  • Page 1 C150-E009-07EN M3096EX AND M3096GX IMAGE SCANNER OPERATOR’S GUIDE...
  • Page 2 Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. REVISION RECORD Revised contents The contents of this manual is subject to change without prior notice. All Rights Reserved, Copyright 1994, 1995, 1996 FUJITSU LIMITED...
  • Page 3 A WARNING indicates that personal injury may result if you do not follow a procedure correctly. CAUTION A CAUTION indicates that damage to the scanner may result if you do not follow a procedure correctly. NOTICE A NOTICE provides “how-to” tips or suggestions to help you perform a procedure correctly.

  • Page 4: Table Of Contents

    PREFACE ...1-1 CHAPTER 2 COMPONENTS ...2-1 Checking the Components ...2-1 Part Names and Functions ...2-2 2.2.1 Exterior view of image scanner ...2-2 2.2.2 Functions of each part ...2-3 Indication Panel Functions (standard model)...2-4 2.3.1 Indicators ...2-4 Operator Panel Functions (LCD model) ...2-4 2.4.1...
  • Page 5 CHAPTER 5 MAINTENANCE ...5-1 Removing Jammed Documents ...5-1 Notes on Daily Use ...5-2 Cleaning ...5-2 5.3.1 Cleaning the document cover, document holding pad, and document bed ...5-2 5.3.2 Cleaning the ADF ...5-3 Consumables/Periodical replacement parts ...5-4 5.4.1 Parts number and replacement cycle ...5-4 5.4.2 Replacing pad ASY ...5-4 5.4.3...
  • Page 6 Received components ...2-1 M3096EX/GX parts names ...2-2 M3096EX/GX Indication panel ...2-4 M3096EX (LCD model) operator panel ...2-4 SCSI-ID setting ...3-6 Flatbed reading ...4-3 Removing the document cover...4-4 ADF paper chute setting ...4-7 Loading the document ...4-9 Removing jammed documents ...5-1 Cleaning the document cover, document holding pad, and document bed ...5-2...
  • Page 7 The differences between the M3096EX and the M3096GX ...1-1 SCSI-ID setting ...3-6 Check items ...6-1 A.1 Installation specifications ...A-1 B.1 LED at an error ...B-2 TABLES page...

  • Page 8: Chapter 1 Preface

    CHAPTER 1 PREFACE This manual describes how to operate the M3096EX and M3096GX image scanners. An image scanner optically reads image information from a document and outputs the information to the host system. The differences between the M3096EX and the M3096GX image scanners are listed in table 1.1.
  • Page 9 This page is intentionally left blank. 1 – 2...

  • Page 10: Chapter 2 Components

    2.1 Checking the Components These high precision components must be handled with care. Confirm that all the components shown in figure 2.1 have been received. If any component is missing, please contact your local Fujitsu sales person. Image scanner Operator’s Guide...

  • Page 11: Part Names And Functions

    This section shows the exterior view of image scanner. This section also provides names of each part and describes their functions. 2.2.1 Exterior view of image scanner The image scanner can read a document of A3 or double-letter size at maximum. Document cover...

  • Page 12: Functions Of Each Part

    Opens or closes the automatic document feeder to remove documents jammed in the feeder. To be connected to an AC power outlet with the power cable. To be connected to the host system with interface cables. Reserved. (M3096EX) 2 – 3...

  • Page 13: Indication Panel Functions (Standard Model)

    The operator panel has indicators and a liquid crystal display screen for displaying image scanner status. The operator panel also has operation buttons. Liquid crystal display screen Figure 2.4 M3096EX (LCD model) operator panel 2 – 4 Buttons Mode 1...

  • Page 14: Indicators

    • Automatic mode: Reading is started by a command from Stop button: This button is effective regardless of whether the scanner is in manual or automatic mode. Press this button to stop the read operation. When this button is pressed, the image scanner operates as follows: •...

  • Page 15: Liquid Crystal Display Screen

    2.4.3 Liquid crystal display screen The screen has two message lines. The current read mode status is displayed in the upper line, and messages and the modes set by the buttons are displayed in the lower line. Upper line Lower line Reading mode Flatbed Automatic document feeder...
  • Page 16 The ADF, size, density, resolution, landscape, half-tone, document, and mode 1 and 2 buttons described below are effective unless other- wise specified by the host system. Automatic document feeder (ADF) button: Selects whether to feed documents automatically by ADF or manually on the flatbed.
  • Page 17 Density button: Selects a density for the read operation. When this button is pressed, the lower line is displayed as shown in Screen 3. Each time this switch is pressed, the blinking part in the lower line changes, and the density indicated on the upper line changes according to the blinking part.
  • Page 18 Landscape button: Specifies whether reading is done in landscape or portrait mode. When this button is pressed, the lower line is displayed as shown in Screen 5. Each time this button is pressed, the blink- ing part changes in turn, and the mode indicated on the upper line changes accordingly.
  • Page 19 Document button: Selects the type of document. When this button is pressed, the lower line is displayed as shown in Screen 7. Each time this button is pressed, “LINE” or “PHOTO” starts blinking in turn, and the document selection indication displayed on the upper line changes accordingly.

  • Page 20: Messages

    2.4.4 Messages Error messages (temporary errors) If a temporary error occurs in the scanner, one of the following mes- sages is displayed. This message is displayed if there is no more paper on the ADF paper chute during a read operation in ADF mode.
  • Page 21 Error messages (device errors) One of the following messages is displayed if an error occurs in the scanner. If one of the following error messages is displayed, turn the power off and then on again. If the same message is displayed, contact your service representative.

  • Page 22: A.1 Installation Specifications

    This chapter explains how to install and connect the image scanner. 3.1 Precautions Do not install the image scanner in the following places and environ- ments. See the appendix A.1 “Installation Specifications” for the information such as size of installation space.

  • Page 23: Removing The Carrier Fixing Bracket

    Place the image scanner on the edge of the desk top so that the left side (where ADF is placed) of the scanner extends from the desk top. Do not set the image scanner upside down or on its side.

  • Page 24: Connections

    Connect the image scanner using the following procedure. Set the power switch to off. Connect the power cable. Connect the power cable to the power inlet on the back of the image scanner. Connect the other end of the power cable to a power outlet. Power inlet Connect the interface cables (for M3096EX).
  • Page 25 Connect the interface cables to the interface connectors and fasten the cables with the catches. Connect the other ends of the cables to the host system. If the image scanner is at the terminal side, connect the terminator. Back of the image scanner Catches 3 –...

  • Page 26: Mounting The Stacker

    3.4 Mounting the Stacker Mount the stacker and extensions using the following procedure. Mount the stacker. Hook the pins on the stacker to the claws on the image scanner. Stacker Claw Mount the extensions. Mount extensions to the stacker and to the ADF paper chute.

  • Page 27: Scsi-Id Setting

    Figure 3.1 SCSI-ID setting Table 3.1 SCSI-ID setting 0 to 7 8, 9 * When the scanner is terminated device, the termination connector must be connected on one side of the connectors. 3 – 6 Address switch Contents...

  • Page 28: Chapter 4 Operations

    CHAPTER 4 OPERATIONS 4.1 Turning on the Power 4.2 Reading a Document in Flatbed Mode 4.3 Reading Documents in ADF Mode Documents can be read in the flatbed mode or automatic document feeder (ADF) mode. In the flat-bed mode, each document is placed on the document bed and is read one by one. In ADF mode, documents are fed and read automatically.

  • Page 29: Reading A Document In Flatbed Mode

    4.2 Reading a Document in Flatbed Mode This section explains how to read a document placed on the document bed. 4.2.1 Reading a standard-size document If the size of the document is smaller than the document bed, read the document using the following procedure: Open the document cover.

  • Page 30: Reading A Page From A Thick Book

    Document cover Reference mark Document Document bed Indication panel Figure 4.1 Flatbed reading Portrait mode Landscape mode Document bed Document 4.2.2 Reading a page from a thick book To read a page from a thick book, remember the following points: Do not close the document cover forcibly.

  • Page 31: Reading A Document Larger Than The Document Board

    4.2.3 Reading a document larger than the document board If the size of the document is larger than the document board, read the document using the following procedure: Open the document cover at an angle of about 80 , then slide the cover to the direction of the arrow to remove it.

  • Page 32: Reading Documents In Adf Mode

    4.3 Reading Documents in ADF Mode This section explains how to read documents using the automatic document feeder. If the following steps are not closely followed, a feed error may occur. Check the documents as follows: (a) Paper quality • Wood-free paper. •...
  • Page 33 NOTICE: Paper should be straightened to fit the condition below. More than 30 mm Less than 3 mm Top of the paper Switch the paper select lever. Switch the lever in the following procedures: • Open the automatic document feeder (ADF) while lifting up the ADF lever.

  • Page 34: Adf Paper Chute Setting

    Pull up the ADF paper chute as follows: • Hold the document cover with one hand and pull up the ADF paper chute with the other hand to set the shaft in position B. ADF paper chute ADF paper chute Position for operation Position for storage position B...
  • Page 35 Take documents to be placed in the ADF paper chute. The thickness of the documents to be placed in the ADF paper chute is limited depending on the size of the documents as follows: A4 or letter size or smaller: 4 mm or less Size larger than A4: Angling the documents Angle the document edges as follows:...

  • Page 36: Loading The Document

    Open the right and left guides of the ADF paper chute about 5 mm wider than the document width. Place the documents face down onto the ADF paper chute with the top edges facing the automatic feeder hole. Adjust the guides to the document sides. Skewing may occur if there is a gap between the guides and documents.
  • Page 37 This page is intentionally left blank. 4 – 10...

  • Page 38: Chapter 5 Maintenance

    CHAPTER 5 MAINTENANCE 5.1 Removing Jammed Documents 5.2 Notes on Daily Use 5.3 Cleaning 5.4 Consumables/Periodical replacement parts This section explains how to remove jammed documents, and provides notes on daily use and cleaning. 5.1 Removing Jammed Documents If documents jam while being fed by the ADF, remove the jammed documents as follows: Remove the documents from the ADF paper chute.

  • Page 39: Notes On Daily Use

    • Use a dry cloth or a cloth with a neutral cleanser to remove dirt from the document cover, document holding pad, and document bed. Do not use organic solvents such as a thinner. • Make sure that no liquid enters the scanner from the edges of the document bed glass. Document cover Document holding pad Figure 5.2 Cleaning the document cover, document holding pad, and document bed...

  • Page 40: Cleaning The Adf

    5.3.2 Cleaning the ADF Clean the automatic document feeder (ADF) once every 5,000 pages. The cycle depends on the types of documents used (paper quality, a level of toner fusing on paper). Pull the ADF lever up to open the ADF. Use the dry cloth or a cloth with ethyl alcohol to softly remove dirt and dust as follows.

  • Page 41: Consumables/Periodical Replacement Parts

    *2: This part may not be provided in some countries due to the conformability of safety regula- tion. Before the order of the pick roller, contact your sales agent or Fujitsu service repre- sentative. 5.4.2 Replacing pad ASY Lift up the ADF lever and open the ADF.

  • Page 42: Replacing Pick Roller

    Insert the pad assembly into the ADF frame hole (the bigger one), slide the assembly to the direction of the arrow until it clicks. NOTICE : Set the paper select lever to "N", before removing pad ASY NOTICE : Pad can be replaced by aligning the holes of the pad with 5.4.3 Replacing pick roller Replace the pickroller as follows.

  • Page 43: Move The Retaining Spring

    (c) Pinch the retaining spring and slide it toward the roller. Free bearing A from the bracket by sliding it toward the roller. (d) Slide the pick roller shaft in the direction of arrow B and remove the shaft from bearing B. The roller shaft can then be lifted and removed as shown in Figure 5.7.

  • Page 44: Chapter 6 Troubleshooting

    Turn off the power once and make an attempt to turn on the power again. If the power is not turned on, contact your Fujitsu service representative.* Insert the first a few pages into the slot. Make sure that the ADF is closed com- pletely.
  • Page 45 Section 3.2, “Removing the Carrier Fixing Bracket.” Turn the power off then on again. If the check indicator turns on again, contact the sales person in charge or a Fujitsu service representative.* When the power is turned off, the mes- sage is cleared.

  • Page 46: Installation Specifications

    APPENDIX A A.1 Installation Specifications Table A.1 Installation specifications Item External dimensions (mm) Weight (kg) Input power Voltage Number of phases Frequency Power Temperature and humidity allowed ranges Temperature Humidity Specification Width Depth Height 17.5 100 to 120 VAC, 200 to 240 VAC Single-phase 50/60 Hz 100 VA...

  • Page 47: External Dimensions

    A.2 External Dimensions (Unit: mm) Figure A.1 External dimensions A – 2...

  • Page 48: Test Mode For Maintenance

    Open the ADF cover and set the sensors to the following state before turning on the image scanner. The image scanner can be placed in the maintenance mode by pulling out the empty sensor lever and setting the A4 size sensor lever to down position (do not change the setting of other paper size sensors) with the ADF cover fully opened (see Figure below).

  • Page 49: Led At An Error

    Open the ADF and close it again. If no document is loaded on the ADF within five seconds after closing the ADF cover, the image scanner runs in flatbed mode. If docu- ments are loaded on the ADF within five seconds after closing the ADF cover, the image scanner continuously feeds the document from ADF.

  • Page 50: Appendix C

    IPC-2 CA01952-0191 CMP-2 CA01952-0196 Contact your Fujitsu sales agent for more information C.2 IPC-2/CMP-2 option board installation WARING: Follow the outlined procedure to avoid danger from electrical components. Verify that the scanner power is turned off. Remove the AC cable from the year of the scanner.
  • Page 51 Remove the flat cable connector and detach the power supply and PCA assembly. Flat cable Flat cable connector Connect the IPC-2 option board connector and tighten the screw. Where a CMP-2 is installed, remove the screw from the memory board and detach the memory board.
  • Page 52 FUJITSU LIMITED International Operations Marunouchi 1-6-1, Chiyoda-ku, Tokyo 100, JAPAN TEL: (81-3) 3216-3211 FAX: (81-3) 3213-7174 TLX: J22833 Cable: “FUJITSU LIMITED TOKYO” FUJITSU COMPUTER PRODUCTS OF AMERICA, INC. 2904 Orchard Parkway, San Jose. California 95134-2022, U.S.A. TEL: 1-408-432-6333 FAX: 1-408-432-3908 FUJITSU CANADA, INC.
  • Page 53 Reader Comment Form We would appreciate your comments and suggestions for improving this publication. Publication No. Rev. Letter Title How did you use this publication? Learning Installing Reference Maintaining What is your overall rating of this publication? Very Good Fair Good Poor Your other comments may be entered here.
