Fluke 365 User Manual

Detachable jaw true-rms clamp meter
Hide thumbs Also See for 365:
Table of Contents

Advertisement

Quick Links

Users Manual
365
True-rms
PN 3622684
August 2010
© 2010 Fluke Corporation. All rights reserved. Printed in China. Specifications are subject to
change without notice. All product names are trademarks of their respective companies.

Advertisement

Table of Contents
loading

Related Manuals for Fluke 365

Summary of Contents for Fluke 365

  • Page 1 Users Manual Detachable Jaw True-rms Clamp Meter PN 3622684 August 2010 © 2010 Fluke Corporation. All rights reserved. Printed in China. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
  • Page 2 LIMITED WARRANTY AND LIMITATION OF LIABILITY This Fluke product will be free from defects in material and workmanship for three years from the date of purchase. This warranty does not cover fuses, disposable batteries, or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.

  • Page 3: Table Of Contents

    Table of Contents Title Page Introduction......................... 1 Contact Fluke ......................2 Safety Information ...................... 2 The Meter ........................7 Specifications ......................14 Electrical Specifications..................14 Mechanical Specifications ..................15 Environmental Specifications ................. 16...
  • Page 4 Users Manual...

  • Page 5: Introduction

    Introduction Warning Read "Safety Information" before you use the Meter. The Fluke 365 is a true-rms hand-held, battery-operated clamp meter (the Meter) that features a detachable Jaw. The Meter measures: ac and dc current ac and dc voltage resistance continuity...

  • Page 6: Contact Fluke

    Users Manual Contact Fluke To contact Fluke, call one of the following telephone numbers: Technical Support USA: 1-800-44-FLUKE (1-800-443-5853) Calibration/Repair USA: 1-888-99-FLUKE (1-888-993-5853) Canada: 1-800-36-FLUKE (1-800-363-5853) Europe: +31 402-675-200 Japan: +81-3-3434-0181 Singapore: +65-738-5655 China: +86-400-810-3435 Anywhere in the world: +1-425-446-5500 Or, visit Fluke's website at www.fluke.com.
  • Page 7 Detachable Jaw True-rms Clamp Meter Safety Information Warning To prevent possible electrical shock or personal injury, follow these guidelines: Use the Meter only as specified in this manual or the protection provided by the Meter can be compromised. Examine the case before you use the Meter. Look for cracks or missing plastic. Carefully look at the insulation around the connectors.
  • Page 8 Users Manual Have the Meter serviced only by qualified service personnel. Be careful around voltages >30 V ac rms, 42 V ac peak, or 60 V dc. Such voltages pose a shock hazard. Do not apply more than the rated voltage, as marked on the Meter, between the terminals or between any terminal and earth ground.
  • Page 9  The Meter shuts down when the Double insulated  battery reaches 2.0 V. Do not dispose of this product as unsorted municipal waste. Go to Conforms to relevant North American   Fluke’s website for recycling Safety Standards. information.
  • Page 10 Users Manual Symbol Meaning Symbol Meaning IEC Measurement Category III CAT III equipment has protection Application around and removal from against transients in equipment in  CAT III HAZARDOUS LIVE conductors is fixed-equipment installations, such permitted. as distribution panels, feeders and short branch circuits, and lighting systems in large buildings.

  • Page 11: The Meter

    Detachable Jaw True-rms Clamp Meter The Meter The Meter Clamp Meter fig01.eps...
  • Page 12 Users Manual Spotlight Detachable Jaw fig12_13_365.eps...
  • Page 13 Detachable Jaw True-rms Clamp Meter The Meter Auto Power Off Backlight AC DC fig02_3.eps...
  • Page 14 Users Manual Fig04_05_365.eps...
  • Page 15 Detachable Jaw True-rms Clamp Meter The Meter Fig06_07_365.eps...
  • Page 16 Users Manual Fig08_09_365.eps...
  • Page 17 Detachable Jaw True-rms Clamp Meter The Meter Fig11_365.eps...

  • Page 18: Specifications

    Users Manual Specifications Electrical Specifications AC Current Range ............. 200.0 A Resolution ..........0.1 A Accuracy ..........2 % 5 digits (45 – 65 Hz) 2.5 % 5 digits (65 – 400 Hz) Crest Factor ..........2.5 @ 125 A 1.55 @ 200 A Add 2 % for C.F.

  • Page 19: Mechanical Specifications

    Detachable Jaw True-rms Clamp Meter Specifications Resolution ..........0.1 V Accuracy ..........1.5 % 5 digits (45 – 400 Hz) DC Voltage Range .............600.0 V Resolution ..........0.1 V Accuracy ..........1 % 5 digits Resistance Range .............600.0 /6000 Resolution ..........0.1 /1 Accuracy ..........1 % 5 digits Mechanical Specifications Size (L x W x H) ........225 x 65 x 46 mm Weight.............275 g (including batteries)

  • Page 20: Environmental Specifications

    Users Manual Environmental Specifications Operating Temperature......-10 C to +50 C Storage Temp ......... -40 C to +60 C Operating Humidity ......... Non condensing (<10 C) 90 % RH (at 10 C to 30 C) 75 % RH (at 30 C to 40 C) 45 % RH (at 40 C to 50 C) (Without Condensation) Operating Altitude ........
  • Page 21 Detachable Jaw True-rms Clamp Meter Specifications Safety Compliance........ANSI/ISA S82.02.01:2004 CAN/CSA-C22.2 No. 61010-1-04 UL 61010-1:2004 EN/IEC 61010-1:2001 to 600V CAT III Pollution Degree 2     Agency Approvals ........Batteries..........2 AA, NEDA 15A, IEC LR6...
  • Page 22 Users Manual...
