Operator's Manual
Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty
O
'
M
peratOr
s
anual
3-in-1 Battery Mower — TB E25
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
TROY-BILT LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Form No. 769-06399
(October 25, 2010)
Advertisement
Related Manuals for Troy-Bilt TB E25
Summary of Contents for Troy-Bilt TB E25
- Page 1 READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL BEFORE ATTEMPTING TO OPERATE THIS MACHINE. FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY. TROY-BILT LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 Form No. 769-06399 (October 25, 2010)
- Page 2 Model TB E25 For a new battery pack, order part 725-05089.
- Page 3 Model TB E25 Ref. Ref. Part Number Description Part Number Description 710-05151 M8 Screw 787-01839 Deck 731-08261 Shroud 715-04107 Quick Release Pin 712-04257 M8 Nut 731-07619 Side Discharge Door 712-04250 M6 Nut 731-07620 Side Discharge Chute 720-04147 Wing Knob 731-07621...
