ALPINE ELECTRONICS, INC.
Tokyo office: 1-1-8 Nishi Gotanda,
Shinagawa-ku, Tokyo 141-8501, Japan
Tel.: (03) 3494-1101
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
California 90501, U.S.A.
Tel.: 1-800-ALPINE-1 (1-800-257-4631)
1-888-NAV-HELP (1-888-628-4357)
ALPINE ELECTRONICS OF CANADA, INC.
Suite 203, 7300 Warden Ave. Markham,
Ontario L3R 9Z6, Canada
Tel.: 1-800-ALPINE-1 (1-800-257-4631)
1-888-NAV-HELP (1-888-628-4357)
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
6-8 Fiveways Boulevarde Keysborough,
Victoria 3173, Australia
Tel.: (03) 9769-0000
ALPINE ELECTRONICS GmbH
40878 Ratingen, Germany
ALPINE ITALIA S.p.A.
Via C. Colombo 8, 20090 Trezzano Sul
Tel.: 02-48 40 16 24
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B 338 101 280)
98, Rue De La Belle Etoile, Z.I. Paris Nord Il
B.P. 50016 F-95945, Roissy,
Charles De Gaulle Cedex, France
Tel.: 01-48 63 89 89
ALPINE ELECTRONICS OF U.K., LTD.
13 Tanners Drive, Blakelands,
Milton Keynes MK14 5BU, U.K.
Tel.: 01908-61 15 56
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal De Gamarra 36, Pabellón 32
01013 Vitoria (Alava)-Apdo. 133, Spain
Yamagata Printing
Co., Ltd.
Designed by ALPINE Japan
2-6-34, Takashima,
Printed in Japan (Y)
Nishi-ku, Yokohama,
Kanagawa, Japan
R
Kreuzerkamp 7-11
Tel.: 02102-45 50
Naviglio MI, Italy
Tel.: 34-45-283588
68P10924Y94-A
1 DIN Voice Guidance Navigation System
NVE-N055PS
OWNER'S MANUAL
Please read before using this equipment.
BEDIENUNGSANLEITUNG
Bitte lesen Sie diese
Bedienungsanleitung vor Gebrauch
Ihres Navigationssytems durch.
MODE D'EMPLOI
Veuillez lire ce mode d'emploi avant la
mise en service de l'appareil.
ISTRUZIONI PER L'USO
Leggere questo manuale prima di
usare l'apparecchio.
GEBRUIKSAANWIJZING
Lees de gebruiksaanwijzing zorgvuldig
door alvorens u het apparaat in gebruik
neemt.
OPEN
INTELLIGENT
HIGH SPEED
PROCESSOR
VERSION UP/ADVANCED ROUTE GUIDANCE
POWER
ACCESS
CAR NAVIGATION SYSTEM NVE-N055PS
R
Auto Route Calculation
Destination Search
Real Time Voice Guidance
Automatische Streckenermittlung
Zielort-Suche
Echtzeit-Sprachführung
Calcul automatique d'itinéraire
Recherche de destination
Guide vocal en temps réel
Calcolo automatico del percorso
Ricerca della destinazione
Guida a voce in tempo reale
Automatisch uitstippelen van de route
Zoeken van uw bestemming
Gesproken instructies terwijl u rijdt

Advertisement

Table of Contents
loading

Related Manuals for Alpine NVE-N055PS

Summary of Contents for Alpine NVE-N055PS

  • Page 1 Zielort-Suche Tel.: 1-800-ALPINE-1 (1-800-257-4631) Bedienungsanleitung vor Gebrauch Echtzeit-Sprachführung 1-888-NAV-HELP (1-888-628-4357) Ihres Navigationssytems durch. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. 6-8 Fiveways Boulevarde Keysborough, MODE D'EMPLOI Calcul automatique d'itinéraire Victoria 3173, Australia Recherche de destination Veuillez lire ce mode d'emploi avant la Tel.: (03) 9769-0000...
  • Page 2 Precautions PRECAUTIONS IMPORTANT INFORMATION, PLEASE READ CAREFULLY BE- FORE USING THIS PRODUCT. This product is intended to safely provide turn by turn instruction to get you to a desired destination. Please read the following precautions to ensure that you use this navigation system correctly.
  • Page 3 There may be situations where the navigation system may display the vehicle’s location erroneously. Use your own driving judgment in this situ- ation, taking into account current driving conditions. Please be aware that in this situation, the navigation system should correct the vehicle’s posi- tion automatically;...

  • Page 4: Point To Observe For Safe Usage

    Points to Observe for Safe Usage a Read this manual carefully before starting operation and use this system safely. Alpine cannot be responsible for problems resulting from failure to observe the instructions in this manual. a This manual uses various pictorial displays to show how to use this product safely and to alert you to potential dangers resulting from improper connections and operation.
  • Page 5 Warning DO NOT DISASSEMBLE OR ALTER Attempts to disassemble or alter may lead to accident, fire or electric shock. KEEP SMALL ARTICLES OUT OF THE REACH OF CHILDREN Store small articles (batteries, screws, etc.) in places not accessible to children. If swallowed, consult a physician immediately.
  • Page 6 Precautions Caution COMPLYING WITH THE CURRENT TRAFFIC CONDITIONS WHILE DRIVING When using the navigation system, always comply with local traffic regulations. DO NOT USE THIS EQUIPMENT OUTSIDE THE VEHICLE Do not use the equipment for purposes other than those listed for a vehicle. Failure to do so may result in an electric shock or an injury.

  • Page 7: Table Of Contents

    Contents Precautions 4 ..........Point to Observe for Safe Usage 5 ..................Warning 6 ..................Caution Preface 8 ..............Navigation systems Names of the Parts and Their Functions 10 ............... Remote control and display Before Using This System 12 ................... Main unit 13 ........
  • Page 8 Preface Preface Navigation systems This navigation system uses three different sensing devices to determine the present location and to track the progress of the vehicle. These three devices are: a GPS (Global Positioning System) receiver which receives digital signals from the GPS satellites to determine the current position of the vehicle, a gyroscope which determines which direction the vehicle turns, and a speedometer pulse sensor which determine how far the vehicle has travelled.
  • Page 9 Locations where GPS signals are received easily The optimum locations for receiving GPS signals are locations that command a good view where there are no tall buildings, trees, or other objects to obstruct the signals. Locations where GPS signals cannot be received In the following locations or conditions GPS signals cannot be received.

  • Page 10: Warning

    Names of the Parts and Their Functions Names of the Parts and Their Functions Remote control and display Operation varies depending upon the disc version in use. For details, refer to the manual for the CD ROM. Remote control transmitter Reticule icon This section transmits the remote This icon automatically appears...
  • Page 11 Transmitting indicator Blinks while the remote control signals are transmitted. Joystick Selects items from menus and moves the map in eight directions. GPS mark ENTER button • Red ..calculating position Selects a highlighted item in • Blue ..two-dimensional the menu when the button is position calculation pressed.

  • Page 12: Before Using This System

    Before using this system Before Using This System Main unit Power indicator Lights up when the power is on for the main unit. a Keep the sliding door closed except when changing the disc. a Before inserting or removing a disc, always turn the ignition key to the ACC or ON position.

  • Page 13: Precautions For The Remote Control

    Precautions for the remote control a This device is lightweight and compact. Do not drop it or bump it. Do not put it in your trousers pocket. Doing so could break it, speed up battery wear, or cause malfunction. a To clean this device, wipe it off with a dry cloth. (If it is extremely dirty, wipe it off with a Tips damp cloth that has been carefully wrung out.) Never use benzene, paint thinner or harsh chemicals.

  • Page 14: Switching The Display On/Off

    If the disc cannot be read, the "CD ROM unreadable. Please check CD ROM" message is displayed. Try reloading the disk and if the problem cannot be cured, return to an authorized Alpine dealer. Tips a If the monitor is kept on with the engine off for an extended period of time, the vehicle’s battery may discharge.

  • Page 15: Reference

    If you encounter a problem, please review the items in the following checklist. This guide will help you isolate the problem if the unit is at fault. Otherwise, make sure the rest of your system is properly connected or consult your authorized Alpine dealer. Symptom...

  • Page 16: If This Message Appears

    Reference If this message appears Various messages are displayed on the screen during operation. In addition to the messages telling you the current status or providing guidance for the next operation, there are also the following error messages. If one of these error messages is displayed, carefully follow the instructions in the solution column.

  • Page 17: Specifications

    Specifications Power requirement 14.4 VDC (11 – 16 V allowable) negative ground Operating temperature (main unit) 0°C to +50°C Operating temperature range (antenna) –30°C to +75°C Antenna type Micro-strip planar antenna Reception frequency 1575.42±1 MHz Reception sensitivity –130 dB max. Reception method Parallel 8 channels External dimensions...
  • Page 18 DIGITAL INFORMATION MAP/CARTE ROUTIERE SUR CD ROM/MAPA DE INFORMACIÓN DIGITAL DIGITALE STRASSENKARTE/MAPPA AD INFORMAZIONI/DIGITALE WEGENKAART SMART MAP PRO Prog. Ver. 4.02 NVE-N055PS/NVE-N055PV SUPPLEMENTARY OWNER’S MANUAL English Please read before using this disc. SUPPLEMENT AU MODE D’EMPLOI Français Veuillez lire avant d’utiliser ce disque.

  • Page 19: User Agreement

    • The right to use the Disk and Database shall expire either when the user destroys this software, or when any of the terms for use is violated and Aisin AW, Alpine and/or Nav Tech exercises the option to revoke the license to use this software.
  • Page 20 • The right to use the Disk and Database shall expire either when the user destroys this software, or when any of the terms for use is violated and Aisin AW, Alpine and/or TELE ATLAS exercises the option to revoke the license to use this soft- ware.
  • Page 21 • Operating-System Programme Rewriting a) To use the new-version of the map disc: Just insert the new-version of the map disc into your navigation system NVE-N055PS or NVE-N055PV. The system will automatically rewrite its operating-system programme and read the new-version of the map disc.
  • Page 23 ALPINE ELECTRONICS OF CANADA, INC. 7300 Warden Ave., Suite 203, Markham, Ontario L3R 9Z6, Canada Tel.: 1-800-ALPINE-1 (1-800-257-4631) 1-888-NAV-HELP (1-888-628-4357) ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. 6-8 Fiveways Boulevarde Keysborough, Victoria 3173, Australia Tel.: (03) 9769-0000 ALPINE ELECTRONICS GmbH Kreuzerkamp 7, 40878 Ratingen, Germany Tel.: 02102-45 50...
