User Guide SoundPoint IP 670 Phone
Changing the Backlight Intensity
2 - 4
5. Press
Backlight intensity on the SoundPoint IP 670 phone has three modes:
•
Backlight On
•
Backlight Idle
•
Dim
You can modify the Backlight On intensity and the Backlight Idle intensity
separately. You can select high, medium, low, and off levels for both.
You can also modify the maximum backlight intensity.
If you have attached one or more SoundPoint IP Expansion Modules to your
SoundPoint IP 670 and you find that the backlight levels between them are
incompatible, you can modify the maximum backlight intensity on a
unit-by-unit basis. This allows you to match all Expansion Module backlights
to an overall consistent level. For more information, refer to
®
SoundPoint
IP Color Expansion Module
Dim mode intensity is determined by the Backlight On intensity and the
Backlight Idle intensity together as follows:
Backlight On Intensity
off
low
medium
high
high
high
high
The Backlight On mode turns on for following events:
•
Any key press
•
Hookswitch release
•
Incoming calls
•
Ending a call, holding a call, resuming a call by the other party
•
A voice or instant message received
to return to the idle display.
on page 5-1.
Backlight Idle Intensity
off
dimmer than low
dimmer than medium
off
low
medium
high
Using the
Dim Intensity
off
low
medium
medium
medium
medium
high
