COM In COM Out COM In Note: Two COM Ports are reserved for this option. -
Page 12: User Controls
User Controls Rear Panel Controls Icon Key Name Menu Down Select Power Menu off status Menu on status Menu appear Menu disappear / return to main item Brightness Main item select up / Adjust up Mute Main item select down / Adjust down Auto Adjust Select sub-item function Power On / Off... -
Page 13: How To Use The Osd Menus
How to Use the OSD Menus Icon Key Name Menu Down Select Power 1. Press the “MENU” button to pop up the “on-screen menu” and press “Up” or “Down” button to select among the six functions in the main menu. 2. -
Page 14: On-Screen Display Menus
On-Screen Display Menus Main OSD Menu: ITEM CONTENT The monitor luminance level control. Contrast The monitor backlight level control. Brightness Fine-tune the image to full screen automatically. Auto Adjust Moving screen image horizontal position to left or right. Left/Right Moving screen image vertical position to up or down. Up/Down The screen image horizontal dot clock adjustment. -
Page 15: Appendix Troubleshooting
► Use “Fine” to make an adjustment. If this problem still exists, use “Horizontal size” to make an adjustment. Problem: Touch no function (for Microsoft Windows® 7 only) ► Microsoft Windows® 7 operating system requires 15 seconds to recognize the PT3285PW after connecting the USB cable and power cable. -
Page 16: Warning Signal
Warning Signal If you see warning messages on your screen, this means that the display cannot receive a clean signal from the computer graphics card. Below are the three kinds of Warning Signal. Please check the cable connections or contact your local dealer or our service center for more information. -
Page 17: Product Dimensions
Product Dimensions 786.1mm 4- R13 69mm Front View Side View 590.0mm 98.1mm 98.1mm 400.0mm Back View... -
Page 18: Compatibility Modes
Compatibility Modes Mode Resolution H-Frequency(khz) V-Frequency(hz) IBM VGA 640X480 31.47 VESA SVGA 800X600 35.16 VESA SVGA 800X600 37.88 VESA XGA 1024X768 48.36 VESA SXGA 1280X1024 64.00 VESA SXGA 1280X960 60.00 WXGA+ 1440X900 56.00 WSXGA+ 1680X1050 65.20 VESA WXGA 1280X768 47.776 VESA WXGA 1280X720 44.77... -
Page 19: Touch Screen Driver Installation
USB cable and power cable. PT3285PW Calibration Tool Install: PLEASE NOTE! 1. Calibration is required when using PT3285PW touch display for the fi rst time or switching from monitor to PC. Do not touch the screen during calibration tool execution process. - Page 20 Tel: 1-866-PLANAR1 (866-752-6271) or +1 503-748-5799 outside the United States. Hours: 24 hours a day, 7 days a week © 2013 Planar Systems, Inc. 1/13 Planar is a registered trademark of Planar Systems, Inc. Other brands and names are the property of their respective owners.
