- Page 1 Instruction Instruction Manual Manual MODEL NO. DTC-14Q1/14Q1T/20Q1/20Q1T/21Q1/21Q1T 14Q2/14Q2T/20Q2/20Q2T/21Q2/21Q2T 14Q3/14Q3T/20Q3/20Q3T/21Q4/21Q4T 14Q6/14Q6T/21Q8/21Q8T 14T1/14T1T/20T1/20T1T/21T1/21T1T 14T2/14T2T/20T2/20T2T/21T2/21T2T 14T3/14T3T/20T3/20T3T/21T5/21T5T/21T9/21T9T...
-
Page 2: Identity Of Features On Localand Remote Control
IDENTITY OF FEATURES ON LOCALAND REMOTE CONTROL LOCAL CONTROL Front VIDEO AUDIO MENU AV & MENU VOLUME PROGRAMME MAIN VIDEO AUDIO HEAD STAND-BY REMOTE BUTTON DOWN/UP DOWN/UP POWER INPUT INPUT PHONE INDICATOR SENSOR BUTTONS BUTTONS BUTTON REMOTE CONTROL TV mode TELETEXT mode POWER POWER... -
Page 3: Table Of Contents
CONTENTS * Identity of features on Local and Remote Control * Important safeguards * Installation After moving the set Inserting Batteries into the Remote Control Unit Aerial connection Mains connection Switching the set on and off Tuning the TV Channels Edit Manual Channel Setting * Daily use... -
Page 4: Installation
INSTALLATION AFTER MOVING THE SET If the used set is moved or placed in a different direction, the MAIN POWER button must be switched off for at least 15 min- utes in order to take out a colour strain on the screen. INSERTING BATTERIES INTO THE REMOTE CONTROL UNIT Press down the battery compartment grip and slide the cover.Insert the batteries supplied(two 1.5V, type AA). -
Page 5: Tuning The Tv Channels
TUNING THE TV CHANNELS MAIN MANU MAIN MENU PICTURE Press the MENU button to call up the MAIN MENU. TIMER The MAIN MENU is consist of 5 sub-menus: LANGUAGE PRESET PICTURE, TIMER, LANGUAGE, PRESET, EDIT menu. EDIT LANGUAGE SELECTION Select a LANGUAGE menu at the MAIN MENU by placing the cursor on the LANGUAGE with UP/DOWN button and press- ing the OK button. -
Page 6: Manual Channel Setting
MANUAL CHANNEL SETTING SELECT PROGRAMME You can also call up the PRESET menu at the MAIN MENU. PRESET AUTO Press the NUMBER button 0..9 or UP/DOWN buttons to select a programme number you want. The screen will change according to the selected programme num- ber. -
Page 7: Daily Use
DAILY USE SELECTING A PROGRAMME NUMBER The NUMBER button 0..9 are used for direct programme selection. In order to select two-digit programme, press the second numbered button within two seconds. Switch through the programme number step by step with the UP/DOWN button. -
Page 8: Sleep
SLEEP By pressing the SLEEP button repeatedly, you can select one of the fol- lowing setting: -> 0->30min. ->60min.->90min.->120min. The set will turn off after time you select. Automatic Switch-Off in No broadcast Signal If a broadcasting signal is not present for about 30 minutes, the set will be automatically turned off. -
Page 9: Local Control Key Mode
LOCAL CONTROL KEY MODE You can call up the MAIN MENU, not only by using the Remote Control but also by pressing the TV/VIDEO key during 3 sec- onds at the local key. Then MAIN MENU will be displayed on the screen. In this mode Move the cursor to SUB MENU you want, and press the TV/VIDEO key during 3 seconds, then SUB MENU will be displayed on the screen, you can set the SUB MENU... - Page 10 PAGE HOLD Several sub pages can be combined under a page number and are scrolled at an interval determined by the television station. The presence of sub pages is indicated by, for example, 3/6 beneath the time, which means that you are looking at the 3rd page of a total of 6 pages.
- Page 11 P/N:48586370E10H-R4...
