Intrusion Alarm Systems | EN4216R Wireless LCD Receiver
EN4216R Wireless LCD Receiver
www.boschsecurity.com
The EN4216R LCD Receiver integrates up to sixteen
900 MHz wireless transmitters into any application.
The Inovonics EchoStream platform uses diversity
reception and advanced signal processing to reduce
dead spots in transmission areas. The liquid crystal
display (LCD) allows the user to view the current
status of all transmitters and view the history of
events. Each receiver stores up to 50 events. The
receiver provides versatile options for adding high
performance wireless to an installation.
System overview
Powered by Inovonics
The Inovonics EchoStream platform, powered by
Inovonics wireless mesh network technology, ensures
superior range, reliability, and scalability for
commercial applications. Using a wide range of
transmitters and repeaters, this proven technology
provides flexibility and performance to meet the most
stringent requirements. This exclusive protocol is
available only on Inovonics EchoStream products.
Wireless 900 MHz Band
The Inovonics EchoStream platform sends redundant
information on several multi-frequency channels within
the FCC Part 15 900 MHz band, providing superior
range and reliability. In comparison, systems that use a
single frequency technology can only send information
Monitors up to 16 transmitters or repeaters
u
Text display (LCD)
u
Cost-effective solution for small systems
u
Flexible alarm and fault output
u
Wireless registration
u
on one narrow band channel. Any interference within
the band can cause missed signals. With wireless
registration, it is easy to add this technology to any
application.
Functions
Flexible Outputs
Transmitters and repeater faults and alarms map to
any of the receiver models.
Wireless Registration
There is no external programmer required. The
transmitter is enrolled using a wireless programming
routine built into the receiver. Wireless registration
reduces installation time.
Secure Wireless Implementation
Jam detection monitors all channels for the presence
of interference for more than 20 sec. A reset terminal
is inside the receiver, allowing the receiver to accept
external reset signals. The receiver includes a case
tamper and internal antennas for added security.
Status Indication
The LCD shows the current condition of each
transmitter. The LCD also provides a history of past
events including activation, tamper, low battery, and
inactivity.
