MO1106-EA
The watch continues to operate, even when it is not exposed to light. Leaving the
watch in the dark can cause the battery to run down, which will result in some watch
functions being disabled. If the battery goes dead, you will have to re-configure
watch settings after recharging. To ensure normal watch operation, be sure to keep it
exposed to light as much as possible.
Battery charges in the light.
Bright Light
Solar cell
(Converts light to
electrical power.)
LEVEL 1
LEVEL 2
LEVEL 3
Charge
LEVEL 4
Rechargeable battery
E-2
About This Manual
E-4
Procedure Lookup
The following is a handy reference list of all the operational procedures contained in
this manual.
To set the current digital time and date .............................................................. E-11
To change the Daylight Saving Time (summer time) setting ............................ E-15
To view the time in another city ........................................................................... E-18
To toggle a city code time between Standard Time
and Daylight Saving Time ............................................................................... E-18
To swap your Home City and World Time City ................................................... E-19
To Set An Alarm Time ............................................................................................. E-21
To turn the Hourly Time Signal on and off .......................................................... E-23
E-6
General Guide
Press
to change from mode to mode.
In any mode (except when a setting screen is on the display), press
the face of the watch.
Timekeeping Mode
E-8
Operation Guide 5208
Battery discharges in the dark.
Electrical
energy
All
LEVEL 1
functions
enabled
LEVEL 2
Dis-
LEVEL 3
charge
LEVEL 4
Depending on the model of your watch, display text
appears either as dark figures on a light background, or
light figures on a dark background. All sample displays
in this manual are shown using dark figures on a light
background.
Button operations are indicated using the letters shown
in the illustration.
Each section of this manual provides you with the
information you need to perform operations in each
mode. Further details and technical information can be
found in the "Reference" section.
Battery Level Indicator
Getting Acquainted
Congratulations upon your selection of this CASIO watch. To get the most out of your
purchase, be sure to read this manual carefully.
Keep the watch exposed to bright light
Bright Light
Solar cell
The actual level at which some functions are disabled depends on the watch model.
Be sure to read "Power Supply" (page E-33) for important information you
need to know when exposing the watch to bright light.
If the display of the watch is blank...
If the display of the watch is blank, it means that the watch's Power Saving function
has turned off the display to conserve power.
See "Power Saving Function" (page E-46) for more information.
Some or all
functions
disabled
Contents
General Guide ......................................................................................................... E-8
Timekeeping .......................................................................................................... E-10
World Time ............................................................................................................. E-17
Alarms .................................................................................................................... E-20
Countdown Timer .................................................................................................. E-24
Stopwatch .............................................................................................................. E-29
Illumination ............................................................................................................ E-31
Power Supply ........................................................................................................ E-33
Reference .............................................................................................................. E-44
Specifications ....................................................................................................... E-50
To configure the countdown timer ...................................................................... E-25
To use the countdown timer ................................................................................ E-27
To measure times with the stopwatch ................................................................ E-30
To illuminate the display ...................................................................................... E-31
To specify the illumination duration ................................................................... E-32
To adjust home positions ..................................................................................... E-42
To turn the button operation tone on and off ..................................................... E-45
To recover from the sleep state ........................................................................... E-47
World Time Mode
to illuminate
Stopwatch Mode
The electricity generated by the solar cell of the watch is
stored by a built-in battery. Leaving or using the watch
where it is not exposed to light causes the battery to run
down. Make sure the watch is exposed to light as much as
possible.
When you are not wearing the watch on your wrist,
position the face so it is pointed at a source of bright
light.
You should try to keep the watch outside of your sleeve
as much as possible. Charging is reduced significantly if
the face is only partially covered.
Alarm Mode
Countdown Timer Mode
E-1
E-3
E-5
E-7
E-9
