HM506H8908 TrueSTEAM™ Specifications
TrueSTEAM 6‐gallon humidifier with H8908 manual humidistat. Draws 7‐amps.
Product Features:
Application flexibility – Mount directly to the duct or remotely up to
•
20 feet away into tight‐fitting or unconditioned air spaces.
Installs in minutes ‐ Limited duct cutting and bracket‐mount design
•
takes less than 5 minutes to complete.
Easy maintenance – Self‐regulates cleaning cycles throughout the
•
year. Annual maintenance requires no tools to access and clean, saving
time and money on annual contractor service calls. In‐line water filter
for scale and sediment also provided.
•
5‐year warranty ‐ Peace of mind when you buy a Honeywell product.
Product Specifications:
Description
Application
Type
Capacity (gal. per day)
Capacity (liter per day)
Voltage
Color
Mounting
Temperature Range (F)
Temperature Range (C)
Plenum Opening (in.)
Plenum Opening (mm)
Dimensions (in.)
Dimensions (mm)
Includes
TrueSTEAM with H8908 control.
Humidification
Steam
6 gal per day
23 L per day
120 Vac
Empire Gray
Duct or Remote Mount (up to 20 feet/6 meters)
34F‐104F
1.1C‐40C
1 3/4 in. diameter
44.45 mm in diameter
19 in. H x 11 1/4 in. W x 9 in. D
482.6 mm H x 285.75 mm L x 228.6 mm D
Duct template hardware, saddle valve, humidistat, drain supply
water tubing, duct nozzle, mounting bracket, water filter,
backflow valve.
