NetVanta 6240/6250 Series HIG
Front Panel Features
Status LEDs
The status LEDs are located on the right side of the front panel. The
status. The LED indicates the status of the voice ports. The
VOICE
the status of the network interfaces. The
networks (LANs). Table 1
LED
STATUS
VOICE
NET 1 through
NET 4
LAN 1/LAN 2

Rear Panel Design

The NetVanta 6240 Series rear panel is shown below.
61700202G1-34B
LAN 1
below describes the front panel LEDs.

Table 1. NetVanta 6240 Front Panel LEDs

Color
Off Unit is not receiving power.
Green (flashing) On power up, the STATUS LED flashes rapidly for five
seconds, during which time the user may escape to boot
mode from the CONSOLE port.
Green (solid) Power is on and the unit is functioning normally.
Amber (solid) Power has failed and the unit is in battery backup mode.
Red Power is on, but the self-test failed.
Off All ports are inactive or administratively disabled.
Green (flashing) At least one port is ringing.
Green (solid) At least one port is off-hook.
Amber (solid) Port is in test mode.
Red Alarm or fault condition is occurring on the port interface.
Off All ports are inactive or administratively disabled.
Green (solid) Port is functioning normally.
Amber (solid) Port is in test mode.
Red Alarm or fault condition is occurring on the port interface.
Off LAN is administratively disabled or link is down.
Green (solid) The link is up.
Amber (flashing) There is activity on the link.
FXO 0/1 FXO 0/2

Figure 2. NetVanta 6240 Rear Panel Layout

Copyright © 2013 ADTRAN, Inc.
STATUS
NET 1
and LEDs reflect the status of the local area
LAN 2
Indication
NET 1 NET 2 NET 3 NET 4
ETH 0/1 ETH 0/2
T1 0/1 T1 0/2 T1 0/3 T1 0/4
10/100 10/100
PRI/CAS
BASE-T BASE-T
Physical Description
LED indicates the unit's
through LEDs reflect
NET 4
15
