Users Manual
365
Detachable Jaw
True-rms
Clamp Meter
PN 3622684
August 2010
© 2010 Fluke Corporation. All rights reserved. Printed in China. Specifications are subject to
change without notice. All product names are trademarks of their respective companies.
MyFlukeStore
1.888.610.7664
www.
.com
Shop for Fluke products online at:

Advertisement

loading

Related Manuals for Fluke 365

Summary of Contents for Fluke 365

  • Page 1 Users Manual Detachable Jaw True-rms Clamp Meter PN 3622684 August 2010 © 2010 Fluke Corporation. All rights reserved. Printed in China. Specifications are subject to change without notice. All product names are trademarks of their respective companies. MyFlukeStore 1.888.610.7664 www. .com...
  • Page 2 LIMITED WARRANTY AND LIMITATION OF LIABILITY This Fluke product will be free from defects in material and workmanship for three years from the date of purchase. This warranty does not cover fuses, disposable batteries, or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.

  • Page 3: Table Of Contents

    Title Page Introduction......................... 1 Contact Fluke ......................2 Safety Information ...................... 2 The Meter ........................7 Specifications ......................14 Electrical Specifications..................14 Mechanical Specifications ..................15 Environmental Specifications ................. 16 MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...

  • Page 4: Introduction

    Introduction Warning Read "Safety Information" before you use the Meter. The Fluke 365 is a true-rms hand-held, battery-operated clamp meter (the Meter) that features a detachable Jaw. The Meter measures: • ac and dc current • ac and dc voltage •...

  • Page 5: Contact Fluke

    Meter damage, equipment under test damage, or permanent loss of data. Symbols used on the Meter and in this manual are explained in Table 1. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
  • Page 6 To avoid false readings that can lead to electrical shock and injury, replace the batteries as soon as the low battery indicator () appears. • When servicing the Meter, use only specified replacement parts. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
  • Page 7 Do not measure ac/dc current in circuits carrying more than 600 V or 200 A with the Meter Jaw. • Never operate the Meter with the back cover removed or the case open. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
  • Page 8 2.0 V. Do not dispose of this product as unsorted municipal waste. Go to Conforms to relevant North American   Fluke’s website for recycling Safety Standards. information. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
  • Page 9 The Measurement Category (CAT) and voltage rating of any combination of test probe, test probe accessory, current clamp accessory, and the Meter is the LOWEST rating of any individual component. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...

  • Page 10: The Meter

    Detachable Jaw True-rms Clamp Meter The Meter The Meter Clamp Meter fig01.eps MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
  • Page 11 Users Manual Spotlight Detachable Jaw fig12_13_365.eps MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
  • Page 12 Detachable Jaw True-rms Clamp Meter The Meter Auto Power Off Backlight AC DC fig02_3.eps MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
  • Page 13 Users Manual Fig04_05_365.eps MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
  • Page 14 Detachable Jaw True-rms Clamp Meter The Meter Fig06_07_365.eps MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
  • Page 15 Users Manual Fig08_09_365.eps MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
  • Page 16 Detachable Jaw True-rms Clamp Meter The Meter Fig11_365.eps MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...

  • Page 17: Specifications

    1.55 @ 200 A Add 2 % for C.F. >2 DC Current Range ............. 200.0 A Resolution ..........0.1 A Accuracy ..........2 % ±5 digits AC Voltage Range ............. 600.0 V MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...

  • Page 18: Mechanical Specifications

    Accuracy ..........1 % ±5 digits Mechanical Specifications Size (L x W x H) ........225 x 65 x 46 mm Weight.............275 g (including batteries) Jaw Opening ...........18 mm Detachable Jaw Cable Length ....900 mm MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...

  • Page 19: Environmental Specifications

    ≤45 % RH (at 40 °C to 50 °C) (Without Condensation) Operating Altitude ........2000 meters Storage Altitude ........12,000 meters Temperature Coefficients......0.1 x(specified accuracy)/ °C (<18 °C or > 28 °C) MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
  • Page 20 Safety Compliance........ANSI/ISA S82.02.01:2004 CAN/CSA-C22.2 No. 61010-1-04 UL 61010-1:2004 EN/IEC 61010-1:2001 to 600V CAT III Pollution Degree 2     Agency Approvals ........Batteries..........2 AA, NEDA 15A, IEC LR6 MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
