Specifications - Gateway HD2401 User Manual

Specifications

Specifications are subject to change without notice or obligation. Many products for Gateway and
its subsidiaries are custom engineered by our suppliers to Gateway specifications and may vary
from similarly marketed products.
Connections and inputs
Power consumption
Wall mount bracket
www.gateway.com
Panel size 24 inches (diagonal)
Panel type 24-inch viewable
TFT active matrix TN
Glare
Pixel resolution 1920 × 1200 (native) (60 Hz)
Pixel pitch 0.0106 × 0.0106 inches (0.270 mm × 0.270 mm)
Aspect ratio 16:10
2
Brightness 400 cd/m
Contrast ratio UltraContrast Disabled: 1000:1 (typical)
UltraContrast Enabled: 2000:1
Viewing angles 160° horizontal, 160° vertical
Response time UltraResponse Enabled: 2 ms (average)
UltraResponse Disabled: 5 ms (typical)
Frequency Horizontal: 74 KHz
Vertical: 60 Hz
Lamp type/life 30,000 hours (minimum)
Colors 16.7 million
Color gamut 92%
OSD languages English, French, Spanish, Italian, Japanese
Analog (VGA): 15-pin mini d-sub VGA
■
Digital (DVI-D): 24-pin DVD-D (supports 480i, 480p, 720p, 1080i, and
■
1080p). Includes HDCP (High-bandwidth Digital Content Protection)
HDMI (supports 480i, 480p, 720p, 1080i, and 1080p)
■
AC power input
■
12V/2A speaker bar power output
■
Included cables 15-pin mini d-sub analog VGA
DVI cable
Power
Normal operation: <150 W
Standby mode: <2 W
Off: <1 W
Power input 100~240 VAC, 50/60 Hz (built-in power supply)
Certifications UL, cUL, FCC Class B, CE, NOM, VCCI
VESA 4 3.937 inches (4 100 mm)
Weight Net weight (with stand): 17.20 lbs. (7.8 kg)
With stand and optional speaker bar: 19.84 lbs (9.0 kg)
Dimensions Stand at lowest position: 22.48 × 17.36 × 9.92 inches
(571 × 441 × 252 mm)
Stand at highest position: 22.48 × 22.48 × 9.92 inches
(571 × 571 × 252 mm)
21
