Samsung SHR-2162 Quick Manual

SHR-2160 / SHR-2162
16-CHannel Standalone digital Video ReCoRdeR
SummaRy
The SHR-2160/SHR-2162 is a sixteen channel Improved
MPEG-4 Digital Video Recorder capable of recording 120ips in
CIF mode. The SHR-2160/SHR-2162 operates in Triplex mode
(monitoring/playback/recording) and can also record synchro-
nized audio on 4 channels at selectable resolutions CIF & Half
D1. Minimum file size is 3.75Kbyte @ CIF: 352x240, 6.5Kbyte @
Half D1: 720x240. Each channel can independently record at
variable rates helping reduce HDD storage.
The SHR-2160/SHR-2162 includes built-in front USB 2.0 & CD-
RW for expanded external storage. The USB 2.0 slot can be
used for internal HDD expansion or external Back Up storage.
It can also be used with a memory stick adding speed and
convenience to video clip downloads.
GVI dba SAMSUNG CCTV • Phone: 972-245-7353 • Fax: 972-245-7333
This product specification is also available in pdf format at www.samsung-security.com
v.02.20.07 The information is subject to change without notice
FeatuReS
• Sixteen Channel DVR
• Triplex Operation (Monitoring/Playback/Recording)
• Resolution: CIF, Half D1
• Improved MPEG-4 (Compression)
(Min. File Size 3.75K)
• Recording Rate: Max. 120ips (CIF)
• Built In CD-RW, USB 2.0
• Back Up: USB HDD, CD-RW, Memory
• Audio Recording: 4 IN/1 OUT
• Motion Detection
• PTZ Control
• Loop Through Video
• Ethernet 10/100 Base T
• DDNS Support (Multiple Options)
• Audio Through Internet Supported
• Available Without CD-RW as SHR-2160
• Remote Controller
aCCeSSoRieS
ADDITIONAL HARD DRIVES
GV-160GBHD, 160GB Fixed Hard Drive
GV-250GBHD, 250GB Fixed Hard Drive
GV-500GBHD, 500GB Fixed Hard Drive
