- Page 1 AUTOMOBILE UNIQUEMENT/PARA USO EN AUTOMÓVILES/SOLO PER L'UTILIZZO IN AUTOMOBILE/ENDAST FÖR BILBRUK/ALLEEN VOOR GEBRUIK IN DE AUTO/ТОЛЬКО ДЛЯ ИСПОЛЬЗОВАНИЯ В АВТОМОБИЛЯХ/KUN TIL BRUG I BILEN Advanced Navi Station INE-S900R QUICK REFERENCE GUIDE Kurzanleitung GUIDE DE RÉFÉRENCE RAPIDE GUÍA DE REFERENCIA RÁPIDA...
-
Page 2: Table Of Contents
CD-ROM. (As it is data CD, the CD cannot be used for playing back music and images on the player.) If required, an ALPINE dealer will readily provide you with a print out of the Owner’s Manual contained in the CD-ROM. -
Page 3: Warning
Failure to do so may cause personal injury or damage to the DO NOT DISASSEMBLE OR ALTER. product. Return it to your authorized Alpine dealer or the nearest Doing so may result in an accident, fi re or electric shock. -
Page 4: Basic Operation
Owner’s manual Touch operation, Location of Controls, Turning Power On or Off Basic Operation Touch operation You can operate the system by using the touch panel on the screen. Common touch switches : Returns to the previous screen. Depending on the function, this switch may cancel operations performed on the screen. -
Page 5: Menu Screen Operation
Owner’s manual Changing between the NAVIGATION menu and the AUDIO/VISUAL menu Menu screen Operation Pressing the <MENU> button displays the Menu screen. You can perform various operations from this screen, such as for navigating a destination search, displaying the AUDIO/VISUAL mode main menu screen, or setting up the system. -
Page 6: How To View A Navigation Screen
Owner’s manual How to View a Navigation Screen, Guidance Display How to View a Navigation Screen Current Vehicle Position Map Next street name display Maneuver arrow guidance Window display For simplifi ed operations in the Audio/Visual mode. Changes map scale The Resize switch Changes the Window Compass Icon... -
Page 7: Find A Destination And Start Route Guidance
Owner’s manual Displaying the Destination Menu Screen, Finding by Address Find a Destination and Start Route Guidance The following operation is an example that shows how to search the address and start route guidance. Touch [ ] on the Map screen. Touch the desired country (area) to select, and then touch [OK]. -
Page 8: Tmc Operation
Activation is performed, and the system will be required for V-Trafi c (France) and RTL returns to the previous screen. (Italy). Visit the Alpine Website (http://www.alpine- TMC Information display europe.com/) and select your country. On the website, select “Support” and then follow the TMC event icon map display instructions to complete the registration. -
Page 9: Radio Operation
Owner’s manual Radio, RDS Operation Radio Operation Programme type display Changing to next station in the PTY Band display Changing to Radio Text mode Frequency/station name display Window display Displays Select PTY For displays in Navigation screen mode. Preset switch Displays the preset stations with a short touch. -
Page 10: Ipod/Iphone Operation (Optional
Owner’s manual iPod/iPhone (Optional) iPod/iPhone Operation (Optional) An iPod/iPhone can be connected to this unit by using the cable (KCU-451iV) (sold separately). You can connect a video-capable iPod to enjoy not only Music but also Video fi les. iPod/iPhone information display Artwork display Window display... -
Page 11: Hands-Free Phone Control
Hands-Free Phone Control Hands-Free Phone Control Hands-free calls are possible when using an HFP (Hands-Free Profi le) compatible mobile phone with the INE-S900R. How to connect to a BLUETOOTH The system shows the product name and device passcode, and waits for the mobile compatible device (Pairing) phone to connect to the system. -
Page 12: Installation
(e.g. on-board computer). Do not location and mount the GPS Antenna. tap into these leads to provide power for this unit. When connecting the INE-S900R to the fuse box, make sure the fuse for the intended circuit GPS Antenna of the INE-S900R has the appropriate amperage. - Page 13 Mounting the Microphone. When your vehicle has the Bracket, mount the long hex bolt onto the Microphone rear panel of the INE-S900R and put the Rubber Cap on the hex bolt. If your vehicle does not have the Cable clamp...
-
Page 14: Connections
Owner’s manual Connections Connections Connections 1/2 (Orange/White) REVERS To plus side of the back lamp signal lead of the car (Yellow/Blue) PARKING BRAKE To the parking brake signal lead SPEED SENSOR (Green/White) To the vehicle speed pulse line ILLM (Orange) To the instrument cluster illumination lead (Red) - Page 15 Connections 2/2 (Yellow) To Video Input terminal AUX OUTPUT (Red) To Audio Input terminals (R, L) (White) (Yellow) To Video Output terminal AUX INPUT (Red) To Audio Output terminals (R, L) (White) RCA Extension Cable (Sold separately) REAR OUT Rear Left Amplifi...
-
Page 16: Specifi Cations
Owner’s manual Specifi cations Specifi cations NAVIGATION SECTION Wow & Flutter (% WRMS) Below measurable limits Total Harmonic Distortion 0.02% (at 1 kHz) Reception frequency 1575.42 ±1 MHz Dynamic Range 95 dB (at 1 kHz) Reception sensitivity -130 dB max. Channel Separation 85 dB (at 1 kHz) Signal system... - Page 17 DivX, Inc. and are used under license • The BLUETOOTH word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Alpine Electronics, Inc. is under license. • “MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.”...
