InSinkErator Model SS-1000 Specifications

PROJECT:
Heavy-duty disposer designed for continuous operation in restaurants, hotels, hospitals and cafeterias. Food waste including
steak bones is quickly and efficiently removed with this labor-saving, self-cleaning, environmentally sound disposer.

SPECIFICATIONS

• Grind Chamber: Corrosion Resistant Stainless Steel
• Mounting: 3/4" (19.1 mm) rubber mounting above grinding chamber isolates sound and
eliminates vibration. Mounting is enclosed in chrome plated covers for sanitation and appearance.
• Motor: 3 – 10 HP Induction Motor, 1725 RPM, totally enclosed to provide protection against
outside moisture. Controlled power air flow cools motor for efficiency and longer life. Built-in
thermal overload protection.
• Cutting Elements: Stationary and rotating shredding elements made from cast nickel chrome
alloy for long life and corrosion resistance, designed for reverse action grinding.
• Main Bearings: Double-tapered Timken roller bearings provide a shock absorbing cushion.
• Motor Seals: Triple lip seal protects motor from water damage. Secondary spring-loaded oil
seal provides double protection against water and loss of grease.
• Finish: All Stainless Steel and Chrome plated. Paint-free for lasting sanitation.
• Warranty: 1 year full warranty from date of installation.
• A Disposer Package Includes: 1 Mounting/Bowl Assembly, 1 Electrical Control, 1 Syphon
Breaker, 1 Solenoid Valve, and 1 Flow Control Valve. The standard Flow Control Valve will be
sent with the unit unless the optional valve is specified.
MODEL & HORSEPOWER/ELECTRICAL REQUIREMENTS
208-230/460V, 60 Hz, 3 Ph, 6.0/7.4/3.7 amps, UL
208-230/460V, 60 Hz, 3 Ph, 6.0/7.4/3.7 amps, UL, short body
SS-300
208-230/460V, 60 Hz, 3 Ph, 7.0/8.6/4.3 amps, CSA
3 H.P.
208-230/460V, 60 Hz, 3 Ph, 7.0/8.6/3.7 amps, NOM
208-230/460V, 60 Hz, 3 Ph, 8.6/8.8/4.4 amps, UL
SS-500
208-230/460V, 60 Hz, 3 Ph, 8.6/8.4/4.4 amps, UL, short body
5 H.P.
208-230/460V, 60 Hz, 3 Ph, 8.5/11.0/5.5 amps, CSA
SS-750 208-230/460V, 60 Hz, 3 Ph, 9.7/12.4/6.2 amps, UL
208-230/460V, 60 Hz, 3 Ph, 9.7/12.4/6.2 amps, UL, short body
7-1/2 H.P.
SS-1000 208-230/460V, 60 Hz, 3 Ph, 11.0/13.0/6.5 amps, UL
10 H.P. 208-230/460V, 60 Hz, 3 Ph, 11.0/13.0/6.5 amps, UL, short body
NOTE: All amp ratings denote amp draw during a grind load.
ELECTRICAL CONTROLS
AS-101 Control Center
AquaSaver ®
(Auto-Reversing)
4700 21st STREET
RACINE, WI 53406
TEL: 800-845-8345
FAX: 262 554-3620
www.insinkerator.com/foodservice
InSinkErator is a division of Emerson Electric Co.
3-10 H.P. DISPOSER MODELS
CC-101 Control Center
(Auto-Reversing)
415V, 50 Hz, 3 Ph, 4.9 amps
220V, 50 Hz, 3 Ph, 7.2 amps
380V, 50/60 Hz, 3 Ph, 4.1/3.0 amps
230/460V, 50 Hz, 3 Ph, 9.0/4.5 amps
415V, 50 Hz, 3 Ph, 6.0 amps
380V, 50 Hz, 3 Ph, 8.9 amps
208-230/460V, 60 Hz, 3 Ph, 11.7/12.6/6.3 amps, CSA
208-230/460V, 60 Hz, 3 Ph, 13.1/14.0/7.0 amps, CSA
CC-202 Control Center
(Auto-Reversing)
Our products appear on The KCL CADalog
CD-ROM based CAD Foodservice Symbol
Library. More information is available from
Kochman Consultants, Ltd. at www.kclcad.com.
InSinkErator ©2011
ITEM NO.:
Manual Reverse Switch
(Dual Direction)
The Emerson logo is a
trademark and a service mark
of Emerson Electric Co.
Printed in USA Form No. F309-11D-45-02
Manual Switch
(Single Direction)
