Model No. WLTL35530
Serial No.
Serial Number
Decal
QUESTIONS?
If you have questions, or if there
are missing parts, we will guar-
antee complete satisfaction
through direct assistance from
our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
Customer Hot Line will provide
immediate assistance, free of
charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for Weslo Cadence R20 Treadmill
Summary of Contents for Weslo Cadence R20 Treadmill
- Page 1 CUSTOMER HOT LINE: 1-800-999-3756 Mon.–Fri., 6 a.m.–6 p.m. MST CAUTION Visit our website at Read all precautions and instruc- www.weslo.com tions in this manual before using this equipment. Save this manual new products, prizes, for future reference. fitness tips, and much more!
-
Page 2: Table Of Contents
5. Do not operate the treadmill where aerosol page 8. To purchase a surge suppressor, see products are used or where oxygen is being your local WESLO dealer or call 1-800-806- administered. 3651 and order part number 146148. 6. Keep children under the age of 12 and pets 12. - Page 3 35 or persons with pre-existing health problems. Read all instructions before using. WESLO assumes no responsibility for personal injury or property damage sustained by or through the use of this product.
-
Page 4: Before You Begin
Congratulations for selecting the new WESLO ® at 1-800-999-3756, Monday through Friday, 6 a.m. until DENCE R20 treadmill. The CADENCE R20 treadmill 6 p.m. Mountain Time (excluding holidays). To help us combines advanced technology with innovative design assist you, please note the product model number and to help you get the most from your exercise in the con- serial number before calling. -
Page 5: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. - Page 6 3. Three Cage Nuts (35) must be inserted into the lower end of each Upright (62, 76). The Cage Nuts must be inserted from the inside, in the locations shown by the arrows at the right. (Note: The front of each Upright is taller than the back. Do These not insert a Cage Nut into the lower hole in the front of each holes...
- Page 7 6. Place the Console Base (46) on the Right Handrail (47) and the Left Handrail (not shown). Attach the Console Base with four 1 1/4” Screws (105) (only two Screws are shown). Do not tighten the Screws yet. Insert the Wire Harness (21) through the two indicated plastic ties on the Console Base (46).
-
Page 8: Operation And Adjustment
Adapter the right). To purchase a surge suppressor, see Surge Suppressor your local WESLO dealer or call toll-free 1-800-806- 3651 and order part number 146148. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge sup- pressor (TVSS). - Page 9 CONSOLE DIAGRAM Note: If there is a thin sheet of plastic on the console, remove it. Clip Insert the key fully into the console. After a moment, CAUTION: the displays will light. Test the clip by carefully tak- Before operating the ing a few steps backward until the key is pulled console, read the following precautions.
- Page 10 To stop the walking belt, press the Stop button. will appear in the Calories/Fat Calories/Pulse dis- The Time display will begin to flash. play. Press the Speed button to change the unit of measurement. When the desired unit of mea- Note: During the first few minutes that the treadmill surement is selected, remove the key and then is used, inspect the alignment of the walking belt...
- Page 11 THE INFORMATION MODE The Time display will show the total number of hours that the The console features an information mode that keeps treadmill has been used. track of the total number of hours that the treadmill has been operated and the total number of miles that the walking belt has moved.
-
Page 12: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, unplug the power cord. CAUTION: You must be able to safely lift 45 pounds (20 kg) in order to raise, lower, or move the treadmill. 1. -
Page 13: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll- free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). PROBLEM: The power does not turn on SOLUTION: a. - Page 14 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that meets all of the specifications described on page 8. b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- 2”–3”...
-
Page 15: Conditioning Guidelines
CONDITIONING GUIDELINES ergy. Only after the first few minutes does your body WARNING: begin to use stored fat calories for energy. If your goal Before beginning this is to burn fat, adjust the speed and incline of the tread- or any exercise program, consult your physi- mill until your heart rate is near the lowest number in cian. - Page 16 PART LIST—Model No. WLTL35530 R1203A Qty. Description Qty. Description Left Handrail Frame Pivot Bolt Key/Clip Latch Decal Incline Leg Pivot Bolt Motor Belly Pan Cover Cable Tie Clamp Left Foot Rail Right Upright Lift Motor Releasable Tie Rear Roller Choke 1”...
- Page 17 PART IDENTIFICATION CHART Remove this chart and use it to identify small parts during assembly. Save this chart and the EXPLODED DRAWING/PART LIST for future reference. 3/4” Screw (13)–6 Crossbar Screw 1 1/4” Screw (105)–4 (53)–2 Silver Ground 1/2” Silver Screw (97)–2 3/4”...
- Page 18 EXPLODED DRAWING—Model No. WLTL35530 R1203A...
-
Page 19: Ordering Replacement Parts
• The KEY NUMBER and DESCRIPTION of the desired part(s) (see the PART LIST and the EXPLODED DRAW- ING in the center of this manual) WESLO is a registered trademark of ICON Health & Fitness, Inc. LIMITED WARRANTY ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase.
