Cub Cadet BV 228 Operator's Manual

Removing Unit From Carton

Assemble The Unit

1 1 2
Remove all contents from Insert the upper blower
carton. tube into the blower outlet
and turn it clockwise until
it locks into place.
Assemble The Unit

Starting The Unit

Primer
Bulb
10 X
5 1 6
Place the unit on a level
Press the primer bulb 10
surface. Fill the fuel tank. times, or until fuel is visible.
Starting The Unit
1 8 9
Crouch in the starting Squeeze and hold the
position. throttle for all further steps.
Starting The Unit
3-5 X
12 1 13
Continue to squeeze the Continue to squeeze the
trigger. Pull the rope 3-5 trigger, or press down the
times to start the engine.
cruise control, and allow the
unit to warm up for 30-60
seconds.
IMPORTANT: READ OPERATOR'S MANUAL THOROUGHLY AND FOLLOW THE SAFE OPERATION PRACTICES WHILE OPERATING THE UNIT.
50:1
1 Gallon
3 4
Install the lower blower tube Mix thoroughly in a separate
onto the upper blower tube fuel can:
and turn it clockwise until it
– 2.6 fl. oz. of 2-cycle
locks into place. engine oil
– 1 gallon of unleaded
gasoline
NOTE: Do not mix directly in
the fuel tank.
Choke Lever
7
Move the choke lever to
Position 1.
5 X
10 11
Pull the rope 5 times. Move the choke lever to
Position 2.
Call 1-877-282-8684
IF engine fails to start after 2 attempts,
14
move choke lever to position 3 and pull
the starter rope until engine starts
Continue to squeeze the
trigger. Move the choke
IF unit still fails to start, refer to the
lever to Position 3. Warm
operator's manual for additional starting
the unit for an additional 60
seconds. The unit may be
used during this time.

Tools Required:

• Flathead Screwdriver
On/Off Stop Control
2.6 oz
Upper Blower Tube
Lower Blower Tube
Lower Vacuum Tube
Need Help?
DIDN'T START?
Repeat the starting instructions.
and troubleshooting information
Handle
Trigger
Cruise Control
Spark Plug
Choke Lever
Muffler
Cover
Primer Bulb
Upper Vacuum Tube
Vacuum Elbow
Vacuum Bag Strap
Cinch Strap
Vacuum Bag
Zipper
Air Filter
Cover
Starter Rope
Fuel Cap
