Page 1 user’s guide hp StorageWorks disk system 2300 Edition E0902...
Page 2 Trademark Information Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential Red Hat is a registered trademark of Red Hat Co.
Page 3: Table Of Contents
contents Product Description 11 General Description 11 Features 13 Status Indicators 15 Power/Standby Switch 16 High Availability 16 Clustering (NT) 16 Upgradability 16 Environmental Services 17 Hardware Event Monitoring 17 Components 18 Disk Modules and Disk Module Filler Panels 18 BCCs and BCC Filler Panels 19 Power Supply/Fan Module 22 Hardware/Software Requirements 24...
Page 4 Installing PDUs 39 Software Requirements 42 Auto-Termination 43 Step 1: Gather Tools 44 Step 2: Unpack the Product 44 Step 3: Install the device 47 Installing the Storage Device into a Rack System/E 47 Installing the storage device into an HP Computer Cabinet 56 Installing the Storage Device into a Rittal-Style Rack 64 Install the Disk System 70 Step 4: Install BCCs 71...
Page 5 Troubleshooting 95 Overview 96 Event Notification (HP-UX Systems) 97 HP Command View SDM 100 TopTools 100 Status LEDs 101 Isolating Faults 104 Removal and Replacement 107 Disk Module 110 Preparation (HP-UX 11.XX) 110 To Determine If a Volume Group or Physical Volume Group Is Active 111 To Determine If the Physical Volume Is Attached 111 To Replace Attached Physical Volumes 112...
Page 6 Deskside Base/External Covers (HP-Qualified Only) 133 Powering Down the Disk System 133 Removing the deskside base and external covers from the disk system 133 Tools 133 Procedure 133 Reinstalling the deskside base and external covers on the disk system. 138 Reference 141 Product Models 141 Upgrade Products 142...
Page 7 figures Figure 1 Disk System - Racked Views 14 Figure 2 Disk System Deskside Views 15 Figure 3 Disk Module 19 Figure 4 BCC 20 Figure 5 BCC Filler Panel 21 Figure 6 Power Supply/Fan Module 22 Figure 7 Basic Configuration - Single Host, Single Disk System 28 Figure 8 Single Host, Split Bus Configuration 29 Figure 9...
Page 8 Figure 30 Installing enclosure retention clipnuts in an HP Computer Cabinet 61 Figure 31 Installing the storage device in an HP Computer Cabinet 62 Figure 32 Installing a filler panel in an HP Computer Cabinet 63 Figure 33 Rittal-Style Rail Kit Contents 64 Figure 34 Rail Alignment 65 Figure 35...
Page 9 tables Table 1 Inrush (Surge) Current and Duration 36 Table 2 Maximum Operating Current 36 Table 3 Recommended PDU/PDRUs for Multiple Disk Systems in HP Computer Cabinets 38 Table 4 Recommended PDU/PDRUs for Multiple Disk Systems in HP System/E Racks 38 Table 5 Disk System Accessories 44 Table 6...
Page 11: Product Description
Product Description General Description Hewlett-Packard’s StorageWorks Disk System 2300 (referred to in this guide as the disk system) is a high-availability Ultra160 SCSI storage product. Dual SCSI ports on dual bus controllers provide LVD connections to the host. Fourteen slots accept high-speed, high-capacity LVD SCSI disks connected to an LVD midplane.
Page 12 HP Command View SDM (Software Device Manager) software is designed to provide storage management for HP disk systems. This software, available on the HP Command View SDM CD-ROM, provides simple, yet sophisticated device management tools for the disk system. HP Command View SDM is supported on the following: HP-UX 11.00 (see Support Plus web site for the required patches) HP-UX 11.11 (see Support Plus web site for the required patches)
Page 13: Features
Features The disk system occupies 3 EIA units in a standard 19-inch rack. Disk drives mount in the front of the system. Redundant power supplies, and BCCs mount in the back. See Figure 1 and Figure 2 below. For disk slots and SCSI addressing, see Figure 49.
Page 14: Figure 1 Disk System - Racked Views
Product Description...
Page 15: Status Indicators
Status Indicators LEDs on the disk system enable you to detect and replace failed components and so prevent or minimize users’ downtime. For additional information about LEDs, see Chapter 4, Troubleshooting. On the front of the disk system, a pair of LEDs indicates the status of the disk system, and an LED for each slot shows disk I/O activity: The system power LED (B in Figure 1) indicates that power is on or off.
Page 16: Power/Standby Switch
Hardware event monitoring and real-time error reporting Clustering (NT) The HP Disk System 2300 is Microsoft® Cluster certified for a variety of solutions. For specific information about supported configurations, see the Hewlett-Packard Company or Microsoft web pages: http://hp.com http://microsoft.com Upgradability...
Page 17: Environmental Services
Hardware Event Monitoring A hardware event monitor monitors the disk system and reports changes in environmental status to Hewlett-Packard’s Event Monitoring System (EMS) for HP-UX. Hardware event monitoring is an important tool for implementing high availability. Using hardware event monitors, you can virtually eliminate undetected hardware failures that interrupt system operation or cause data loss.
Page 18: Components
Components User-replaceable components enable high availability and easy maintenance. This section describes the following components: Disks and disk fillers BCCs and BCC fillers Power supply/fan modules Disk Modules and Disk Module Filler Panels Disk modules, shown in Figure 3, contain 3.5-inch Low Profile Ultra 3 LVD disks.
Page 19: Bccs And Bcc Filler Panels
BCCs and BCC Filler Panels BCCs (Bus Control Cards) plug into two slots in the back of the disk system. Each BCC connects to both LVD (low voltage differential) buses inside the disk system. In full bus mode (DIP switch 1 set to “|”), both BCCs have access to all installed disks.
Page 20: Figure 4 Bcc
Other features of the BCC are: LEDs (C) indicating BCC status and bus configuration DIP switches (D) on the rear panel: 1 Bus Mode (full or split bus) 2 Monitor Mode (SAF-TE or SES) Locking thumbscrews (E) Cam levers (F) Product Description...
Page 21: Figure 5 Bcc Filler Panel
BCC circuitry provides the following functions: Bus configuration (see “Setting DIP Switches” in Chapter 3) Bus expansion (LVD) SCSI environmental services (see page 17) System fault detection A BCC filler panel (Figure 5) replaces the second BCC when redundancy is not required.
Page 22: Power Supply/Fan Module
Power Supply/Fan Module Redundant, hot-pluggable 340-watt power supplies convert wide-ranging AC voltage from an external main to stable DC output and deliver it to the midplane. Each power supply has an internal fan, an AC receptacle (A in Figure 6), two ejector handles (D) with thumbscrews (C), and 2 LEDs (B).
Page 23 Power supplies share the load reciprocally; that is, each supply automatically increases its output to compensate for reduced output from the other, and vice versa. If one power supply fails, the other delivers the entire load. Internal circuitry triggers a fault when the internal fan or other part fails. At the same time, the power fault LED (amber) illuminates, and, if enabled, the hardware event monitor sends an event message.
Page 24: Hardware/Software Requirements
Hardware/Software Requirements The disk system is supported on the following operating systems: HP-UX 11.00 with HWE 0302 (March 2002 Patch bundles) or greater HP-UX 11.11 with HWE 0302 (March 2002 Patch bundles) or greater Linux Red Hat 6.2, 7.0, 7.1 Windows NT 4.0 (Advanced Server, Enterprise Edition) Windows 2000 (Server and Advanced Server) Microsoft Windows.Net (Server and Advanced Server)
Page 25 A6829A, Dual Port Ultra160 SCSI (PCI bus) adapter Host bus adapter for rp54X0, rp7400, rp7410, and rp8400 servers and A-, N-, L-, V-Class, and Superdome systems (Full length card). The following host bus adapters are supported on HP Netservers: C7430A, PCI Ultra2 wide Host bus adapter D5025A, HP Ultra/Wide SCSI Host bus adapter for Netservers D9161A, NetRAID 4M/64MB Cache Host bus adapter for HP Netservers D9351A, NetRAID 4M/128MB Cache Host bus adapter for HP Netservers...
Page 26 The following HP Netserver models are supported by the Disk System 2300: rc7100 tc7100 tc 6100 tc4100 tc3100 rx4610 LXr8000 LXr8500 LH3/LH3r LH4/LH4r LH3000/LH3000r LH6000/LH6000r LC2000/LC2000r LT6000 LP1000r LP2000r E45/E50 E55/E60 E200/E200se E800 The following host bust adapters are not supported at this time: D2140A, NetRAID 1Si Host bus adapter D5955A, NetRAID 3Si Host bus adapter P3410A, NetRAID 1M Ultra160 SCSI Host bus adapter with 64MB...
Page 27: Topologies
Topologies The disk system supports high availability through redundant components and redundant connections to redundant hosts. Each SCSI port on a BCC can be connected to a different host bus adapter in the same or different hosts. Internal mirroring within the disk system is also possible. Basic high availability topologies are described on the following pages.
Page 28: Figure 7 Basic Configuration - Single Host, Single Disk System
Another type of high availability topology connects mirrored disk systems to redundant hosts. Dual host bus adapters in each host are connected to mirrored disk systems. With the disk systems in full bus mode (switch 1 on), each host can reach all disks in both disk systems.
Page 29: Figure 8 Single Host, Split Bus Configuration
The disk system can be connected to a single host with two host bus adapters (HBAs) in a split bus configuration. See Figure 8. Each HBA will do reads and writes to a maximum of seven disks. This configuration can provide a maximum capacity of approximately 1.1 Terabytes.
Page 30: Figure 9 Single Host Pv-Links Configuration
Data path redundancy can be secured with the configuration shown in Figure 9. Using an additional host bus adapter (HBA) and the LVM software, alternate links can be created, providing a redundant path to data for each disk system. In addition, a separate mirror path can be created for data protection.
Page 31: Figure 10 Two Host Non-High Availability Configuration
For customers with small data storage needs, a single disk system can be connected to two hosts in a split bus mode. Each host can do reads and writes to a maximum of seven disk modules. Each BCC can provide disk system status to the host it is connected to.
Page 32: Figure 11 Two Host High Availability Configuration
A two-host configuration could be constructed using the Disk System 2300. Each disk system could still be configured using mirrors. High availability software will protect against a system failure. See Figure 11, above. Product Description...
Page 33: Definitions
Definitions The following terms have specific meanings in the context of this guide: High availability (HA) HA describes hardware and software systems that are designed to minimize planned and unplanned downtime. High availability is measured at the system level and stated as the percentage of time the system is in a state to do useful work;...
Page 34: Ultra160 Scsi
Ultra160 SCSI Ultra160 is a SCSI interface that transfers 160 Mbytes/sec for wide busses. Product Description...
Page 35: Installation
Installation Installation...
Page 36: Preparation
Preparation Before installing the disk system, make sure (1) electrical wiring, breakers, and PDUs meet power needs, (2) the required support software is installed on the host, and (3) if you are connecting the disk system to a V-class server, auto- termination is enabled on the host bus adapter.
Page 37: Choosing Pdus
Circuit breakers must be adequately rated for inrush and operating currents. Hewlett-Packard recommends magnetic-type circuit breakers, which are capable of handling large inrush currents for short durations (10 to 12 cycles) and are rated adequately for steady state currents. Choosing PDUs Peak power requirements and PDU capacity affect the number of disk systems that can be installed in a rack.
Page 38: Table 3 Recommended Pdu/Pdrus For Multiple Disk Systems In Hp Computer Cabinets
Table 3 Recommended PDU/PDRUs for Multiple Disk Systems in HP Computer Cabinets No. of Disk 1.1 meter (21 U) 1.6 meter (32 U) 2.0 meter (41 U) Systems 2 5-foot/16-amp or 1 – 5 2 3-foot/16-amp 2 19-inch/16-amp PDUs PDUs* PDUs 2 19-inch/16-amp PDUs...
Page 39: Installing Pdus
Installing PDUs The 19-inch PDUs and PDRUs can be installed vertically or horizontally in the rack. Choose PDU/PDRU locations with the following guidelines in mind: Place PDU/PDRUs within the reach of disk system cords. Place PDU/PDRUs vertically whenever possible. See sample installations in Figure 12 Figure 13.
Page 40: Figure 12 Pdru Placement In 1.6-Meter Rack
Installation...
Page 41: Figure 13 Pdru Placement In A 2.0-Meter Rack
Installation...
Page 42: Software Requirements
Software Requirements Ensure that the minimum revisions of HP-UX extension software and online diagnostics are installed. These release packages enable CommandView SDM and EMS for the disk system. 1. At the host console, enter swlist | grep HWE and look for the following extension software according to the installed HP-UX revision: HP-UX 11.00 with HWE 0302 HP-UX 11.11 with HWE 0302...
Page 43: Auto-Termination
Auto-Termination Auto-termination is disabled when a shunt is installed over both pins on the TP2 pinset. To enable auto-termination, remove the shunt entirely or move it to only one of the pins. The result must be open pins, as shown Figure 14.
Page 44: Step 1: Gather Tools
Step 1: Gather Tools Once the electrical, software, and special V-class preparations are complete, collect the tools you need to install the disk system hardware: Torx T25 screwdriver Torx T15 screwdriver Small flat-blade screwdriver Step 2: Unpack the Product 1. Lift off the overcarton and verify the contents of the accessories (top) box. Table 5 Figure Table 5...
Page 45: Figure 15 Disk System Accessories
2. Lift off the accessories box and the top of the under box, and verify the contents shown in Table 6 Figure Installation...
Page 46: Figure 16 Disk System Contentsdisk System Contents
Table 6 Disk System Contents Figure Part (part number) Label Installation Manual (A6490-96003) Two power cords (8120-6514) SCSI Cable (see Reference Section for part numbers) Disk System Chassis (A6490-60100) If a part is missing, contact an HP sales representative. Installation...
Page 47: Step 3: Install The Device
Step 3: Install the device Follow the procedures in this section to install your storage device in one of the following rack systems: HP Rack System/E HP Computer Cabinet Rittal-Style Rack Installing the Storage Device into a Rack System/E Your storage device can be installed into any of these HP Rack System/E Products: A4902A HP Rack System/E41 (1.96 M;...
Page 48: Figure 17 Hp Rack System/E Rail Kit Contents
Installation...
Page 49: Figure 18 Hp Rack System/E Installation Overview
2. Study the installation overview (see Figure 18). The following tools are required for the installation of the storage device: Flat-blade screwdriver T25 nut driver WARNING To ensure cabinet or rack stability and avoid possible injury, always install the storage devices in the rack or cabinet from the bottom up.
Page 50: Table 7 Rail Positions For Sequential Disk Systems
3. Locate a place on the rack columns with the available space required for the installation of the storage device. The storage device and the rail kit require 3 EIA units of space. Use the following table as a guide for placement of the rails in a Rack System/E where multiple disk systems will be installed.
Page 51: Figure 20 Installing Clipnuts For An Hp Rack System/E
4. Install clipnuts as shown in Figure Figure 20. Installing clipnuts for an HP Rack System/E Installation...
Page 52: Figure 21 Installing Rails In An Hp Rack System/E
5. Insert the rail tabs into the appropriate column holes (see Figure 21). 6. Secure the rail ends with one M5 screw each. 7. Install clipnuts on the front columns of the cabinet (see Figure 22). These are used for the retention bracket screws. Installation...
Page 53 8. Place the storage device on the rails and slide it into the cabinet until the retention bracket comes in contact with the rack column (see Figure 23). WARNING An empty storage device weighs more than 54 pounds (24.5 kg) (without disk modules installed).
Page 54 9. Insert and tighten the storage device retention (M5) screws through the retention bracket (see Figure 23). Installation...
Page 55 10. Place a rail clamp on each rail and slide them to each bottom rear corner of the storage device.(see Figure 24). 11. Secure the clamps to the rails. Use one 10-32 screw for each rail clamp. Installation...
Page 56: Installing The Storage Device Into An Hp Computer Cabinet
Installing the storage device into an HP Computer Cabinet Your storage device can be installed into the following Computer Cabinets: C2785A Computer Cabinet (1.10M; 21U) C2786A Computer Cabinet (1.60M; 32U) C2787A Computer Cabinet (1.96M; 41U) Caution To ensure proper installation, only use the instructions in this manual for installing the storage device in the HP Computer Cabinet.
Page 57: Figure 26 Hp Computer Cabinet Installation Overview
2. Study the installation overview (see Figure The following tools are required for the installation of the storage device: Flat-blade screwdriver T25 nut driver WARNING To ensure cabinet or rack stability and avoid possible injury, always install storage devices in the rack or cabinet from the bottom up.
Page 58 Installation...
Page 59: Figure 28 Installing Rail Clip Nuts In The Hp Computer Cabinet
4. Install clipnuts as shown in Figure 28 Installation...
Page 60: Figure 29 Installing Rails In The Hp Computer Cabinet
5. Insert the rail tabs into the appropriate holes on the HP Computer Cabinet columns (see Figure 29). 6. Secure the rail ends with one M5 screw each. Figure 29. Installing rails in the HP Computer Cabinet A rail tab B clip nut Installation...
Page 61: Cabinet
7. Install clipnuts on the front columns of the cabinet (see Figure 30). These are used for the device retention screws. 8. Place the storage device on the rails and slide it into the cabinet until the retention bracket comes in contact with the rack column (see Figure 31).
Page 62: Figure 31 Installing The Storage Device In An Hp Computer Cabinet
9. Tighten the storage device retention (M5) screws through the retention bracket (see Figure 31). Installation...
Page 63: Figure 32 Installing A Filler Panel In An Hp Computer Cabinet
10. Install a filler panel in the space below the storage device. If a filler panel is required, it must be ordered separately. Contact your local HP sales representative for assistance. Installation...
Page 64: Installing The Storage Device Into A Rittal-Style Rack
Installing the Storage Device into a Rittal-Style Rack Your storage device can be installed into the Rittal-Style Rack by doing the following steps: 1. Inspect the contents of the rail kit. If any parts are missing, call your nearest HP sales office. See Figure Installation...
Page 65: Figure 34 Rail Alignment
2. Align the front of rails to the inside of the front cabinet column. Carefully observe the alignment of the groups of holes on the columns so the holes in the rails align properly. Installation...
Page 66: Figure 35 Front Screw Installation
3. Insert and finger tighten the rail mounting screws. Use the third and seventh holes from the top of rail to mount the rail to the front column of the cabinet. 4. Extend the adjustable slide to the back column of the cabinet. 5.
Page 67: Figure 36 Rear Slide Extension
6. Tighten the center nuts to finger tightness. Figure 37. Center Nut Tightening 7. Tighten all screws to their final tightness using a driver. Tighten the screws that hold the rail to the columns first, before tightening the center slide nuts to their final tightness. Installation...
Page 68: Figure 38 Installing A Disk System Into The Rittal-Style Rack
8. Repeat the procedure above for the other rail. 9. Insert the disk system (with disk modules and power supplies removed) onto the rails. 10. Move the disk system retention brackets to the frontmost set of mounting holes. This allows the disk system to install further back into the cabinet; and so, allows the cabinet doors (if present) to close properly.
Page 69: Figure 39 Moving A Disk System Retention Bracket
11. Push the disk system back into the rack until the disk system retaining bracket is flush against the front column of the rack. 12. Bolt the disk system to the front column. Use the fifth hole from the top of the front of the rail. Figure 40.
Page 70: Install The Disk System
Install the Disk System 1. Remove the power supply/fan modules to prepare the disk system for lifting: Loosen the screws in each extractor handle of each power supply/fan module with the chassis still in the box. Pull the extractor handles out from the center of the power supply to disengage the it from the midplane.
Page 71: Step 4: Install Bccs
Step 4: Install BCCs The disk system comes with one or two BCCs, depending on the option purchased. If you are installing only one BCC, you will install a BCC filler in the open BCC slot. 1. Attach your ESD strap to ground. 2.
Page 72: Figure 41 Bcc Installation
8. If you have a second BCC, repeat steps 2 through 6, installing the second BCC in the right slot. Installation...
Page 73: Figure 42 Bcc Filler Panel
9. If you do not have a second BCC, install the BCC filler as follows: Unpack the BCC filler from the accessories box. Align the filler panel edges with the appropriate slot and insert the filler into the open slot until the cam handles engage. Press the cam handles toward the center of the BCC until they are against the face of the filler panel.
Page 74: Step 5: Set Dip Switches
Step 5: Set DIP Switches BCCs are shipped from the factory with all DIP switches (see Figure 43) in the “|” position. The pull-out label on top of the disk system identifies each switch position. Caution DIP Switch settings must be the same on both BCCs. If settings differ, the disk system will fail its power-on self-test and the disks will not be accessible through the second BCC.
Page 75: Step 6: Connect Scsi And Power Cables
Step 6: Connect SCSI and Power Cables 1. Attach an LVD SCSI cable to SCSI port A or B, on one or both BCCs. (Sample topologies appear in Chapter 1.) 2. Attach the other end of each SCSI cable to a host bus adapter. (See bus configuration options in Chapter 3.) 3.
Page 76: Figure 44 Wiring Scheme For 1.6-Meter Rack
Installation...
Page 77: Figure 45 Wiring Scheme For 2.0-Meter Rack
Installation...
Page 78: Step 7: Install Disk Modules
Step 7: Install Disk Modules Caution Touching exposed areas on the disk can cause electrical discharge and disable the disk. Be sure you are grounded and be careful not to touch exposed circuits. Disk modules are fragile and ESD sensitive. Dropping one end of the disk just two inches is enough to cause permanent damage.
Page 79 1. Determine which slots, 1 through 14, will contain disk modules and which will contain fillers. — If DIP switch 1 is set to “|” (full bus mode), choose any slots for disk modules or fillers. In full bus mode, the SCSI address 7 is reserved for the host bus adapter.
Page 80: Step 8: Turn On The Disk System
Step 8: Turn on the Disk System Caution When starting up the disk system, do not override automatic spin- up by issuing SCSI start commands to the drives. Doing so could cause an overcurrent fault, requiring a power cycle to recover. Press in the power/standby switch with the retracted tip of a pen or pencil to power-on the array (see Figure...
Page 81: Step 9: Verify Devices On The Host
Step 9: Verify Devices on the Host On an HP-UX host run IOSCAN (ioscan -f) and verify that the disks and BCC(s) are listed in IOSCAN output. If the displayed “S/W State” is not “claimed,” begin troubleshooting (see Chapter 4). Sample IOSCAN The example shows a fully loaded disk system.
Page 82: Where Do You Go From Here
The “descriptions” in this example represent some of the valid disk modules. Valid disk descriptions include: ST318404LC18-Gbyte 10K rpm LVD disk module ST318406LC ST336704LC36-Gbyte 10K rpm LVD disk module ST336706LC ST373405LC73-Gbyte 10K rpm LVD disk module ST318452LC18-Gbyte 15K rpm LVD disk module MAM3184MC ST336752LC36-Gbyte 15K rpm LVD disk module MAM3367MC...
Page 83: Configuration
Configuration Configuration...
Page 84: Viewing A Disk System In Ioscan
Viewing a Disk System in IOSCAN An IOSCAN (example below) shows each BCC (0/1/0/0.15.0) and disk in the disk system. Sample IOSCAN Type the command: ioscan -f Class H/W Path Driver S/W State H/W Type Description ============================================================================== ext_bus 0/1/0/0 c8xx CLAIMED INTERFACE SCSI C1010 Ultra160...
Page 85: Setting Dip Switches
Setting DIP Switches Two DIP switches on left slot BCC determine bus architecture and some bus behavior. If that BCC is removed, then the DIP switches on the other BCC define the bus. See Table 8 for a description of switch settings.
Page 86: Figure 48 Dip Switches
Configuration...
Page 87: Rationale
Rationale Sites choose DIP switch options according to their priorities and preferences. High availability sites, for example, may want automatic bus reset on whereas high performance sites may choose to turn it off. The following table gives some of the typical reasons for choosing specific DIP switch settings.
Page 88: Disk Addressing
Disk Addressing Each disk in the StorageWorks Disk System 2300 occupies a separate address (SCSI ID) on the SCSI bus. Disk addresses range from 0 to 6 and 8 to 14 in full- bus mode (DIP switch 1 set to “|”). In split bus mode (DIP switch 1 set to “0”), the left BCC (viewing the disk system from the rear) is on the high numbered bank (with disk slots 8, 9, 10, 11,12, 13, and 14) and the right BCC is on the low numbered bank (with disk slots 0, 1, 2, 3,4, 5, and 6) of disk slots.
Page 89: Disk Slots And Addressing
Note In split bus mode, the enclosure monitor circuitry on each BCC utilizes SCSI address 15. This is allowable since each BCC is connected to a separate SCSI bus. However, when the enclosure configuration is in Full Bus mode, and the separate SCSI busses on the midplane are connected together and there are two BCCs in the enclosure, the secondary BCC does not connect to the SCSI bus.
Page 90: Setting Up The Hardware Event Monitor
Setting Up the Hardware Event Monitor Separate monitors watch over the disks and the disk system. You need to install and configure the Disk Monitor (disk_em) and the High Availability Storage System Monitor (dm_ses_enclosure) for complete event notification. To install and configure the required monitors, refer to the EMS Hardware Monitors User’s Guide, which is included in Adobe Acrobat format on IPR Support Media.
Page 91: Updating Firmware (Hp-Qualified Only)
Updating Firmware (HP-Qualified Only) Obtain the latest disk or BCC firmware release from the support site before traveling to the customer site. For specific information about updating firmware, see the HP CommandView SDM Disk System Installation and User Guide, Version 1.04.
Page 92: Supported Operating Systems
Supported Operating Systems The HP Command View SDM software is supported on the operating systems listed below. Both the HP Command View SDM software and the Upgrade License software products are supported on these operating systems. Minimum system requirements for each operating system are identified in this section, prior to the installation instructions for each operating system.
Page 93: Hp Toptools
HP TopTools HP TopTools is a web-based, device management tool that enables administrators and MIS managers to use a web browser to obtain information about devices on their network. It provides specific management to the following HP products: HP Vectra and Brio Desktops HP Kayak and Visualize Workstations HP Omnibook Notebooks HP Netservers...
Page 94 Configuration...
Page 95: Troubleshooting
Troubleshooting Troubleshooting...
Page 96: Overview
Overview The following steps will help you identify and resolve disk system failures: Gather information from all sources: — Hardware event notifications (page 97) — Disk system LED status (page 101) — Online information tools (page 104) Isolate the cause of the problem (page 104). Correct the problem (chapter 5, Removal and Replacement).
Page 97: Event Notification (Hp-Ux Systems)
Event Notification (HP-UX Systems) The EMS hardware event monitor polls environmental services on the BCC and reports any changes in the status of monitored components. Depending on how the monitor is set up, you can receive messages at the console, in e-mail, in a log file, or through third-party applications.
Page 98 Event messages (see Figure 50) contain the following: Message Data – Date and time the message was sent, the source and destination of the message, and the severity level Event Data – Date and time of the event, the host, event ID, name of the monitor, event number, event class, severity level, hardware path, associated OS error log entry ID Error Description –...
Page 99: Figure 50 Sample Hardware Event Notification
Figure 50. Sample Hardware Event Notification Notification Time: Wed Feb 3 11:27:15 1999 yourserver sent Event Monitor notification information: /storage/events/enclosures/ses_enclosure/8_0_1_0.15.0 is >=1. Its current value is MAJORWARNING(3) Event data from monitor: Event Time: Wed Feb 3 11:27:15 1999 Hostname: yourserver.rose.hp.com IP Address : 15.43.213.13 Event ID: 0x0036b8a313000000002 Monitor...
Page 100: Hp Command View Sdm
HP Command View SDM For specific information about using HP CommandView SDM for viewing the disk logs and for other functions, see the HP CommandView SDM Disk System Installation and User Guide. This document can be found at the following URL: http://h200002.www2.hp.com/bc/docs/support/ SupportManual/lpg29284/lpg29284.pdf TopTools...
Page 101: Status Leds
Status LEDs LEDs indicate the status of the disk system itself and each of its components (see Table 11). Green and amber system LEDs are visible on the front of the disk system. They show that power is on (green) and a fault has occurred (amber).
Page 102: Table 11 Led Functions
LED states are described in Table 11: Table 11. LED Functions State Indication System Power Green Power is on Power is off System Fault Amber Self-test / Problem Normal operation Flashing BCC A & B DIP switch settings do not match. BCC Fault Amber Self-test...
Page 103 Table 11. LED Functions (Continued) State Indication Power Supply/ Amber Power Supply/Fan fault Fan Module Amber Host is identifying the power supply Flashing module. Green Operating normally Power is off. Disk Activity Green LED Disk module installed and operating normally (Controlled by the disk drive) Green Flashing Disk drive self-test in progress or I/O activity to/from disk (Controlled by the disk drive)
Page 104: Isolating Faults
Isolating Faults Table 12 lists the probable causes and solutions for problems you may detect on the disk system. When more than one problem applies to your situation, investigate the first description that applies. The table lists the most basic problems first and excludes them from subsequent problem descriptions.
Page 105 Table 12. Troubleshooting Table (Continued) Problem HW Event Probable Cause/Solution Description Category State Status Power supply/ Critical Amber Critical An incompatible or defective fan LED is component caused a amber temporary fault. Power supply hardware is faulty. Unplug the power cord and wait for the LED to turn off.
Page 106 Table 12. Troubleshooting Table (Continued) Problem HW Event Probable Cause/Solution Description Category State Status Temperatur Critical none Critical A fan is faulty. Check status and correct. e is over Temp is limit Airflow is obstructed; vents are >54.5º blocked. One or more slots are empty. Major none Non-...
Page 107: Removal And Replacement
Removal and Replacement Caution Do not remove hot-pluggable components until you have the replacement parts and are ready to install them. An empty slot will cause uneven cooling and eventual overheating. Caution Do not move the disk system with disks installed and power on. Even a one-inch drop of the disk system can damage spinning disks Removal and Replacement 107...
Page 108: Figure 52 Disk System Field Replaceable Units (Frus)
108 Removal and Replacement...
Page 109: Table 13 Jbod Enclosure Field Replaceable Units
Table 13. JBOD Enclosure Field Replaceable Units Fig. Exch/ Part No. FRU Description Repl. Type Item Part A6537-69001 18GB 10k rpm LVD disk module A6538-69001 36GB 10k rpm LVD disk module A6539-69001 73GB 10k rpm LVD disk module A6540-69001 18GB 15k rpm LVD disk module A6541-69001 36GB 15k rpm LVD disk module A6198-67014...
Page 110: Disk Module
Disk Module Add or replace disks to increase storage capacity or eliminate faults. (See Chapter 4 for troubleshooting procedures.) Disks must be Ultra-3 SCSI (LVD) and 3.5 inches wide but can vary in capacity. For current information about supported disks, consult an HP sales representative. You do not need to turn off the disk system to replace a disk or filler.
Page 111: To Determine If A Volume Group Or Physical Volume Group Is Active
To Determine If a Volume Group or Physical Volume Group Is Active At the host console, enter: # vgdisplay <VG name> For example: #vgdisplay /dev/vg00 If the volume group is not active, the host will display: # vgdisplay: volume group not activated. # vgdisplay: cannot display volume group /dev/vg00 The following messages will appear if the disk is defective:...
Page 112: To Replace Attached Physical Volumes
To Replace Attached Physical Volumes Use the following commands to reduce any logical volumes that have mirror copies on the faulty disk and to recreate the mirror extents once the disk has been replaced. Commands to recover from a host failure are included with most steps. Note The way that mirrors span several disks may not be duplicated exactly.
Page 113 For example: # vgcfgrestore -n /dev/vg00 /dev/rdsk/c2t4d0 If the host fails, repeat the step to ensure all configuration data is written to the new disk. Note If this replacement procedure is being performed now on another host system and there is no need to execute any lvreduce commands, then the configuration file can be updated with the vgcfbackup command.
Page 114: To Replace Unattached Physical Volumes
To Replace Unattached Physical Volumes Follow these instructions if the volume group is not active or if the physical volume is unattached. Replace the disk (see page 115). Execute IOSCAN to verify that the replaced disk is accessible and a proper replacement disk.
Page 115: Windows 2000
Exit the “Disk Administrator” utility and execute explorer (right-click start and choose explorer). View the newly created drives and ensure all drives are shown. Windows 2000 Note The following instructions are for the configuration of a new disk module. They should not be followed to add a disk module with data to an existing disk system.
Page 116 empty slot will cause uneven cooling and eventual overheating. Release the disk from the slot by squeezing the latch tab (B) and pulling it toward you. Caution Spinning disks generate heat and gyroscopic force. Wait for a spinning disk to slow down and cool off before removing it from the product.
Page 117: Figure 53 Disk Module Removal
Caution Replace the disk module or filler immediately (see next step). Caution Touching the disk circuit board can cause high energy discharge and permanently damage the disk. Disk modules are fragile. Handle carefully. Remove the replacement disk module from its ESD bag, being careful to grasp the disk module by its extraction handle (see Figure 53).
Page 118 Press the extraction handle to seat the disk module firmly on the midplane. An audible click indicates the disk module is fully seated. If you are installing a disk module (as opposed to a filler), monitor the LED (D). It should be on while the disk spins up and then turn off. The LED will blink with I/O activity to the disk.
Page 119: Bcc
Replace a BCC when troubleshooting shows that the card is faulty (see “Isolating Faults” in Chapter 4). There is no need to turn off the disk system to remove and replace a BCC. In full bus mode with two BCCs, there is also no need to stop I/O to the disks. In other configurations, however, the host must be notified that all disks on the affected bus will be unavailable for I/O.
Page 120: Figure 54 Bcc Removal And Replacement
Remove the replacement BCC from its ESD bag. Caution Switches must have the same settings on both BCCs. Open the cam levers (see Figure 54) of the replacement BCC by pulling them away from the center of the card. Insert the BCC in the empty slot. Push the cam levers flat against the center of the card to seat the BCC pins firmly on the midplane.
Page 121: Figure 55 Bcc Dip Switches
Watch the BCC Fault LED (B in Figure 55). It should come on briefly and then turn off. If the LED stays on and a buzzer sounds, the switch settings do not match the settings on the peer BCC. For other solutions to a BCC fault, see “Isolating Causes”...
Page 122: Bcc Filler Panel
BCC Filler Panel If a BCC is removed and a new one is not available, the BCC slot must be filled to ensure proper cooling for the disk system. This is done with a BCC filler panel. For removal instructions for the BCC, see page 119. Caution Do not remove the malfunctioning BCC until you have available either a BCC filler panel or a replacement BCC.
Page 123: Power Supply
Power Supply Replace a power supply as soon as possible when troubleshooting indicates a power supply failure (see “Isolating Causes” in Chapter 4). If a power supply fails, the remaining power supply provides proper voltage to the disk system. However, if the remaining power supply fails before the first power supply is replaced, the disk system will turn off.
Page 124: Figure 57 Power Supply Removal And Replacement
Slide the replacement power supply into the empty slot (D in Figure 57). The power supply begins to engage the midplane with 3/8 inch (8mm) still exposed. Rotate the handles back toward the center of the power supply module to draw the power supply the last 3/8 inch into the chassis and firmly seat the power supply on the midplane.
Page 125: Disk System
Disk System Use this procedure if you need to move or remove and replace the disk system in the rack. For example, you must remove the disk system from the rack in order to replace the midplane or power switch assembly. 24 inches of vertical space is required in the rack if these units are to be replaced without removing the disk system from the rack.
Page 126: Figure 58 Disk System Removal And Replacement
Remove screws from the mounting ears (see detail in Figure 58). WARNING An empty storage device weighs approximately 54 pounds (without disk modules installed) (24.5 kg). To avoid personal injury, it is recommended that two people install the storage device in the rack.
Page 127 Insert and tighten the front mounting screws. Reinstall the power supply/fan module(s). Reinstall the disk modules in the slots from which they were removed. Reconnect SCSI cables and power cords. Push the power button in to turn on the disk system. Perform necessary system administration to return file systems to service.
Page 128: Top Cover (Hp-Qualified Only)
Top Cover (HP-Qualified Only) The following procedure is for HP-qualified personnel only. Remove and replace the top cover (not a replaceable part) in order to replace the power switch assembly, light pipes, or the midplane. You will need to turn the power off to perform this procedure. Tools Small flat-blade screwdriver Torx T25 screwdriver...
Page 129: Figure 59 Top Cover Assembly
To reinstall the top cover: Insert the edge of the top cover under the outer sheet metal of the chassis. Slide the cover toward the middle of the chassis, making sure to rotate the top cover down to align with the edges of the chassis. Insert the three Torx T10 screws through the holes as shown in Figure 59.
Page 130: Midplane (Hp-Qualified Only)
Reinstall the power and SCSI cables. Reinstall disks and fillers. See page 110. Midplane (HP-Qualified Only) The midplane board is replaceable by HP-qualified personnel only. Replace the midplane based on troubleshooting results (see “Isolating Causes” in Chapter 4). Disks, BCCs, fans, and power supplies connect to the midplane. The power must be OFF (out) and the top cover removed in order to remove and replace the midplane board.
Page 131 To remove the midplane: Loosen the cam handle locking screws and pull power supplies free of the midplane (see page 123). Loosen the cam handle locking screws and pull the BCCs free of the midplane. Remove the disk modules and fillers from the chassis. Remove the light pipes (see Figure 60 on page 132) from the chassis.
Page 133: Deskside Base/External Covers (Hp-Qualified Only)
Deskside Base/External Covers (HP-Qualified Only) The deskside base and external covers must be removed from the chassis before the top cover, the midplane, the light pipes, or the power switch extender arm can be replaced. Follow the procedures below to remove and replace the deskside conversion kit: Powering Down the Disk System Complete the appropriate system administration tasks for taking this storage device offline for your operating system.
Page 135: Figure 62 Base Removal And Replacement
Rotate the disk system and place it on its top. Remove the four M5 screws from the array chassis using a Torx T25 driver. They are the four screws that are closest to the center of the base. See Figure 62. Removal and Replacement 135...
Page 136: Figure 63 Base Removal From Chassis
Remove the four M5 screws from the cover using a Torx T25 driver. They are the four screws that are closest to the edges of the base. Figure 63. Base Removal from Chassis A base 136 Removal and Replacement...
Page 137: Figure 64 Removal From Cover
Lift the disk system chassis off the alignment pins and out of the cover. Removal and Replacement 137...
Page 138: Reinstalling The Deskside Base And External Covers On The Disk System
Reinstalling the deskside base and external covers on the disk system. Place the deskside external cover on its top, on a sturdy surface. Lift the disk system chassis into the cover, onto the alignment pins. The disk system should be installed into the cover with the power switch down (toward the closed part of the cover).
Page 139: Figure 66 Installing Base To Cover And Chassis
Rotate the disk system and place it on the back end of the disk system. The empty disk module slots should be facing up. Align the end cap tabs into the appropriate slots at the top of the disk system. Rotate the end cap down over the base, aligning the small tabs at the top of the end cap with the end cap slots.
Page 141: Reference
Reference Product Models Two models of the disk system are available: A6490A and A6490AV field-racked (by HP-qualified service engineers) A6490AE empty field rack disk system A6490AD deskside disk system A6490ED empty deskside disk system A6490AZ factory-racked disk system Reference 141...
Page 142: Upgrade Products
Upgrade Products Order the following parts to expand or reconfigure your original purchase: Table 14. Upgrade Products Order No. Description A6537A 18-Gbyte 10K rpm LVD disk module A6538A 36-Gbyte 10K rpm LVD disk module A6539A 73-Gbyte 10K rpm LVD disk module A6540A 18-Gbyte 15K rpm LVD disk module A6541A...
Page 143: Pdu/Pdru Products
PDU/PDRU Products Table 15. PDU/PDRU Products Order No. Description E7676A 19-inch, 100-240 V, 16 Amp, 1 C20 inlet, 10 C13 outlets E7671A 19-inch, 100-240 V, 16 Amp, 1 C20 inlet, 2 C19 & 6 C13 outlets E7674A 19-inch, 100-240 V, 16 Amp, 1 C20 inlet, 1 C19 & 7 C13 outlets E7679A 19-inch, 100-127 V, 16 Amp, 2 C20 inlets, 2 C19 outlets, switch accessory...
Page 144: Replaceable Parts
Replaceable Parts Table 16. Replacement and Exchange Part Numbers Replacement Exchange Part Part Description Number Number 8120-6514 Power cord (North America Only) 5021-1121 Terminator A6490-67001 Front Bezel A6250-67001 A6250-69001 Power supply/Fan module A6490-67005 Midplane Assembly A6491-67001 A6491-69001 Bus Control Card (BCC) A6490-67002 BCC Filler Panel A6198-67002...
Page 145: Specifications
Specifications Dimensions The maximum dimensions of the racked version of the disk system with the power supply handles closed are as follows: Height: 13.0 cm (5.10 in.) Width: 44.8 cm (17.60 in.) Depth: 50.5 cm (19.90 in.) Weight: 27.3 - 36.4 kg (60 - 80 lbs) depending on configuration The maximum dimensions of the deskside version are: Height: 49.1 cm (19.3 in) Width: 31.7 (base): cm (12.5 in)
Page 146: Ac Power Input
Environment The following environmental specifications were type-tested under controlled conditions. Hewlett-Packard maintains an active program of auditing production products to make sure these specifications remain true when products are retested under the same conditions. However, the limits of these specifications do not represent the optimum for long, trouble-free operation and specifically are not recommended for maximum satisfaction.
Page 147: Acoustics
The environmental limits in a nonoperating state (shipping and storage) are wider: Temperature: -40º C to 70º C (-40º F to 158º F) Maximum gradient:24º C per hour (43.2º F per hour) Relative humidity:15% to 90% noncondensing Altitude:4600 m (15,000 ft.) Acoustics Sound power: 6.7 Bels Sound pressure at operator’s position: 51.6 dB(A)
Page 148: Regulatory Statements
The end user of this product should be aware that any changes or modifications made to this equipment without the approval of Hewlett-Packard could result in the product not meeting the Class A limits, in which case the FCC could void the user's authority to operate the equipment.
Page 149: Product Noise Declaration (Germany)
Cher Client, Conformément à la Réglementation Française en vigueur l’installation ou le transfert d’installation, et l’exploitation de cet appareil de classe A, doivent faire l’objet d’une déclaration (en deux exemplaires) simultanément auprès des services suivants: — Comité de Coordination des Télécommunications 20, avenue de Ségur - 75700 PARIS —...
Page 150: Vcci Statement (Japan)
E. VCCI Statement (Japan) Harmonics Conformance (Japan) F. BCIQ EMC Statement (Taiwan) 150 Reference...
Page 151: Declaration Of Conformity
G. Declaration of Conformity Reference 151...
Page 152: Product Web Site
Product Web Site For the most current information about the HP StorageWorks Disk System 2300, visit the support Web site located at http://www.hp.com. Related Documents The following manuals explain how to use the system software interfaces to the StorageWorks Disk System 2300: EMS Hardware Monitors User’s Guide, available at http://www.docs.hp.com/ hpux/systems/ Online Diagnostics (for HP 9000): Support Tools Manager Overview,...
Page 153 index AC power 146 cables acoustics, product 147 See SCSI cables or power Acrobat Reader cables World Wide Web site 90 Cautions Address High switch 85 damage to power switch audio alarm 104 data loss 130 multiple disk systems 70 operating with empty slot description of 19 119, 123...
Page 154 removing 128 user guide 152 event notification 90, 97–99 exchange part numbers 144 DC power 146 Declaration of Conformity 151 definitions 33 dimensions, product 145 troubleshooting 106 disk firmware installing 78 mismatch 104 disk filler 117 obtaining latest release 91 installing 115 troubleshooting 106 removing 115...
Page 155 midplane 130 PDU/PDRU 39 midplane power cable 75 installing 130 power supply/fan module removing 130 model numbers 141 SCSI cable 75 terminator 75 tools required 44 operating systems verifying operation 80 supported 24 IOSCAN order number example 81 BCC 44 troubleshooting NO_HW LVD terminator 44...
Page 156 power switch of 18–23 and PDUs 33 replacement part numbers 144 troubleshooting 104 restoring operation 125 power up the disk system 80 power/standby switch location and function 16 safety certifications 147 product SCSI cable AC power 146 installing 75 acoustics 147 products 142 DC power 146 site preparation 36...
Page 157 turning on the disk system 80 Ultra 3 SCSI definition 34 upgrade products order numbers 142 User Guide order number 44 verify connection to the host 81 voltage, troubleshooting 106 volume groups 111 web site documents 152 weight, product 145...
