Clevo M980NU Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Chapters

Table of Contents
loading

Related Manuals for Clevo M980NU

Summary of Contents for Clevo M980NU

  • Page 3 Preface Notebook Computer M980NU Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the M980NU series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 8: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. VIII...

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 LCD ....................A-6 Mainboard ..................A-7 Overview ..................1-1 Blu-Ray Combo ................A-8 System Specifications ..............1-2 DVD Super Multi ................A-9 External Locator - Top View with LCD Panel Open ......1-5 Schematic Diagrams......... B-1 External Locator - Front & Right side Views .........1-6 External Locator - Left Side &...
  • Page 12 Preface Card Reader, IEEE 1394 .............. B-27 MXM 3.0 Master ................B-28 MXM 3.0 Slave ................B-29 MB to Small B’d Connector A ............. B-30 MB to Small B’d Connector B ............. B-31 Power System ................B-32 Power VCore ................B-33 PWR 1.05V, Screw Hole ..............

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the M980NU series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about driv- ers (e.g.

  • Page 14: System Specifications

    Introduction System Specifications Video Adapter Processor nVIDIA® GeForce GTX 280M SLI PCIe Video Card Intel® Core™ 2 Quad Processor - (478-pin) Micro-FC-PGA Package, 1GB GDDR3 Video RAM On Board 45nm (45 Nanometer) Process Technology: Supports PCIe * 8 (SLI - 2 * PCIe * 8) QX93000 - 2.53 GHz, 12MB On-die L2 Cache &...
  • Page 15 Introduction Interface Communication Four USB 2.0 Ports Built-In Giga Base-TX Ethernet LAN One eSATA Port Bluetooth 2.1 + EDR (Enhanced Data Rate) Module (Factory Option) One DVI-Out Port (with CRT out) Intel® WiFi Link 5300 Series (3*3 - 802.11a/g/n) Wireless LAN PCIe interface Mini-Card Module (Option) One HDMI (High-Definition Multimedia Interface) Port with Audio Output (with HDCP Support)
  • Page 16 Introduction Environmental Spec Temperature ° ° Operating: C - 35 Non-Operating: -20°C - 60°C Relative Humidity Operating: 20% - 80% Non-Operating: 10% - 90% Optional Super Multi Drive Module Blu-Ray Combo Drive Module Intel® WiFi Link 5300/5100 Series (3*3/1*2 - 802.11a/g/n) Wireless LAN PCIe Interface Mini-Card Module 3rd Party 802.11b/g Wireless LAN PCIe Interface Mini-Card Module Bluetooth 2.1 + EDR (Enhanced Data Rate) Module (Factory Option)

  • Page 17: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Optional Built-In PC Camera 2. LCD 3. LED Status Indicators 4. Touch Sensor Instant Keys 5. 8 * Gaming Keys 6. Keyboard 7. TouchPad and Buttons 8.

  • Page 18: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right side Views Figure 2 Front Views 1. Color LEDs 2. Speakers 3. LED Power Indicators 4. Consumer Infrared Transceiver (enabled with optional TV Tuner only) Figure 3 Right Side Views 5. Headphone-In Jack 6.

  • Page 19: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. DVI-Out Port 2. 2 * USB 2.0 Ports 3. RJ-45 LAN Jack 4. HDMI-Out Port 5. 7-in-1 Card Reader 6. ExpressCard Slot 7. Mini-IEEE 1394 Port 8.

  • Page 20: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Sub Woofer 2. Fan Outlet/Intake 3. Component Bay Cover 4. Battery (Secondary HDD Bay - HDD3) 5. Primary HDD Bay (HDD1 & 2) Overheating To prevent your com- puter from overheating make sure nothing...

  • Page 21: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. North Bridge 2. Memory Slots DDR3 So-DIMM 3. Mini-Card Connector (WLAN Module) Mainboard Overview - Top (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. CPU Socket 2. VGA Socket 3. Mini-Card Connector (TV Module) 1 - 10 Mainboard Overview - Bottom (Key Parts)

  • Page 23: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. CCD Cable Connector 2. LCD Cable Connector 3. Side L Cable Connector 4. Inverter Cable Connector 5. LED Cable Connector 6. Subwoofer Connector 7. Power Button Connector 8. Game-Key Cable Connector 9.

  • Page 24: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. Battery Connector 1 - 12 Mainboard Overview - Bottom (Connectors)

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the M980NU series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: 1. Remove the battery page 2 - 5 To remove the Optical Device: 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery Figure 1 Battery Removal If you are confident in undertaking upgrade procedures yourself, for safety reasons it is best to remove the battery. a. Loosen screws. 1. Turn the computer off, and turn it over. b. Release the battery. 2.

  • Page 30: Removing The Optical (Cd/Dvd) Device

    Disassembly Removing the Optical (CD/DVD) Device Figure 2 Optical Device 1. Turn off the computer, and turn it over and remove the battery (page 2 - Removal 2. Locate the hard disk bay cover and remove screws & , and remove the bay cover 3.

  • Page 31: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive Figure 3 The hard disk drive is mounted in a removable case and can be taken out to accommodate other 2.5" SATA hard disk HDD Assembly drives with a height of 9.5mm (h). Follow your operating system’s installation instructions, and install all necessary driv- Removal ers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 32 Disassembly Removing the Hard Disk(s) in the Secondary HDD Bay Figure 4 1. Turn off the computer, and turn it over and remove the battery. Secondary HDD 2. The secondary hard disk bay is located under the battery compartment. Assembly Removal 3.

  • Page 33: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 5 RAM Module The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) DDR III Removal (DDR3) supporting 1066/1333 MHz. The main memory can be expanded up to 6GB. The SO-DIMM modules supported are 1024MB and 2048MB DDR Modules.
  • Page 34 Disassembly 5. Carefully lift the keyboard up, being careful not to bend the keyboard ribbon cable. Figure 6 6. Disconnect the keyboard ribbon cable from the locking collar socket RAM Module 7. Remove the keyboard and keyboard shielding plate Removal (cont’d.) d.

  • Page 35: Removing The Vga Card

    Disassembly Removing the VGA Card Figure 7 VGA Card Removal 1. Turn off the computer, and turn it over and remove the battery (page 2 - 2. Locate the component bay cover and remove screws a. Remove the screws. 3. Carefully (a fan and cable are attached to the under side of the cover) lift up the bay cover. b.
  • Page 36 Disassembly 7. Remove screws from the heatsink in the order indicated on the label (two video cards are pictured Figure 8 here). VGA Card Removal 8. Grip the handle and carefully remove the heatsink (cont’d.) 9. Remove screws from the video card. 10.

  • Page 37: Installing The Vga Card

    Disassembly Installing the VGA Card 1. Prepare to fit the VGA card into the slot by holding it at about a 30° angle. Figure 9 2. The card needs to be fully into the slot, and the VGA card and socket have a guide-key and pin which align to allow VGA Card the card to fit securely.

  • Page 38: Removing The Tv Tuner Card

    Disassembly Removing the TV Tuner Card Figure 10 TV Tuner Card 1. Turn off the computer, and turn it over, remove the battery (page 2 - Removal 2. The TV tuner card is visible at point 3. Remove the screw from the TV tuner module and disconnect the cable 4.

  • Page 39: Part Lists

    Part Lists Appendix A: Part Lists This appendix breaks down the M980NU series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 40: Part List Illustration Location

    Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A- 1 Part List Illustration Location Parts M980NU Top with Fingerprint page A - 3 Top without Fingerprint page A - 4 Bottom...

  • Page 41: Top With Fingerprint

    Part Lists Top with Fingerprint Figure A - 1 Top with Fingerprint 㾲䈷 ╭ ╭ 㾲䈷╭ ╭ ╭ ╭ ╭ ╭ 㾲䈷 ╭ 㾲䈷╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ 㾲䈷╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭...

  • Page 42: Top Without Fingerprint

    Part Lists Top without Fingerprint Figure A - 2 Top without Fingerprint 㾲䈷 ╭ ╭ 㾲䈷╭ ╭ ╭ ╭ ╭ ╭ 㾲䈷 ╭ 㾲䈷╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ 㾲䈷╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭...

  • Page 43: Bottom

    Part Lists Bottom Figure A - 3 Bottom 㾲䈷 㾲䈷╭ ╭ ╭ ╭ ╭ ╭ ╭ 㓶╭ ╭ ╭ ╭ ╭ 䞤㙓╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ 㾲䈷╭ ╭ ╭ ╭ ╭ ╭ ╭...

  • Page 44: Lcd

    Part Lists Figure A - 4 ╭ ╭ ╭ ╭ ╭ ╭ 㾲䈷╭ ╭ ╭ ╭ ╭ ╭ ╭ 㾲䈷╭ ╭ ╭ ╭ ╭ ╭ 㾲䈷╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ 㾲䈷╭ ╭ ╭ ╭ ╭ ╭ ╭...

  • Page 45: Mainboard

    Part Lists Mainboard Figure A - 5 Mainboard ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ 㾲䈷 㾲䈷╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ 㾲䈷╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ ╭ 㾲䈷╭ ╭ ╭ ╭ ╭ ╭ ╭...

  • Page 46: Blu-Ray Combo

    Part Lists Blu-Ray Combo Figure A - 6 Blu-Ray Combo 㾲䈷 㾲䈷 㾲䈷 㕰㖑䜛 㾲䈷 㾲䈷 A - 8 Blu-Ray Combo...

  • Page 47: Dvd Super Multi

    Part Lists DVD Super Multi Figure A - 7 DVD Super Multi 㾲䈷 㾲䈷 㖑䜛 㾲䈷 㖑䜛 㾲䈷 㾲䈷 㾲䈷 DVD Super Multi A - 9...
  • Page 48 Part Lists A - 10...

  • Page 49: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the M980NU notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1...

  • Page 50: Schematic Diagrams

    Schematic Diagrams System Block Diagram Sheet 1 of 53 System Block Diagram B - 2 System Block Diagram...

  • Page 51: Penryn 1/2

    Schematic Diagrams PENRYN 1/2 Sheet 2 of 53 PENRYN 1/2 PENRYN 1/2 B - 3...

  • Page 52: Penryn3 2/2

    Schematic Diagrams PENRYN3 2/2 Sheet 3 of 53 PENRYN 2/2 B - 4 PENRYN3 2/2...

  • Page 53: Mcp79 Fsbi

    Schematic Diagrams MCP79 FSBI Sheet 4 of 53 MCP79 FSB MCP79 FSBI B - 5...

  • Page 54: Mcp79 Mem Ctrl (1

    Schematic Diagrams MCP79 MEM CTRL (1) Sheet 5 of 53 MCP79 MEM CRTL B - 6 MCP79 MEM CTRL (1)

  • Page 55: Mcp79 Mem Ctrl (2)

    Schematic Diagrams MCP79 MEM CTRL (2) Sheet 6 of 53 MCP79 MEM CRTL MCP79 MEM CTRL (2) B - 7...

  • Page 56: Mcp79 Pci-E

    Schematic Diagrams MCP79 PCI-E Sheet 7 of 53 MCP79 PCI-E B - 8 MCP79 PCI-E...

  • Page 57: Mcp79 Lan, Panel

    Schematic Diagrams MCP79 LAN, Panel Sheet 8 of 53 MCP79 LAN, Panel MCP79 LAN, Panel B - 9...

  • Page 58: Mcp79 Pci, Lpc

    Schematic Diagrams MCP79 PCI, LPC Sheet 9 of 53 MCP79 PCI, LPC B - 10 MCP79 PCI, LPC...

  • Page 59: Mcp79 Sata, Usb

    Schematic Diagrams MCP79 SATA, USB Sheet 10 of 53 MCP79 SATA, USB MCP79 SATA, USB B - 11...

  • Page 60: Mcp79 Hda, Misc

    Schematic Diagrams MCP79 HDA, Misc Sheet 11 of 53 MCP79 HDA, Misc B - 12 MCP79 HDA, Misc...

  • Page 61: Mcp79 Power

    Schematic Diagrams MCP79 Power Sheet 12 of 53 MCP79 Power MCP79 Power B - 13...

  • Page 62: Mcp79 Gnd, Rmgt Pwr, Pwrgd

    Schematic Diagrams MCP79 GND, RMGT PWR, PWRGD Sheet 13 of 53 MCP79 GND, RMGT PWR, PWRGD B - 14 MCP79 GND, RMGT PWR, PWRGD...

  • Page 63: Ddr3 So-Dimm_0

    Schematic Diagrams DDR3 SO-DIMM_0 Sheet 14 of 53 DDR3 SO-DIMM_0 DDR3 SO-DIMM_0 B - 15...

  • Page 64: B - 16 Ddr So-Dimm_1

    Schematic Diagrams DDR SO-DIMM_1 Sheet 15 of 53 DDR3 SO-DIMM_1 B - 16 DDR SO-DIMM_1...

  • Page 65: Panel, Inverter, Tpm

    Schematic Diagrams Panel, Inverter, TPM Sheet 16 of 53 Panel, Inverter, Panel, Inverter, TPM B - 17...

  • Page 66: Hdmi, Fan Control

    Schematic Diagrams HDMI, Fan Control Sheet 17 of 53 HDMI, Fan Control B - 18 HDMI, Fan Control...

  • Page 67: Crt, Dvi

    Schematic Diagrams CRT, DVI Sheet 18 of 53 CRT, DVI CRT, DVI B - 19...

  • Page 68: Odd, Ccd, Bt, Usb 2.0

    Schematic Diagrams ODD, CCD, BT, USB 2.0 Sheet 19 of 53 ODD, CCD, BT, USB 2.0 B - 20 ODD, CCD, BT, USB 2.0...

  • Page 69: Kbc Ite It8512-J

    Schematic Diagrams KBC ITE IT8512-J Sheet 20 of 53 KBC ITE IT8512-J KBC ITE IT8512-J B - 21...

  • Page 70: Phy Rtl8211Cl

    Schematic Diagrams PHY RTL8211CL Sheet 21 of 53 PHY RTL8211CL B - 22 PHY RTL8211CL...

  • Page 71: Codec, Subwoofer, Dmic

    Schematic Diagrams Codec, Subwoofer, DMIC Sheet 22 of 53 Codec, Subwoofer, DMIC Codec, Subwoofer, DMIC B - 23...

  • Page 72: Audio Amp

    Schematic Diagrams Audio AMP Sheet 23 of 53 Audio AMP B - 24 Audio AMP...

  • Page 73: Hdmi Switch

    Schematic Diagrams HDMI Switch Sheet 24 of 53 HDMI Switch HDMI Switch B - 25...

  • Page 74: New Card, Mini Card

    Schematic Diagrams New Card, Mini Card Sheet 25 of 53 New Card, Mini Card B - 26 New Card, Mini Card...

  • Page 75: Card Reader, Ieee 1394

    Schematic Diagrams Card Reader, IEEE 1394 Sheet 26 of 53 Card Reader, IEEE1394 Card Reader, IEEE 1394 B - 27...

  • Page 76: Mxm 3.0 Master

    Schematic Diagrams MXM 3.0 Master Sheet 27 of 53 MXM 3.0 Master B - 28 MXM 3.0 Master...

  • Page 77: Mxm 3.0 Slave

    Schematic Diagrams MXM 3.0 Slave Sheet 28 of 53 MXM 3.0 Slave MXM 3.0 Slave B - 29...

  • Page 78: Mb To Small B'd Connector A

    Schematic Diagrams MB to Small B’d Connector A Sheet 29 of 53 MB to Small B‘d Connector A B - 30 MB to Small B’d Connector A...

  • Page 79: Mb To Small B'd Connector B

    Schematic Diagrams MB to Small B’d Connector B Sheet 30 of 53 MB to Small B‘d Connector B MB to Small B’d Connector B B - 31...

  • Page 80: Power System

    Schematic Diagrams Power System Sheet 31 of 53 Power System B - 32 Power System...

  • Page 81: Power Vcore

    Schematic Diagrams Power VCore Sheet 32 of 53 Power VCore Power VCore B - 33...

  • Page 82: Pwr 1.05V, Screw Hole

    Schematic Diagrams PWR 1.05V, Screw Hole Sheet 33 of 53 PWR 1.05V, Screw Hole B - 34 PWR 1.05V, Screw Hole...

  • Page 83: Power 1.5V/0.75V

    Schematic Diagrams Power 1.5V/0.75V Sheet 34 of 53 Power 1.5V/0.75V Power 1.5V/0.75V B - 35...

  • Page 84: Power 1.0Vs

    Schematic Diagrams Power 1.0VS Sheet 35 of 53 Power 1.0VS B - 36 Power 1.0VS...

  • Page 85: Power 3.3V/5V

    Schematic Diagrams Power 3.3V/5V Sheet 36 of 53 Power 3.3V/5V Power 3.3V/5V B - 37...

  • Page 86: Power Charger, Dc-In

    Schematic Diagrams Power Charger, DC-In Sheet 37 of 53 Power Charger, DC-In B - 38 Power Charger, DC-In...

  • Page 87: Single Hdd Board

    Schematic Diagrams Single HDD Board Sheet 38 of 53 Single HDD Board Single HDD Board B - 39...

  • Page 88: Dual Hdd Board

    Schematic Diagrams Dual HDD Board Sheet 39 of 53 Dual HDD Board B - 40 Dual HDD Board...

  • Page 89: Audio Board

    Schematic Diagrams Audio Board Sheet 40 of 53 Audio Board Audio Board B - 41...

  • Page 90: Power Button Board

    Schematic Diagrams Power Button Board Sheet 41 of 53 Power Button Board B - 42 Power Button Board...

  • Page 91: Click & Fp Board

    Schematic Diagrams Click & FP Board Sheet 42 of 53 Click & FP Board Click & FP Board B - 43...

  • Page 92: Logo Led Board

    Schematic Diagrams Logo LED Board Sheet 43 of 53 Logo LED Board B - 44 Logo LED Board...

  • Page 93: Game Key Board

    Schematic Diagrams Game Key Board Sheet 44 of 53 Game Key Board Game Key Board B - 45...

  • Page 94: Touchpad Led Board

    Schematic Diagrams TouchPad LED Board Sheet 45 of 53 TouchPad LED Board B - 46 TouchPad LED Board...

  • Page 95: Front R Side Led Board

    Schematic Diagrams Front R Side LED Board Sheet 46 of 53 Front R Side LED Board Front R Side LED Board B - 47...

  • Page 96: Front L Side Led Board

    Schematic Diagrams Front L Side LED Board Sheet 47 of 53 Front L Side LED Board B - 48 Front L Side LED Board...

  • Page 97: Back L Side Led Board

    Schematic Diagrams Back L Side LED Board Sheet 48 of 53 Back L Side LED Board Back L Side LED Board B - 49...

  • Page 98: Touch Sensor Board A

    Schematic Diagrams Touch Sensor Board A Sheet 49 of 53 Touch Sensor Board A B - 50 Touch Sensor Board A...

  • Page 99: Touch Sensor Board B

    Schematic Diagrams Touch Sensor Board B Sheet 50 of 53 Touch Sensor Board B Touch Sensor Board B B - 51...

  • Page 100: Cir Board

    Schematic Diagrams CIR Board CIR BOARD Sheet 51 of 53 CIR Board KH_O1 KH_O2 KH_O3 KVDD5 KJ_MB KCIR_RX KGND KGND KVDD5 88266-03001 KGND IRM-V038/TR1-P KVDD5_CIR 100_04 GND2 GND2 GND1 GND1 0.1U_16V_04 *4.7U_10V_X5R_06 10U_10V_08 KGND KGND KGND KCIR_RX B - 52 CIR Board...

  • Page 101: Finger Board

    Schematic Diagrams Finger Board Sheet 52 of 53 Finger Board Finger Board B - 53...

  • Page 102: Pwr On Seq Diagram

    Schematic Diagrams PWR on SEQ Diagram Sheet 53 of 53 PWR on SEQ Diagram B - 54 PWR on SEQ Diagram...
