3-14
! Parallel Port Mode:
This item specifies the parallel port mode.
[SPP]: (Standard Parallel Port) Allows bi-directional parallel port operation at normal speed.
[EPP]: (Enhanced Parallel Port) Allows bi-directional parallel port operation at maximum speed.
[ECP]: (Extended Capabilities Port) Allows bi-directional parallel port operation at a speed faster than
the normal mode's data transfer rate.
[ECP+EPP]: Allows parallel port operation at ECP and EPP mode.
[Normal]: Allows the standard parallel port mode to be used.
! ECP Mode Use DMA:
This item selects the DMA channel of the parallel port.
KV-85
Chapter 3
