Manual
Model No. WATL13906.0
Serial No.
Serial Number
Decal
QUESTIONS?
If you have questions, or if any
parts are missing or damaged,
PLEASE CONTACT OUR CUS-
TOMER SERVICE DEPARTMENT
DIRECTLY.
Call toll-free:
800-830-7240
E-mail:
service@goodfamily.cc
Goodfamily's Web site:
www.goodfamily.cc
ICON's Web site:
www.iconfitness.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Goodfamily is an authorized dealer of this treadmill in the
territory of mainland China. This treadmill is designed and
manufactured by ICON Health & Fitness, Inc.
Advertisement
Related Manuals for Weslo Cadence A50 Treadmill
Summary of Contents for Weslo Cadence A50 Treadmill
- Page 1 Model No. WATL13906.0 USER'S MANUAL Serial No. Serial Number Decal QUESTIONS? If you have questions, or if any parts are missing or damaged, PLEASE CONTACT OUR CUS- TOMER SERVICE DEPARTMENT DIRECTLY. Call toll-free: 800-830-7240 E-mail: service@goodfamily.cc Goodfamily’s Web site: www.goodfamily.cc ICON’s Web site: www.iconfitness.com CAUTION...
-
Page 2: Table Of Contents
ORDERING REPLACEMENT PARTS ..........Back Cover Note: A PART IDENTIFICATION CHART, an EXPLODED DRAWING, and a PART LIST are attached in the center of this manual. WESLO is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure 11. If an extension cord is needed, use only a 3- that all users of this treadmill are adequately conductor, 1mm (14-gauge) cord that is no... - Page 4 21. Do not change the incline of the treadmill by tenance and adjustment procedures de- placing objects under the treadmill. scribed in this manual. Never remove the motor hood unless instructed to do so by an 22. Inspect and properly tighten all parts of the authorized service representative.
-
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the new WESLO ® CADENCE ing this manual, please see the front cover of this man- S5 treadmill. The CADENCE S5 treadmill combines ual. To help us assist you, please note the product advanced technology with innovative design to make model number and serial number before contacting us. -
Page 6: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials; do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. - Page 7 3. With the help of a second person, raise the Uprights (53, 54) so the Base (52) is flat on the floor as shown. Hole Next, position the front of the treadmill Frame (51) between the Uprights. See the inset drawing. Locate the wire inside of the lower end of the Right Upright (54).
- Page 8 5. Place the Left Handrail (56) on the Console Assembly (91). Attach the end of the ground wire from the Console Assembly to the indicated small hole in the Left Handrail with the Silver Ground Screw (8). Attach the Left Handrail (56) to the Console Assembly (91) with two Console Screws (4), a Crossbar Screw (5), Ground Wire Small...
- Page 9 8. Set the Console Assembly (91) on the Right Upright (54) and the Left Upright (not shown). Next, start four Handrail Bolts (3) with four Handrail Washers (13) and four Handrail Star Washers (10) (only two of each are shown) Slot into the Right Upright and the Left Upright.
-
Page 10: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT Your treadmill features a walking belt coated with high-performance lubricant. IMPORTANT: Never apply sili- cone spray or other substances to the walking belt or the walking platform. Such substances will deterio- rate the walking belt and cause excessive wear. HOW TO PLUG IN THE POWER CORD This product must be earthed. - Page 11 CONSOLE DIAGRAM Clip FEATURES OF THE CONSOLE HOW TO TURN ON THE POWER The treadmill console offers a selection of features Plug in the power cord (see designed to make your workouts more effective. page 10). Next, locate the on/off switch on the treadmill Position While the manual mode of the console is selected, the frame near the right upright.
- Page 12 The lower left HOW TO USE THE MANUAL MODE display—As you exer- cise, the lower left dis- play can show the Insert the key into the console. elapsed time and the distance that you have See HOW TO TURN ON THE POWER on page walked or run.
- Page 13 Each program consists of 30 one-minute periods. Measure your heart rate if desired. One speed setting is programmed for each period. Note: The same speed setting may be pro- Before using the hand- grammed for two or more consecutive periods. grip pulse sensor, re- The profiles on the left side of the Program Select move the sheets of...
- Page 14 HOW TO CHANGE THE INCLINE OF THE TREADMILL To change the incline, first remove the incline pin from one of the incline legs. Adjust the incline leg to the de- To vary the intensity of your exercise, you can change sired position, and then fully reinsert the incline pin.
-
Page 15: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45 lbs.) to raise, lower, or move the treadmill. 1. Hold the metal frame firmly in the location shown by the arrow at the right. - Page 16 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Next, lower the frame until it is past the latch pin.
-
Page 17: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a. - Page 18 PROBLEM: The walking belt slows when walked on SOLUTION: a. If an extension cord is needed, use only a 3-conductor, 1mm (14-gauge) cord that is no longer than 1.5 m (5 ft.). b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- 5–7cm come damaged.
-
Page 19: Conditioning Guidelines
CONDITIONING GUIDELINES is to burn fat, adjust the speed and incline of the tread- WARNING: mill until your heart rate is near the lowest number in Before beginning this your training zone. or any exercise program, consult your physi- cian. This is especially important for individu- For maximum fat burning, adjust the speed and incline als over the age of 35 or individuals with pre- of the treadmill until your heart rate is near the middle... - Page 20 PART LIST—Model No. WATL13906.0 R0606A No. Qty. Description No. Qty. Description No. Qty. Description Frame Pivot Bolt Electronics Star Tie Holder Upright Bolt Washer Reed Switch Clip Handrail Bolt Incline Leg Washer Belly Pan Grommet Console Screw Motor Tension Nut Grommet Crossbar Screw Frame Pivot Nut...
- Page 21 Handrail Washer (11)–2 4” Bolt (120)–2 PART IDENTIFICATION CHART Remove this chart and use it to identify small parts during assembly. Save this chart and the EXPLODED DRAWING/PART LIST for future reference. Console Silver Ground Crossbar Latch/Console Crossbar Star Screw (4)–4 Screw (5)–2 Screw (8)–1 Back Screw...
- Page 22 EXPLODED DRAWING—Model No. WATL13906.0 R0606A...
-
Page 23: Ordering Replacement Parts
0951-6719831 When ordering parts, please be prepared to provide the following information: • the MODEL NUMBER of the product (WATL13906.0) • the NAME of the product (WESLO ® CADENCE S5 treadmill) • the SERIAL NUMBER of the product (see the front cover of this manual) •...
