To Replace The System Ram Module - HP OmniBook 510 - Notebook PC Reference Manual

3. Turn the unit upside down, remove the screw holding the RAM cover, and remove the
cover.
4. Release the two latches at the sides of the RAM module, so the free edge of the
module pops up.
5. Pull the module out of the connector.
6. Replace the cover.
7. Insert the battery.

To replace the system RAM module

If needed, you can replace your computer's system RAM module (under the keyboard) to
increase the computer's RAM.
1. If your computer is docked, undock it.
2. Click Start, Shut Down, Shut down (Windows 98 or 2000) or Start, Turn Off
Computer, Turn Off (Windows XP).
3. Important: unplug the AC adapter, if present, and remove the battery.
Add-On Devices
Installing Additional RAM
Reference Guide 99
