Alpine MRV-1005 Owner's Manual

From MRV-1005 etc, hay 4 modelos partes que faltan from W82-O 13-11-96
MRV-1505/MRV-1005/
MRV-T505
2 Channel Power Amplifier
• OWNER'S MANUAL
Please read this manual to maximize your
enjoyment of the outstanding performance and
feature capabilities of the equipment, then retain
the manual for future reference.
• MODE D'EMPLOI
Veuillez lire ce mode d'emploi pour tirer
pleinement profit des excellentes performances et
fonctions de cet appareil, et conservez-le pour
toute référence future.
• MANUAL DE OPERACION
Lea este manual, por favor, para disfrutar al
máximo de las excepcionales prestaciones y
posibilidades funcionales que ofrece el equipo,
luego guarde el manual para usarlo como
referencia en el futuro.
(MRV-1505)
ALPINE ELECTRONICS, INC.
Tokyo office: 1-1-8 Nishi Gotanda,
Shinagawa-ku, Tokyo 141, Japan
Tel.: (03) 3494-1101
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
California 90501, U.S.A.
Tel.: 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF CANADA, INC.
Suite 203, 7300 Warden Ave. Markham,
Ontario L3R 9Z6, Canada
Tel.: 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
6-8 Fiveways Boulevarde Keysborough,
Victoria 3173, Australia
Tel.: (03) 9769-0000
ALPINE ELECTRONICS GmbH
Brandenburger Strasse 2-6 D-40880 Ratingen,
ALPINE ITALIA S.p.A.
Via C. Colombo 8, 20090 Trezzano Sul
Tel.: 02-48 40 16 24
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B 338 101 280)
98, Rue De La Belle Etoile, Z.I. Paris Nord II
B.P. 50016 F-95945, Roissy,
Charles de Gaulle Cedex, France
Tel.: 01-48 63 89 89
ALPINE ELECTRONICS OF U. K., LTD.
13 Tanners Drive, Blakelands,
Milton Keynes MK14 5BU, U.K.
Tel.: 01908-61 15 56
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal De Gamarra 36, Pabellón 32
01013 Vitoria (Alava) - Apdo. 133, Spain
Designed by ALPINE Japan
Printed in Japan (S)
Sankei Kikaku Co., Ltd.
1-13-38, Hinodai,
Hino, Tokyo, Japan
2/1 CHANNEL
POWER AMPLIFIER 0° 180° 1(MONO) ST 1+2 OFF HP LP NOM 4V OFF ON OFF ON
MRV-1505 PHASE INPUT MODE FILTER INPUT LEVEL PARAME EQ LOW IMPEDANCE
R
Germany
Tel.: 02102-45 50
Naviglio MI, Italy
Tel.: 34-45-283588
68P90664W91-B
Please read this OWNER'S MANUAL thoroughly to familiarize yourself with each control and function. We at
R
ALPINE hope that your new MRV-1505/MRV-1005/MRV-T505 will give you many years of listening enjoyment.
In case of problems when installing your MRV-1505/MRV-1005/MRV-T505, please contact your authorized
ALPINE dealer.
CAUTION: These controls are for tuning your system. Please consult your authorized Dealer for adjust-
ment.
• Perform the installation at a location that is level. Make sure the parking brake is on and the ignition
is OFF.
• Always disconnect the cable from the (–) negative pole of the battery before connecting or discon-
necting the MRV-1505/MRV-1005/MRV-T505. This will prevent the possibility of short circuits.
• When replacing a blown fuse make sure to replace it with one of the same value.
• Be sure to connect the color coded leads according to the diagram. Incorrect connections may
cause the unit to malfunction or damage to the vehicle's electrical system.
• Be sure to connect the speaker (–) leads to the speaker (–) terminal. Never connect left and right
channel speaker cables to each other or to the vehicle body.
• This unit is designed for 12 VDC, negative ground systems. Make sure that your vehicle has this
type of electrical system before connecting the power cable.
• When making connections to the car's electrical system, be aware of the factory installed compo-
nents (e.g. on-board computer). Do not tap into these leads to provide power for this unit. When
connecting the MRV-1505/MRV-1005/MRV-T505 to the fuse box, make sure the fuse for the intended
circuit of the MRV-1505/MRV-1005/MRV-T505 has the appropriate amperage. Failure to do so may
result in damage to the unit and/or the vehicle. When in doubt, consult your ALPINE dealer.
• The MRV-1505/MRV-1005/MRV-T505 uses female RCA-type jacks for connection to other units (e.g.
amplifier) having RCA connectors. You may need an adaptor to connect other units. If so, please
contact your authorized ALPINE dealer for assistance.
• Due to the high power output of the MRV-1505/MRV-1005/MRV-T505, it is important that all connec-
tions are clean and well secured, or damage could result.
• When installation and connections are completed, check the followings: a) Connections are proper.
b) Operation of brake lamps, horn etc. are proper with the ignition ON. c) Operation of audio units is
proper with the switch ON.
SERVICE CARE
For European Customers
Should you have any questions about warranty,
please consult your store of purchase.
SPECIFICATIONS
Power Output: RMS Continuous Power (at 12.0V, 20 Hz to 20 kHz)
Per channel into 4 ohms
Per channel into 2 ohms
Bridged into 4 ohms
Power Output: RMS Continuous Power (at 14.4V, 20 Hz to 20 kHz)
Per channel into 4 ohms
Per channel into 2 ohms
Bridged into 4 ohms
EIAJ Max. Power (at 14.4V)
Per channel into 4 ohms
Bridged into 4 ohms
Frequency Response
Signal-to-Noise Ratio
Slew factor
Input Sensitivity (for rated
power output)
Input Impedance
Speaker Impedance
Active Dividing Network
Frequency and Slope
Power Requirement
Dimensions (W x H x D)
MRV-1505 ..................................................................... 240mm x 53mm x 500mm (9-7/16" x 2-1/16" x 19-5/8")
MRV-1005 ........................................................................... 240mm x 53mm x 330mm (9-7/16" x 2-1/16" x 13")
MRV-T505 ................................................................... 240mm x 53mm x 250mm (9-7/16" x 2-1/16" x 9-13/16")
Weight
MRV-1505 ........................................................................................................................... 5.8 kg (12 lbs. 12 oz)
MRV-1005 ............................................................................................................................. 4.4 kg (9 lbs. 11 oz)
MRV-T505 ............................................................................................................................. 3.1 kg (6 lbs. 13 oz)
NOTE:
For product improvement, specifications and design are subject to change without notice.
ENGLISH
PRECAUTIONS
For Customers in other Countries
IMPORTANT NOTICE
Customers who purchase the product with which
this notice is packaged, and who make this
purchase in countries other than the United
States of America and Canada, please contact
your dealer for information regarding warranty
coverage.
MRV-1505 MRV-1005
150W 100W
0.04% THD
300W 200W
0.3% THD
600W 400W
0.3% THD
225W 150W
0.04% THD
450W 300W
0.3% THD
900W 600W
0.3% THD
450W 400W
1500W 1000W
8 Hz to 60 kHz
(+0, –1 dB)
105 dBA 105 dBA
(referenced to rated power)
Greater than 5
200mV to 4.0V (1.0V at center detent)
10k ohms <
4 or 2 ohms (Stereo), 4 ohms (Bridged)
50 to 200 Hz, 12 dB per octave
11 – 16VDC Negative Ground
MRV-T505
50W
100W
200W
75W
150W
300W
200W
500W
10 Hz to 50 kHz
100 dBA
