Removing a Memory Upgrade Module

Perform steps 1 through 5 of Installing a Memory
1
Upgrade Module.
Pull the clips sideways away from each side of the
2
memory upgrade module at the same time.
While holding the clips out, remove the module
3
from the slot by lifting it up and pulling towards
the rear of your LIFEBOOK notebook. (Figure 38)
Store the memory upgrade module in a static
4
guarded sleeve.
Replace the cover by following step 8 of Installing
5
a Memory Upgrade Module.
A
FTER INSTALLING YOUR ADDED MEMORY MODULE
OPERATE PROPERLY ON YOUR

Checking the Memory Capacity

Once you have changed the system memory capacity by replacing the installed module with a larger one, be sure to
check that your notebook has recognized the change.
Check the memory capacity by clicking [Start] > Control Panel (Classic View) > System. The amount of memory is
displayed next to Memory (RAM): The amount of memory displayed should be approximately the total of all memory
modules installed. There may be a discrepancy which is allocated for fixed video memory.
I
F THE TOTAL MEMORY DISPLAYED IS INCORRECT
,
YOU MUST RESET THE POWER PLAN PARAMETERS IN ORDER FOR THE
S "H
LIFEBOOK .
EE IBERNATION
NOTEBOOK
,
CHECK THAT YOUR MEMORY UPGRADE MODULE IS PROPERLY INSTALLED
66 - Memory Upgrade Module
Memory Clip
Figure 38. Removing a Memory Upgrade Module
(S - -D ) F
AVE TO ISK EATURE
Memory Clip
S - -D
AVE TO ISK MODE TO
" 40.
ON PAGE
.
