Ashly P70-400 Owner's Manual

70 volt power amplifiers

Advertisement

Quick Links

SPECIFICATIONS
P70-400
Output Power
EIA Spec.
(±1dB <1% THD @ 1KHz)
Both Channels Driven
Dual
200W @ 70V
Bridged-Mono
400W @ 140V
FTC Spec.
(<.1%THD 20Hz-20KHz)
Both Channels Driven
Dual
160W @ 70V
Bridge-Mono
320W @ 140V
Total Harmonic
Distortion
(at rated power)
<.05%
20Hz-1KHz
.< .1%
20KHz
IM Distortion
< .05%
(at rated power)
>500 20Hz-1KHz
Damping Factor (25Ω)
100KHz
Bandwidth (-3dB)
>20V/µS
Slew Rate
+0/-.4dB
Frequency Response
(20Hz-20KHz)
1.77V
Full Power Input Sensitivity
20KΩ Balanced 20KΩ Balanced
Input Impedance
>105dB below full output
Hum and Noise
(20Hz-20KHz unweighted)
Forced Air
Cooling
790W Max, 75W Idle
Power Requirement
120VAC 50-60Hz 120VAC 50-60Hz
(240V available)
19"Wx3.5"Hx17.8"D
Size
44 lbs.
Shipping Weight
Ashly P70 Owners Manual
P70-800
400W @ 70V
800W @ 140V
320W @ 70V
640W @ 140V
<.05%
< .1%
< .05%
>500 20Hz-1KHz
100KHz
>20V/µS
+0/-.4dB
1.77V
>105dB below full output
Forced Air
1580W Max, 150W Idle
(240V available)
19"Wx3.5"Hx17.8"D
60 lbs.
Page
12
ASHLY
70 VOLT
POWER AMPLIFIERS
Models P70-400, P70-800
TABLE OF CONTENTS
Introduction ..................................................................... 1
Standard Connections and Controls ................................ 2
Typical Applications ....................................................... 5
Input Options ................................................................... 7
Transformer Input Option ................................................ 7
Limiter Input Option ........................................................ 7
Crossover Input Option ................................................... 8
Mic/Line Mixer Input Option ......................................... 8
Design Theory ................................................................. 10
Dimensional Diagrams ..................................................... 11
Specifications .................................................................. 12
INTRODUCTION . . . Why MOSFETS?
The Ashly P70 series MOSFET amplifiers combine the sonic excellence of
a high-end stereo amp with the ruggedness and stamina necessary in commercial
audio. The P70 series amps use power MOSFETs (metal-oxide-semiconductor,
field-effect transistors) for their superior audio fidelity and unmatched reliability
as proven in Ashly amps for over ten years.
MOSFET output devices are used in the P70 series amps because of their
superior performance characteristics over bipolar power transistors which are
normally used in conventional power amp designs. The power MOSFET is
inherently more self-regulating and does not exhibit the failure modes that bipolar
transistors are susceptible to. MOSFETS do not require any thermal runaway
compensation circuitry, thus making the design simpler and more reliable. MOS-
FETS do not exhibit secondary breakdown (an instantaneous failure in bipolar
transistors when their collector current exceeds a safe level, even at voltages much
lower than their maximum rating). The MOSFET will even withstand a dead shorted
output resulting in very high drain current without any protection circuitry for a very
short time.
Ashly P70 Owners Manual
Page
1

Advertisement

loading

Summary of Contents for Ashly P70-400

  • Page 1 20KΩ Balanced 20KΩ Balanced Input Impedance >105dB below full output >105dB below full output The Ashly P70 series MOSFET amplifiers combine the sonic excellence of Hum and Noise a high-end stereo amp with the ruggedness and stamina necessary in commercial (20Hz-20KHz unweighted)
  • Page 2 UNPACKING As a part of our system of quality control, every Ashly product is carefully inspected before leaving the factory to ensure flawless appearance. After unpack- ing, please inspect for any physical damage. Save the shipping carton and all...
  • Page 3: Design Theory

    DESIGN THEORY Ashly P70 series amplifiers use a direct-coupled output stage with totally discrete high-voltage, wide bandwidth electronics. A modulated power supply improves output device efficiency, allowing more power with less heat dissipation. The input section is a complimentary Darlington differential amplifier stage for high common-mode rejection, low noise and low distortion.
  • Page 4: Normal/Bridging Switch

    Figure 9: Mic/Line Mixer Input Option OR CONNECT EITHER OUTPUT TERMINAL TO COMMON. To prevent electric shock, always replace the barrier strip protective cover before applying power to the amplifier. Ashly P70 Owners Manual Ashly P70 Owners Manual Page Page 9...
  • Page 5: Typical Applications

    MIC/LINE MIXER INPUT OPTION The MM-6 mixer input option provides four high-impedance line inputs and figure 3: P70-400 Front Panel two balanced low-impedance microphone inputs, each with its own level control. A switchable 200 Hz high-pass filter is provided on the mic inputs to reduce unwanted low frequency noise.
  • Page 6: Input Options

    Both channels are then controlled by the channel 1 level transformers for signal isolation. Ashly P70 series amplifiers as well as all other control. Both outputs will be identical and can be connected to separate speaker Ashly amps (excluding the single rack space SRA-120) will accept Ashly input lines.
