Page 1: Illustrated Parts List
ILLUSTRATED PARTS LIST MODEL NUMBER MRT6 PRODUCT NUMBER 960 91 00-21 MFG. ID NO. 96091002103 581 63 87-27 Rev. 2 08.19.13 BY... -
Page 2: Handle Assembly
TILLER - MODEL NO. MRT6 (PRODUCT NO. 960 91 00-21) MFG. ID. NO. 96091002103 HANDLE ASSEMBLY 12 13 handle_assy_106 PART PART DESCRIPTION DESCRIPTION 819 13 16-11 Washer 13/32 x 1 x 11 Gauge 532 18 94-82 Control, Throttle 532 42 76-43 Grip, Handle... - Page 3 TILLER - MODEL NO. MRT6 (PRODUCT NO. 960 91 00-21) MFG. ID. NO. 96091002103 MAINFRAME, LEFT SIDE 28 3 mainframe_left_30 PART PART DESCRIPTION DESCRIPTION 873 93 06-00 Nut, Hex 3/8-16 28 532 10 46-79 Pulley, Idler 583 87 77-01 Shield, Inner Belt Guard, R.H.
- Page 4 TILLER - MODEL NO. MRT6 (PRODUCT NO. 960 91 00-21) MFG. ID. NO. 96091002103 MAINFRAME, RIGHT SIDE PART PART DESCRIPTION DESCRIPTION 873 97 05-00 Locknut, Hex, Flanged 5/16-18 - - - Engine, Briggs & Stratton 581 86 47-01 Bracket, Reinforcement...
- Page 5 TILLER - MODEL NO. MRT6 (PRODUCT NO. 960 91 00-21) MFG. ID. NO. 96091002103 TRANSMISSION PART PART DESCRIPTION DESCRIPTION 532 18 85-54 Transmission Assembly 532 15 07-37 Ground Shaft Assembly (In cludes Key Numbers 2–53) 532 14 30-08 Bearing, Shaft, Ground Drive, R.H.
- Page 6 TILLER - MODEL NO. MRT6 (PRODUCT NO. 960 91 00-21) MFG. ID. NO. 96091002103 TINE SHIELD PART PART DESCRIPTION DESCRIPTION 873 90 05-00 Locknut, Hex, Flanged 5/16-18 874 93 06-32 Bolt, Hex Head 3/8-16 x 2 532 19 57-97 Shield, Side, Outer, L.H.
-
Page 7: Tine Assembly
TILLER - MODEL NO. MRT6 (PRODUCT NO. 960 91 00-21) MFG. ID. NO. 96091002103 TINE ASSEMBLY tine_ipb_1 PART PART DESCRIPTION DESCRIPTION 532 00 44-59 Tine, Outer, L.H. 10 581 81 37-01 Assembly, Hub and Plate, R.H. 532 13 26-73 Clevis Pin 11 532 00 65-55 Tine, Inner, R.H. - Page 8 TILLER - MODEL NO. MRT6 (PRODUCT NO. 960 91 00-21) MFG. ID. NO. 96091002103 DECALS PART DESCRIPTION 532 15 98-77 Decal, Hand Placement 532 10 21-80 Decal, Shift Indicator 532 14 54-37 Decal, Euro, C.E. 532 43 53-35 Decal, Engine, B&S...
