Specifications - Fujitsu PRIMERGY 4Gbit/s FC I/O Modules Owner's Manual

1.2

Specifications

This product is an expansion board used in order to install fiber channel interface on the server blade.
This product has the following features:
• Capable of high-speed data transfer at a maximum rate of 4Gbps.
• You can place the connected device away from the server.
• Uses thin and light cables so they can be easily connected.
The following shows the specifications of this product:
Item
Product name
Product ID
Function
Number of channels (ports)
Host bus interface
External interface
46
Functions and Specifications
4Gbit/s FC I/O Module
PG-FCD201
Fabric/FC-AL (Arbitrated Loop)
1 channel (2 ports)
PCI-Express 1.0a
1/2/4Gbps (Automatic recognition)
Fibre channel (Optical cable)
LC connector/non-OFC/multimode
