Cub Cadet BB230 Operator's Manual

Remove Unit From Carton Assemble The Unit
1 1 2
Remove all contents from Place a hose clamp over
the carton. the end of the Flex Tube
and slide the end of the
with the clamp on it over
the elbow tube. Tighten
the clamp screw.
Assemble The Unit
50:1
1 Gallon
7
6
Loosen the 2 screws on Mix thoroughly in separate
fuel can:
the throttle control. Move
– 2.6 fl. oz. of 2-cycle
the throttle control to the
position that provides the engine oil
– 1 gallon of unleaded
best grip and tighten.
gasoline
NOTE: Do not mix directly
in fuel tank.
Start The Unit
SLOW
FAST
11 12
Press down cruise control Crouch in starting
to FAST position. position.
IMPORTANT: READ OPERATOR'S MANUAL THOROUGHLY AND FOLLOW THE SAFE OPERATION PRACTICES WHILE OPERATING THE UNIT.
NEED HELP?
769-07539 P00
Operator's Manual
3
Place a hose clamp over
the other end of Flex Tube
and slide the end over the
top end of the upper
blower tube. Tighten the
clamp screw.
2.6 oz
8
Place unit on a level
urface and fill fuel tank.
DO NOT overfill.
5 X
13
Pull rope 5 times.
Call 1-877-282-8684 in U.S. or 1–800–668–1238 in
4 5
Insert the upper blower Insert the lower blower
tube into the lower blower tube into the nozzle and
tube and twist the lower twist the nozzle clockwise
tube clockwise unit it locks until it locks into place.
into place. Zip tie the throttle cable to
the elbow tube.
Start The Unit
Primer
Bulb
10 X
9 10
Press primer bulb 10 Move choke lever to
times, or until fuel is Position 1.
visible
14 15
Move choke lever to Pull rope 3-5 times to
Position 2 . start engine. Keep the
cruise control in FAST
position and allow unit to
warm up for 30 to 60
seconds.
BB230
2-Cycle Backpack
Blower
Tools Required-
Phillips Screwdriver
T-20 Torx ® Screwdriver
Flex Tube
On/ Off Switch
Cruise Control
Spark Plug
Throttle Control
Lower Blower Tube
Nozzle
Upper Blower
Tube
Choke Lever
Primer Bulb
Fuel Cap
SLOW
16 17
Continue to keep the
Move choke lever to
Position 3. cruise control in FAST
position and warm unit for
an additional 60 seconds
to complete warm-up. Unit
may be used during this
time.
DIDN'T START?
Repeat these instructions.
IF the engine hesitates, return the choke lever to
Position 2 and continue the warm-up.
IF the engine does not start, go back to step 9.
IF the unit fails to start after 2 attempts, move choke
lever to Position 3 and pull rope until unit starts
CANADA
Starter Rope
FAST
01/12
