I NS TAL L AT IO N M A N U A L F OR
T FM M O D E L S ( T RUE F R E E Z E R M E R C H A N D IS ER )
TABLE OF CONTENTS
Safety Precautions --------------------------- 1
Proper Disposal ----------------------------- 2
Connecting Electricity------------------------- 3
Adapter Plugs ------------------------------ 3
Ownership --------------------------------- 4
Required Tools ------------------------------ 4
Uncrating --------------------------------- 4
Location ---------------------------------- 5
Leveling Cabinet ---------------------------- 5
Sealing Cabinet to the floor / Ventilation /
Cabinet Drain ------------------------------ 6
TFM-29FL
Wire Gauge Chart --------------------------- 7
Electrical Instructions & Start-up ---------------- 8
Operations --------------------------------- 9
Cleaning the Condenser ---------------------- 10
Important Warranty Information ---------------- 11
Stainless Steel Equipment Care & Cleaning ---- 12-13
Warranty (U.S.A. & Canada Only!) --------------- 14
CONGRATULATIONS!
You have just purchased the finest commercial
refrigeration available. You can expect many years
of trouble-free operation.
TFM-41FL
TF M ( T RUE FRE EZER
ME RCH ANDIS ER)
............ www.truemfg.com ............
#922341
