Planar PXL2230MW User Manual

Led touch monitor
Hide thumbs

Advertisement

Table of Contents

PXL2230MW
LED Touch Monitor
USER'S GUIDE
www.planar.com

Advertisement

Table of Contents
loading

Related Manuals for Planar PXL2230MW

Summary of Contents for Planar PXL2230MW

  • Page 1 PXL2230MW LED Touch Monitor USER'S GUIDE www.planar.com...

  • Page 2: Table Of Contents

    Unpacking Instructions ......................2 Safety Precautions .........................2 Front View of the Product.......................3 Rear View of the Product ......................4 Quick Installation........................5 Basic Operation and Calibration/Reset Instructions ..............6 Advanced Operation—OSD Menu ..................8 Supporting Timing Modes....................11 Technical Information ......................12 Wall-Mount Installation Instructions..................13 Troubleshooting........................14 Planar Support ........................15...

  • Page 3: Operation Instructions

    According to WEEE regulation, this Touchscreen LED Monitor can't be handled as normal trash in Europe when it is out of usage. Please refer to the recycle information on Planar’s website to handle it.For more information on how to recycle your product, please visit WWW.PLANARSYSTEMS.COM/GREEN...

  • Page 4: Unpacking Instructions

    Unpacking Instructions  Move the LED LCD monitor out of the package and take off the plastic bag and Polystyrene Foam.  Pull the base from Parallel versus Panel to Vertical.  Adjust the Panel between 0° leaning forward and 20° leaning backward. Safety Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit.

  • Page 5: Front View Of The Product

    Front View of the Product ① ② ③ ④ ⑤ ⑥ ① OSD Turn On/ Off ② Volume Adjust/ Scroll Down/ Adjust Decrease ③ Preset Mode/ Scroll UP/ Adjust Increase ④ Input select/ Confirm Selection ⑤ Power On/ Off ⑥ LED Indicator...

  • Page 6: Rear View Of The Product

    Rear View of the Product ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑦ Power Input ⑧ USB – Type A to B ⑨ Headphone Jack ⑩ Audio Input ⑪ HDMI Input(HDMI 19 pin) ⑫ DVI Input (DVI 24 pin) ⑬ VGA Input (D-Sub 15 pin)

  • Page 7: Quick Installation

    Quick Installation 1. Connect either VGA, DVI or HDMI Video Source from the monitor to the computer. Make sure both monitor and computer are powered OFF. 2. Connect the audio cable from audio output of computer to the audio input of the monitor. 3.

  • Page 8: Basic Operation And Calibration/Reset Instructions

    Basic Operation and Calibration/Reset Instructions Before using the TFT Touchscreen LED LCD monitor:  Connect external equipment properly.  Insert the power plug, and the power LED indicator will light orange. Power On/Off To turn the TFT Touchscreen LED LCD monitor on/off: Press POWER button on the front.
  • Page 9 Repeat this step to unlock. PXL2230MW Calibration/Reset Instructions: The PXL2230MW is available with USB connection. It is Microsoft® Windows® 7 HID (Human Interface Device) compatible if you use the USB touch screen interface. No additional software driver is required. Calibration is a simple process and can be invoked by running Tablet PC Settings from Control Panel and clicking the Calibrate button.

  • Page 10: Advanced Operation-Osd Menu

    Advanced Operation—OSD Menu You can use the OSD menu to adjust various settings for your TFT Touchscreen LED LCD monitor. Press the 1 button to display the OSD Menu, and use ▲▼ to select the desired OSD menu. Short Cuts Function from the button(s) Auto Image Adjust: To auto adjust Horizontal Position, Vertical Position, Phase (Fine Tune) and Clock (H.
  • Page 11 Color Adjust: To select the color for improving brightness and color saturation between 9300K, 6500K, 5400K, and User Color. 9300K: Adds blue to screen image for cooler white. 6500K: Adds red to screen image for warmer white and richer red. 5400K: Adds green to screen image for a darker color.
  • Page 12 Setup Menu: To set up Language, OSD Position, OSD Time Out and OSD Background. Language Select: To allow users to choose from available languages. Press ▼ or ▲ button to select between horizontal and vertical OSD OSD Position: Position adjustment. H.

  • Page 13: Supporting Timing Modes

    Supporting Timing Modes STANDARD RESOLUTION 720 x 400 @ 70Hz 640 x 480 @ 60Hz 640 x 480 @ 67Hz VESA 640 x 480 @ 72Hz VESA 640 x 480 @ 75Hz VESA 800 x 600 @ 56Hz VESA 800 x 600 @ 60Hz VESA 800 x 600 @ 72Hz VESA...

  • Page 14: Technical Information

    Technical Information LCD Panel 21.5” TFT (with LED backlight) Power Management On: 25 Watts (typical),30 Watts (maximum) Standby Mode : < 0.5 Watt Off: < 0.5 Watt Displayable Resolution Full HD 1920 x 1080 max. Vertical Frequency 60Hz max. Pixel Dimension 0.24825 x 0.24825 mm LCD Display Color 16.7M...

  • Page 15: Wall-Mount Installation Instructions

    Wall-Mount Installation Instructions Wall Mount Arm not included Turn the power OFF then disconnect the cables from the TFT Touchscreen LED LCD monitor before performing the procedure below. 1. Lay the TFT Touchscreen LED LCD monitor face down on a soft surface.

  • Page 16: Troubleshooting

    Troubleshooting No power  Make sure A/C power cord is securely connected to the power adapter and the power supply is firmly connected to the TFT Touchscreen LED LCD monitor .  Plug another electrical device into the power outlet to verify that the outlet is supplying proper voltage.

  • Page 17: Planar Support

    Planar Support Cables, Replacement Lamps, Accessories To find cables, replacement lamps and accessories for your LED LCD monitor, touch screen or other Planar products visit our online store at www.PlanarOnline.com or find other stores who carry Planar products at http://www.planar.com/howtobuy Technical Support Visit Planar at http://www.planar.com/support for product registration, operations manuals,...
  • Page 18 2013 020-1024-01A P/N:2001171303T...
