Sanyo PLC-XP55/L Specifications

4500 ANSI LUMENS
PLC-XP55/L
XGA Portable Multimedia Projector
IMPRESSIVE BRIGHTNESS AND CONTRAST RATIO
A 300W NSH lamp combined with Sanyo's high-contrast optical
system with Micro Lens technology delivers an impressive
4500 ANSI lumens of brightness and a contrast ratio of 1100:1.
NETWORK CONTROL / ADMINISTRATION
Sanyo's optional PJ-Net Organizer Plus allows for control and
administration of a projector via a network. Projector status
can be monitored, and projector functions can be controlled
through a web browser. A notification can be automatically
sent via E-mail whenever the projector encounters a problem,
allowing the administrator to act quickly to resolve the issue.
NETWORK IMAGE TRANSFER
The optional PJ-Net Organizer Plus also provides for the
transfer of image data from a PC through the network to the
projector. The Image Capture Mode allows for real-time image
capture and transmission. In the Network Viewer mode, image
data can be called up from a network server, converted using
the included software, and controlled and presented on the
networked projector.
SANYO's NEW PROGRESSIVE IC
A newly developed progressive integrated circuit provides
highly improved playback of moving images. 1080 interlaced
signals are converted into progressive signals while 2-3
pulldown doubles the resolution of images from DVD playback.
HDCP COMPLIANT DIGITAL VISUAL INTERFACE
The digital visual interface (DVI-D) of the PLC-XP55/L is High-
bandwidth Digital Content Protection (HDCP) compliant for
playback of encrypted digital video sources.
UNIQUE COLOR MANAGEMENT SYSTEM
Sanyo's color management system allows you to change the
shading of a specific color in the image to a desired shade
without affecting other colors or adjustment items such as tint
or white balance.
OPTIONAL REAL COLOR MANAGER SYSTEM
The optional Real Color Manager System provides white
balance adjustment and gamma correction from a PC using the
included image adjustment software by simply comparing the
on-screen image to a printed color chart.
CUSTOMIZABLE START-UP LOGO
The PLC-XP55/L can capture logo files to display during the
projector's countdown sequence at startup.
BAYONET-STYLE ONE-TOUCH LENS REPLACEMENT
Attaching the included One-Touch lens mount adapters to your
lenses makes installation and removal of our optional lenses
quick and easy.
PRESENTATION TECHNOLOGIES
Issued 8/03
TRUE XGA
Resolution
Brightness (typical)
Uniformity
LCD Panel System
Number of Pixels
Contrast Ratio
Projection Image (diagonal)
Aspect Ratio
Throw Distance
Zoom/Focus
Up/Down Ratio
Digital Keystone Correction
Projection System
Projection Lens
Lens Throw Ratio
Projection Lamp
Scanning Frequency
Dot Clock
Color System
Computer Compatibility
Sound Output
Voltage
BTU Rating
dB Rating
Power Consumption
Dimensions (WxHxD)
Net Weight
User Maintenance
Input Terminal Panel 1
Input Terminal Panel 2
Input Terminal Panel 3
Additional Input Terminals
Output Terminals
Included Accessories
Optional Accessories
Warranty
Because its products are subject to continuous improvement, SANYO reserves the right to
modify product design and specifications without notice and without incurring any obligations.
21605 Plummer Street
Chatsworth, CA 91311
Ph: 818.998.7322 ext. 288
Fax 818.717.2719
www.sanyolcd.com
Model PLC-XP55L does not include a lens
MULTIMEDIA PROJECTOR
S p e c i f i c a t i o n s
RGBHV or Composite/Component Video (BNC x5)
D-Sub 15 x 1 • Variable audio x1 (stereo mini-jack)
Wired/Wireless I/R Remote Control w/Mouse Pad and
• Wired remote cable • Serial/USB Control Cables
• Dust cover • Lens cover • One-touch Lens mount
Optional Lens Specifications
On-Axis
Short Fixed
Part No. LNS-W32
Zoom No
Throw Ratio 0.8:1
F Stop 2.6
Length 9.25"
Weight 3.5 lbs.
XGA (1024 x 768)
4500 ANSI Lumens
90%
1.3" TFT Poly w/Micro Lens x 3
2,359,296 (786,432 x 3)
1100:1 (full on/off)
31"-400"
4:3
4.6'-48.2'
Powered (1:1.3 zoom)
10:0 – 1:1
Vert. +/- 40°, Horiz. +/- 10°
Polarized Beam Splitter optical system
F1.7-2.0 / f1.9"-2.5"
1.8-2.4:1
300W NSH
H 15-100kHz; V 50-100Hz (auto sense/select)
180 MHz
PAL/PAL-M/PAL-N/SECAM/NTSC/NNTSC4.43
SXGA, XGA, SVGA, VGA
Two-piece stereo 2W rms
100-240V AC; 50/60/Hz (auto sense/select)
1535
35.0 (Eco mode)
450W
12.6" x6.6"x16.9"
PLC-XP55: 18.5 lbs.; PLC-XP55L: 15.7 lbs.
Clean air filters, replace lamp assembly
D-Sub 15 x1 • DVI–D x1 (w/HDCP)
• Audio x1 (stereo mini jack)
• Audio x1 (stereo mini jack)
Composite/Component Video (RCA x3)
• L & R Audio (RCA x2) • S-Video x1
Wired remote control jack x 1 (stereo mini jack)
• USB x 1 • Control Port x 1 (Mini Din 8-pin)
Laser Pointer • AC power cord • VGA Cable
adapter (POA-LNA03) • Owner's manual
• PJ-Net Organizer Plus (POA-PN02)
• Real Color Manager CD-ROM (POA-RCM01)
• Optional Lenses (see below)
Three years parts and labor; 90 days lamp;
Quick Repair Program under warranty
Short Zoom Long Zoom
LNS-W31A LNS-T31A
Power Power
1.25–1.8:1 2.3–4.2:1
2.5 – 3.1 2.0 – 2.9
7.6" 8.5"
3.7 lbs. 4.2 lbs.
© 2003 SANYO
Ultra Long
Zoom
LNS-T32
Power
4.2-6.0:1
2.1 – 2.7
4.6"
3.7 lbs.
