Tripp Lite SmartRack SRW10US Features & Specifications

Model #: SRW10US
SmartRack 10U Wall-Mount Rack Enclosure Cabinet
Description
The SRW10US 10U Wall-Mount Rack Enclosure Cabinet is designed to integrate wall-mounting, easy equipment access, and cable management in
IT network applications with limited floor space. Ventilated front door and side panels allow generous airflow to keep equipment operating safely.
Adjustable rack rails with square mounting holes accommodate up to 10U of standard 19" rackmount equipment. Supports up to 200 lbs of
equipment. A sturdy hinge between the cabinet and the wall-mount bracket allows the cabinet to swing away from the wall for easy access to
equipment and cabling. Top and bottom panels include convenient cutouts for cable routing.
Package Includes
SRW10US Wallmount Rack Enclosure
(24) M6 screws
(24) M6 cagenuts
(24) M6 washers
(2) Keys
Owner's Manual
Features
10U wall-mounted enclosure
Adjustable mounting depths from 3" to 20.5" inches
Ventilated front door and side panels for increased airflow
Hinged cabinet swings away from wall bracket for easy equipment and cable access
Locking, reversible front door
Locking, removable side panels
Top and bottom panel cable access openings
Fully assembled for quick installation
Meets all enclosure requirements towards PCI DSS (Payment Card Industry Data Security Standard) Compliance
Specifications
PHYSICAL
Installed whole system
maximum rack depth (inches)
Highlights
20.5
10U with adjustable front and rear vertical rackmount rails
Hinged cabinet swings away from wall bracket for easy equipment access
(swing direction is reversible)
Locking, reversible front door and locking, removable side panels
Fully assembled for quick installation
Meets all enclosure requirements towards PCI DSS (Payment Card Industry
Data Security Standard) Compliance
