Eye damage could result. Be especially careful that children do not stare directly into the beam. – Install the projector in a proper position. If not, it may result in a fire hazard. – Provide appropriate space on the top, sides and rear of the projector cabinet for allowing air circulation and cooling the projector.
Do not use attachments not recommended by the manufacturer as they may cause hazards. Do not place this projector on an unstable cart, stand, or table. The projector may fall, causing serious injury to a child or adult, and serious damage to the projector. Use only with a cart or stand recommended by the manufacturer, or sold with the projector.
Telephone No. : (818)998-7322 The AC Power Cord supplied with this projector meets the requirement for use in the country you purchased it. AC Power Cord for the United States and Canada: AC Power Cord used in the United States and Canada is listed by the Underwriters Laboratories (UL) and certified by the Canadian Standard Association (CSA).
TABLE OF CONTENTS FEATURES AND DESIGN PREPARATION NAME OF EACH PART OF PROJECTOR SETTING-UP PROJECTOR CONNECTING AC POWER CORD LENS INSTALLATION ADJUSTABLE FEET INSTALLING PROJECTOR IN PROPER POSITION MOVING PROJECTOR CONNECTING PROJECTOR TERMINALS OF PROJECTOR CONNECTING TO COMPUTERS CONNECTING TO VIDEO EQUIPMENT...
This Multimedia Projector is designed with most advanced technology for portability, durability, and ease of use. This projector utilizes built-in multimedia features, a palette of 1.07 billion colors, and matrix liquid crystal display (LCD) technology. ◆ Compact Design This projector is extremely compact in size and weight.
Refer to the owner's manual of the optional PJ-Net organizer. AIR INTAKE VENTS This projector is equipped with cooling fans for protecting from overheating. Pay attention to the following matters to ensure proper ventilation and avoid a possible risk of fire and malfunction.
NOTE ON POWER CORD AC power cord must meet the requirements of the country where you use the projector. Confirm the AC plug type with the chart below and a proper AC power cord must be used.
2. For installation, refer to the installation manual of the optional lens. NOTE: • When installing the lens, remove the cover cap of the projector. LENS INSTALLATION COVER CAP PREPARATION...
Keystone distortion of the projected image can be corrected by the Menu Operation. (See pages 22 and 38.) INSTALLING PROJECTOR IN PROPER POSITION Install the projector properly. Improper installation may reduce the lamp life and cause a fire hazard. 10˚ 10˚...
● When carrying the projector, use a suitable carrying case. ● Do not transport the projector by courier or any other transport service in an unsuitable transport case. This may cause damage to the projector. To transport the projector by courier or any other transport service, consult your dealer for the best way.
CONNECTING PROJECTOR TERMINALS OF PROJECTOR This projector has input and output terminals on its back for connecting computers and video equipment. Refer to the figures on pages 12 to 14 and connect properly. COMPUTER AUDIO INPUT 1/ AUDIO MONITOR OUTPUT...
AC outlet before connecting cables. Turn a projector and peripheral equipment on before computer is switched on. (✽ = Cables or adapters not supplied with this projector.) • Control Cable for PS2 Port ✽ • USB Cable •...
VIDEO Y - Cb/Pb - Cr/Pr Terminals of the Projector NOTE: Audio Speakers Unplug the power cords of both the projector and (stereo) external equipment from the AC outlet before connecting cables. ✽ Component video output equipment. (such as DVD players or high-definition TV sources.)
Used to adjust focus. (p.22) LASER POINTER FUNCTION These caution labels are put on the remote control. POWER ON-OFF BUTTON Used to turn the projector on or off. (p.20, 21) AUTO PC ADJ. BUTTON Use to operate the AUTO PC Adjustment function.
Point the remote control toward projector Receiver Window) when pressing any button. Maximum operating range for the remote control is about 16.4’ (5 m) and 60° in front and rear of the projector. 60° 16.4’ (5 m) 16.4’ (5 m) 60°...
TOP CONTROLS AND INDICATORS This projector has CONTROL BUTTONS (TOP CONTROLS) and INDICATORS on its top. LAMP REPLACE INDICATOR WARNING TEMP. INDICATOR Turns to yellow when the Blinks red when the internal projection lamp reaches its temperature of the projector end of life.
BEFORE OPERATION HOW TO OPERATE ON-SCREEN MENU You can control and adjust this projector with On-Screen Menu. Refer to the relevant pages to operate each adjustment. 1. DISPLAY MENU Press the MENU button to display the On-Screen Menu. 2. MOVING POINTER Move the pointer (✽...
Auto picture control/Color temp./White balance (R/G/B)/ Sharpness/Gamma/Noise reduction/Progressive] (See pages 35-37.) BEFORE OPERATION SETTING MENU Used to change settings of the projector or reset the Lamp replacement counter. (See pages 38-44.) SOUND MENU Used to adjust the volume, switch the Built- in SP.
Lamp control status icon (see page 41) appear on the screen. If the projector is locked with a PIN code, a PIN code Input Dialog Box appears. Enter a PIN code as instructed below. To Enter a PIN code Select a number by pressing the POINT LEFT/RIGHT button and fix the number with the SELECT button.
You can turn it on again after the READY indicator becomes GREEN again. • When the On start function is “On,” this projector is turned on automatically by connecting the AC power cord to an AC outlet. (See page 41 for the On start function.)
BASIC OPERATION Press the ZOOM button on the top control or ZOOM ▲/▼ buttons on the remote control. “Zoom” appears on the screen. Press the ZOOM ▲ button or POINT UP button to make the image larger, and press the ZOOM ▼ button or POINT DOWN button to make the image smaller.
PICTURE FREEZE FUNCTION Press the FREEZE button on the remote control to freeze the picture on the screen. To cancel the FREEZE function, press the FREEZE button again or press any other button. Press the NO SHOW button on the remote control to black out the image.
DVI (Digital Visual Interface) from being copied. The specification of HDCP is decided and controlled by Digital Content Protection, LLC. Should the specification be changed, this projector may not display the digital content protected by HDCP. INPUT button ✽...
(Some computers need to be set manually.) The projector displays one of these: Auto, -----, Mode 1~ 10, or the system provided in the projector. When the projector cannot recognize a connected signal...
To store the adjusted parameters. The system parameters from Auto PC Adjustment can be memorized in this projector. Once the parameters are stored, the setting can be done just by selecting Mode in PC SYSTEM Menu (p.25). See MANUAL PC ADJUSTMENT on pages 27-28.
However, some computers employ special signal formats which may not be tuned by the Multi-Scan system of this projector. If this happens, the projector cannot reproduce proper image and it may be recognized as a flickering; non-synchronized; non-centered; or skewed picture.
Page 28
COMPUTER INPUT Reset To reset the adjusted parameters, select Reset and press the SELECT button. A confirmation box appears. Select [Yes]. All the adjustments return to their previous figures. Mode free To clear adjusted parameters previously set, move the red frame pointer to the Mode free icon and then press the SELECT button.
Select an image level from among Standard, Real, and Image 1 to Image 10 by pressing the IMAGE button on the top control or on the remote control. Standard Normal picture level preset on this projector. Real Picture level with improved halftone for graphics. IMAGE 1~10 User preset picture adjustment in the IMAGE ADJUST Menu.
COMPUTER INPUT PICTURE SCREEN ADJUSTMENT This projector has a picture screen resize function, which enables you to display the desirable image size. Press the MENU button to display the On-Screen Menu. Press the POINT LEFT/RIGHT buttons to move the red frame pointer to the SCREEN Menu icon.
Select an INPUT source by pressing the INPUT button on the top control or the INPUT 1, INPUT 2, or INPUT 3 buttons on the remote control. If the projector cannot reproduce proper image, select a correct input source with the MENU OPERATION (see below).
PAL / SECAM / NTSC / NTSC4.43 / PAL-M / PAL-N If the projector cannot reproduce proper video image, select a specific broadcast signal format from among PAL, SECAM, NTSC, NTSC 4.43, PAL-M, and PAL-N.
Select an image level from among Standard, Cinema, Image 1 to Image 10 by pressing the IMAGE button on the top control or on the remote control. Standard Normal picture level preset on this projector. Cinema Picture level adjusted for picture with fine tone. IMAGE 1~10 User preset picture adjustment in the IMAGE ADJUST Menu.
VIDEO INPUT PICTURE SCREEN ADJUSTMENT This projector has a picture screen resize function, which enables you to customize the image size. Press the MENU button to display the On-Screen Menu. Press the POINT LEFT/RIGHT buttons to move the red frame pointer to the SCREEN Menu icon.
PICTURE IMAGE PICTURE IMAGE ADJUSTMENTS Press the MENU button to display the On-Screen Menu. Press the POINT LEFT/RIGHT buttons to move the red frame pointer to the IMAGE ADJUST Menu icon. Press the POINT UP/DOWN buttons to move the red frame pointer to the desired item and then press the SELECT button.
Page 36
PICTURE IMAGE COLOR SELECTION MODE (continued) COLOR M. Return to the COLOR MANAGEMENT POINTER. (If you press the MENU button on the top control or the remote control, it returns to the COLOR MANAGEMENT POINTER and you will need to reselect and readjust the color.) MENU Return to the IMAGE ADJUST Menu.
Page 37
Off ..Progressive scan mode is “Off.” On ..Progressive scan mode is “On.” Film . . . Select for watching a film. With this function, the projector reproduces pictures faithful to the original film quality. NOTE: •...
SETTING This projector has Setting menu that allows you to set up the other various functions described as follows: Press the MENU button to display the On-Screen Menu. Press the POINT LEFT/RIGHT buttons to move the red frame pointer to the Setting Menu icon.
Page 39
• Certain signals may not be captured properly. • When capturing the image that has been adjusted by the Keystone function, the adjusted data is automatically reset and the projector captures an image without keystone correction. • When starting to capture a new image, the previously stored image is cleared even if you cancel the capturing.
Page 40
For reducing power consumption as well as maintaining the lamp life, the Power management function turns off the projection lamp when the projector is not used for a certain period. If the input signal is interrupted and no button is pressed for more than 30 seconds, the timer display with “No signal”...
Page 41
• Be sure to turn the projector off properly (see “TURNING OFF THE PROJECTOR” on page 21). If the projector is turned off in the incorrect sequence, such as unplugging the AC power cord before completing the cool-down etc., the On start function does not operate properly.
Page 42
SETTING This Projector has a USB port for interactive operation between the projector and computers. Set the mode by following the steps below. Wireless Mouse mode Select “ ” when controlling a computer with the remote control of this projector.
Page 43
Off ..the projector is not locked with the PIN code. On1 . . . requires to enter the PIN code every time turning on the projector.
Page 44
SETTING Lamp counter This function is used to reset the Lamp replacement counter. When replacing the projection lamp, reset the Lamp replacement counter with this function. See page 49 for operation. Factory default This function returns all setting values except for the User logo, Key lock, PIN code lock, Logo PIN code lock, and the Lamp counter to the factory default settings.
APPENDIX Remote control is not only able to operate this projector but also functions as a wireless mouse for most personal computers. The MOUSE POINTER, DRAG ON/OFF button, and two CLICK buttons are used for wireless mouse operation. The Wireless mouse function is available only when the PC mouse pointer is displayed on the screen.
ON-OFF button on the top control or remote control. If this happens, unplug and reconnect the AC power cord, and then turn on the projector again to check the operation. If the projector shuts down again or cannot to be turned on, internal checking and repair is required.
When using the projector under dusty or smoky conditions, dust may accumulate on a lens, liquid crystal panels, or optical elements inside the projector. Such condition may degrade the quality of the projected image.
(2) screws. Make sure that the lamp assembly is set properly. Put back the lamp cover and tighten the two (2) screws. Connect the AC power cord to the projector and turn on the projector. Reset the Lamp replacement counter (refer to”LAMP REPLACE COUNTER”...
Additionally, check carefully to ensure that there are no broken shards or pieces of glass around the projector or coming out from the cooling air circulation holes. Any broken shards found should be cleaned up carefully. No one should check the inside of the projector except those who are authorized trained technicians and who are familiar with projector service.
A problem may be noticed with your graphics controller rather than with the projector. (When you reconnect the projector, be sure to turn the computer and monitor off before you turn on the projector. Turn on equipment in the order of the projector and computer.) 6.
Page 51
● Check if the ALL-OFF switch on the remote control is set to “ON.” not work. ● Make sure there is no obstruction in between the Infrared remote receiver of the projector and the remote control. ● Make sure you are not too far from the projector when using the remote control.
APPENDIX Computer Input/Video Input Input Input 1 Input 2 Input 3 Computer Input System ✽ System displayed in the System Menu varies depending on the input signal. PC Adjust Auto PC adj. Fine sync. Total dots Position H Position V Current mode Clamp Display area - H...
Page 53
Ready Shut down 1-30 Min. Quit On-Start On/Off Lamp control Auto/Normal/Eco Remote Control Code 1 Code 8 Quit Mouse Projector Security Key lock Projector Remote Control Quit PIN code lock Off/On1/On2 PIN code change Quit Lamp counter Yes/No Factory default...
APPENDIX COMPATIBLE COMPUTER SPECIFICATIONS Basically this projector can accept a signal from all computers with V-, H-Frequency mentioned below, and less than 140 MHz of Dot Clock. ON-SCREEN RESOLUTION DISPLAY VGA 1 640 x 480 VGA 2 720 x 400...
Projector Condition LAMP The projector is OFF. (The AC power cord is unplugged.) The projector is ready to be turned on with the POWER ON- OFF button. The projector is operating normally. The Warning Temp. indicator blinks red to let you know the internal temperature of the projector exceeds a normal level.
Page 56
READY LAMP green The projector is in cooling mode. It cannot be turned on until the READY indicator lights green. The projector detects an abnormal condition and cannot be turned on. Unplug the AC power cord and plug it again to turn on the projector.
● Each projector has its own characteristics. When projecting with several projectors on the same screen or side by side, you may recognize different white balance and color uniformity on each projector. Multi-media Projector 12.6” x 6.6” x 16.8” (319 mm x 168 mm x 429.5 mm) 17.4 lbs (7.9 kg)
APPENDIX COMPUTER INPUT-1 TERMINALS (ANALOG) Terminal: HDB15-PIN Pin Configuration COMPUTER INPUT-1 TERMINAL (DIGITAL) Terminal: DVI 24-pin Pin Configuration CONTROL PORT CONNECTOR Terminal: Mini DIN 8-PIN Pin Configuration 8 7 6 USB CONNECTOR (Series B) Pin Configuration CONFIGURATIONS OF TERMINALS Red Input +5V Power Green Input Ground (Vert.
● PJ-Net Organizer ● External Air Filter Kit The lens of this projector can be replaced with other optional lens. This feature enables you to use the projector for wide variety of uses. For installation and replacement of the lens, always contact the sales dealer. The projector lens must be installed or replaced by well-trained sales or service engineers.
APPENDIX Write down the PIN code number in the column below and keep it with this manual securely. If you forgot or lost the number and unable to use the projector, contact the service station. PIN Code Lock No. Logo PIN Code Lock No.
