GE Profile Arctica PTS25LHPBB Dimension Manual

TM
PTS25LHP – GE Profile Arctica
Dimensions (in inches)
B
A
Specification Created 2/03
24.6 Cu. Ft. Top-Freezer Refrigerator
™
H
G
C
D
Height to top of hinge (in.) A
Height to top of case (in.) B
Case depth without door (in.) C
Case depth less door handle (in.) D
Case depth with door handle (in.) E
Depth with fresh food door open 90° (in.) F
E
Width (in.) G
Width with door open 90° with door handle (in.) H
F
Each side (in.)
Top (in.)
Back (in.)
Total volume and shelf
area are calculated by the
Association of Home
Appliance Manufacturers'
standards.
For answers to your Monogram,
GE appliance questions, visit our website at
R
GEAppliances.com or call
GE Answer Center
68-5/8
67-7/8
27-5/82
31-5/8
33-5/8
66
35-7/8
38
1/8
1
1
Listed by
Underwriters
As an ENERGY STAR ® Partner,
GE has determined that this product
Laboratories
R
meets the ENERGY STAR
guidelines for energy efficiency.
® GE Profile ™ or
® service, 800.626.2000.
®
