COLOR TELEVISION INSTRUCTION MANUAL MODEL MODEL DTC-25M5/29M5 DTC-14D9/20D9/21D9/2131 DTC-25M5T/29M5T DTC-14D9T/20D9T/21D9T/2131T DTC-25M5TP/29M5TP DTC-14D9TP/20D9TP/21D9TP/2131TP DTC-25M5MT/29M5MT DTC-2132/2132T/2132TP DTC-29M6/29M6T DTC-14K3ME/14K3MP/14K3MT/14K3MZ DTC-29U1/29U5 DTC-21K3ME/21K3MP/21K3MT/21K3MZ DTC-29U1T/29U5T DTC-29U1TP/29U5TP 48586907E202-R2... -
Page 2: Table Of Contents
Table of contents Safeguards INTRODUCTION Features Installation Identification of controls Remote control Swicthing the set ON/OFF Tuning the TV channels Convenient picture control Enjoying wide and zoom picture Convenient sound control Using other menus Watching picture in picture (option) Connecting the external equipment Connecting with other equipment Connecting DVD PLAYER/BS receiver The Othello game... -
Page 3: Safeguards
SAFEGUARDS To operate your receiver at the peak performance, please read this Instruction Manual carefully and retain it for the future reference. M Water and Moisture : Never install the set in the following places : in the bathroom, in a wet basement(Dripping or splashing water). -
Page 4: Introduction Features
INTRODUCTION Features WIDE / ZOOM Screen : You can select a desired WIDE(or ZOOM) screen mode for movies as well as the most 4:3 picture mode. Selectable picture and selectable sound : Allows one-touch selection of your favorite picture quality and tone quality. Off-timer and On-timer: Turns off the TV automatically and will turn it back on at a preset time. -
Page 5: Identification Of Controls
Identification of controls VIDEO 2 FRONT SIDE 29” 29” L(MONO) MENU ON/OFF AUDIO Others AUDIO ON/OFF VIDEO 2 L(MONO) R MENU REAR AUDIO VIDEO VIDEO DVD-Y (MONO) MAIN VIDEO 2 HEAD STAND-BY REMOTE PROGRAMME MENU TV/VIDEO VOLUME INPUT (MONO) PHONE INDICATOR SENSOR DOWN/UP... -
Page 6: Swicthing The Set On/Off
SWITCHING THE SET ON AND OFF Switching On Switch the set on with the ON/OFF button in front of the receiver TV. The set will be turn on. If not, press either : - PR UP or DOWN button on the front of set - or POWER button or the PR UP/DOWN button or one of the NUMBER button 0..9 on the remote controller. -
Page 7: Tuning The Tv Channels
TUNING THE TV CHANNELS AUTO SETUP SYSTEM AUTO SETUP SYSTEM 1. Press the MENU button to select INSTALL. 2. Press the y / x buttons and then select INSTALL. 3. Select AUTO SETUP with the PRy / x buttons. Press the right button and then select a sound system. Press the right button to start AUTO SETUP. - Page 8 EDIT 1. Press the menu button to select INSTALL. 2. Press the y / x buttons and then INSTALL SYSTEM. 3. Select EDIT with the PR y / x buttons and press the C / B buttons to start EDIT. 4.
-
Page 9: Convenient Picture Control
CONVENIENT PICTURE CONTROL You can select the picture quality instantly. TO SELECT THE PICTURE MODE 1. press the MENU button to select the PICTURE and then to be displayed on the right appearance. BY pressing the C / B buttons, the following four mode change cyclically.[DTC-29U*:Three mode(NORMAL, MILD, FAVOURITE)] MODE Picture Quality... -
Page 10: Enjoying Wide And Zoom Picture
ENJOYING WIDE AND ZOOM PICTURE You can enjoy WIDE picture and ZOOM picture with TV. In addition to regular wide / zoom screen mode. TO SELECT THE WIDE OR ZOOM SCREEN 1. By pressing the P.SIZE button in remote control, the following four modes change cyclically. NORMAL WIDE ZOOM... -
Page 11: Convenient Sound Control
CONVENIENT SOUND CONTROL You can select and adjust the sound quality as you like. TO VOLUME CONTROL Adjust the volume with the volume Down / Up button on the front of the set, or with the C / B buttons on the remote control. -
Page 12: Using Other Menus
USING OTHER MENUS TO SET CLOCK 1. Press the MENU button to select the FEATURES and then to be displayed on the right appearance. 2. Select the CLOCK with PR y / x buttons. 3. Press the C / B buttons to activate the hour or the minute and preset the hour or minute with the direct(0~9) buttons. - Page 13 TO TURN ON THE TV AUTOMATICALLY(WAKE TIME) With the CLOCK, the WAKE TIME, the WAKE PR. Preset, the TV will automatically turn on to a preset program number at a reset time. Select the WAKE TIME with PR y / x buttons. Press the C / B buttons to activate the hour or the minute and preset the hour or the minute with the PR y / x buttons or the direct(0~9) buttons.
- Page 14 SLEEP TIME SETTING PR02 1. By pressing the SLEEP button repeatedly, you can set the sleep time SLEEP 2. If you press the SLEEP button for the first time, SLEEP 0 sign of the non set sleep-timer appears on the upper left side of the screen. 3.
- Page 15 TO SELECT THE ON-SCREEN DISPLAY LANGUAGE Use this function to choose the language of the on-screen display(OSD) among English, Vietnamese, Indonesian, Russian, Arabic, Persian, French and Rumanian. 1. Press the MENU button to select the FEATURES and then to be displayed on the right appearance.
-
Page 16: Watching Picture In Picture(Option)
WATCHING PICTURE IN PICTURE(OPTION) The unit is capable of displaying two picture with the small sub picture simultaneously. This is called the Picture-In-Picture function. A TV picture or a picture from external source equipment such as a VTR can be displayed as another picture. TO WATCH A TV OR AN EXTERNAL SOURCE AS A SUB-PICTURE 1. - Page 17 TO SWITCH THE MAIN AND SUB-PICTURE OF THE PIP Press the SWAP button when a picture-in-picture is displayed. The main picture(the large picture) and sub-picture(the small picture) are switched. Press the SWAP button again to switch again. TO CHANGE THE POSITION OF THE SUB PICTURE Press the POSITION button repeatedly when a sub-picture is displayed.
-
Page 18: Connecting The External Equipment
CONNECTING THE EXTERNAL EQUIPMENT When connecting other equipment, please ensure you turn the main switch OFF to prevent any damage to the equipment. HEADPHONE JACK(29”:SIDE, OTHERS:FRONT) Insert the headphone plug (3.5mm ) into the headphone socket. The sound from the speaker will be cut off. VIDEO 2 L(MONO) 29”... -
Page 19: Connecting With Other Equipment
CONNECTING WITH OTHER EQUIPMENT When connecting other equipment, please ensure you turn the main switch OFF to prevent any damage to the equipment. DVD-Y VIDEO (MONO) DVD IN LEFT VIDEO RIGHT 1. You can use other equipment with TV signal. 2. -
Page 20: Connecting Dvd Player/Bs Receiver
CONNECTING DVD PLAYER/BS RECEIVER 1. Prepare the connective plug for picture / sound. DVD-Y VIDEO 2. Connect the DVD-Y output terminal of DVD player with the DVD-Y input terminal of TV. 3. Connect the DVD-Cr, Cb output terminal of DVD player (MONO) with the DVD-Cr, Cb input terminal of TV. -
Page 21: The Othello Game
THE OTHELLO GAME 1. Introduction Othello is a two player strategy game. Othello is player on an 8 x 8 square board, one taking white while the other taking green. The object of Othello is to flip as many of your opponents discs to your color as possible without opponent flipping your discs. - Page 22 3. How to Play 1. Press the TV/AV( ) button to open the Game mode DVD1 DVD2 GAME) You can open the Game mode by pressing SIZE(PIP) key. 2. Select Opponent This option allow you to choice opponent. PLAYER 1 You can select Man vs Man or Man vs TV.
-
Page 23: Teletext(Option)
TELETEXT(OPTION) TEXT Language SELECT The TEXT language is supported by the OSD language. * If you select incorrect the OSD language for your mother tongue, the TEXT language will display a letter incorrectly. SWITCHING TELETEXT ON/OFF Press the TELETEXT button ( ). -
Page 24: Specification
SPECIFICATION TV Standard Color system PAL/SECAM, NTSC-4.43(AV) Sound system B/G, D/K, I Rated voltage AC100-250V, 50/60Hz Power consumption 14” : 80W, 20” : 90W, 21” : 95W, 29” : 130W Sound Output Power 5W+5W(14”, 20”), 7W+7W(21”, 29”) Tuning System FS Tuning System Program No.
