Setting the clock
This may be operated only with the remote control.
In this example, the clock is set for the 12-hour (AM12:00) display.
1
Press the CLOCK button and within 3 seconds, press
the MEMORY button.
2
Within 1 minute, press the PRESET (
select 12-hour or 24-hour display and then press the
MEMORY button.
"AM 12:00" The 12-hour display will appear.
(AM 12:00 - PM 11:59)
"0:00" The 24-hour display will appear.
(0:00 - 23:59)
Note that this can only be set when the unit is first installed or it
has been reset.
Remote control
Test of the remote control
Face the remote control directly to the remote sensor on the unit.
The remote control can be used within the range shown below:
Press the POWER button. Does the power turn on? Now, you can
enjoy your music.
Remote sensor
8" - 20'
(0.2 m - 6 m)

OPERATION MANUAL

3
Within 1 minute, press the PRESET (
adjust the hour and then press the MEMORY button.
When the 12-hour display is selected, "AM" will change auto-
matically to "PM".
4
Within 1 minute, press the PRESET (
adjust the minutes and then press the MEMORY button.
The clock starts from "0" second. (Seconds are not displayed.)
To confirm the time display when the power is on:
Press the CLOCK button.
The time display will appear for about 5 seconds.
Note:
or ) button to
The time will flash at the push of the CLOCK button when the AC
power supply is restored after a power failure or unplugging the unit.
Readjust the clock as follows.
To readjust the clock:
Perform "Setting the clock" from the beginning. If the time display is
flashing, step 2 (for selecting the 12-hour or 24-hour display) will be
skipped.
To change the 12-hour or 24-hour display:
1 Clear all the programmed contents.
2 Perform "Setting the clock" from the beginning.
Troubleshooting Chart
If trouble occurs
When this product is subjected to strong external interference
(mechanical shock, excessive static electricity, abnormal supply
voltage due to lightning, etc.) or if it is operated incorrectly, it may
malfunction.
If such a problem occurs, do the following:
1 Set the unit to the stand-by mode and turn the power on
again.
2 If the unit is not restored in step 1, unplug and plug in the
unit, and then turn the power on.
3 If neither step 1 nor 2 restores the unit, do the following:
Caution:
This operation will erase all data stored in memory including clock,
timer settings, tuner preset, and CD program.
– 5 –
Press the POWER button to enter the power stand-by mode.
Unplug the AC power cord from the AC INPUT jack on the
unit.
While pressing down the MEMORY/SET button and the
button, plug the AC power cord into the AC INPUT jack on the
unit.
XL-1700/1700C
or ) button to
or ) button to
AC INPUT
