- Page 1 Versa E6000 Disassembly Manual...
-
Page 2: Table Of Contents
Removing the LCD Panel.............................14 Removing the CPU...............................15 Removing the Top Cover .............................18 Removing the Touch Pad.............................20 Removing the Main Board............................21 Removing the Speaker Assembly ........................24 DIP Switch Settings ..............................25 Screws..................................26 Notice ...................................27 NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 2... -
Page 3: Overview
Furthermore, the screws that are removed are shown next to the image of the parts themselves. NEC reserves the right to make changes to the Versa E6000/EasyNote G5 chassis without notice. Technician Notes Only technicians authorized by NEC Computers International BV should attempt to repair this equipment. -
Page 4: Hazardous Voltage
Inside the power supply are hazardous avviare il sistema senza aver prima messo a voltages that can cause serious personal injury. Always posto il coperchio return a defective power supply to your dealer. NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 4... -
Page 5: Removing The Battery
Removing the Battery Perform the following steps to remove the battery: 1. Make sure to power off the Versa E6000/EasyNote G5. 2. Turn the unit upside down. 3. Unlock the battery and slide it out of its place as the arrow shows in Fig. 1 Fig. -
Page 6: Removing The Memory Module
Fig. 2 Removing the screw retaining the memory module slot cover 2. Unclip the memory module as shown in Fig. 3 Fig. 3 Removing the memory module 3. Remove the memory module from its slot and put it aside. NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 6... -
Page 7: Removing The Mdc Modem
1. Release screws and disconnect cable on MCD Modem as shown in Fig. 4 M2.5x4 Silver Fig. 4 MDC Modem 2. Lift up the MDC modem and put it aside. NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 7... -
Page 8: Removing The Hard Disk Drive
2. Release the screws that secure HDD module as shown in Fig. 6 and carefully pull the HDD module out from the base unit. M3x8.5 Silver Fig. 6 Screw retaining the HDD module NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 8... -
Page 9: Removing The Keyboard
Fig. 7 Releasing the keyboard cover 2. Lift up the keyboard cover carefully and disconnect cable attached on it as shown in Fig. 8 Fig. 8 Lifting up the Keyboard Cover NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 9... -
Page 10: Removing The Optical Disk Drive
Keyboard (see Removing the Keyboard) then perform the following steps: 1. Remove the screws retaining the optical drive as shown in Fig. 10 M2.5x9 Silver Fig. 10 Releasing the optical drive NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 10... - Page 11 2. Flip over the unit, and push the ODD module out from the base unit as shown in Fig. 11 Fig. 11 Pushing the optical drive out from the base unit NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 11...
-
Page 12: Removing The Lcd Module
Fig. 13 Removing the screws retaining the LCD Module 5. Release the screws on the system rear side as shown in Fig. 14 M2.5x9 Silver Fig. 14 Removing the screws retaining the LCD Module NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 12... -
Page 13: Removing The Wlan Card Module
Module) then perform the following steps: 1. Remove the wireless antenna connector and release the WLAN Card Module as shown in Error! Reference source not found. Fig. 16 Wireless Card Module NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 13... -
Page 14: Removing The Lcd Panel
Fig. 17 Removing the rubber covers & screws on the LCD Module 3. Release the inverter board by remove the screw and disconnect all connectors as shown in Fig. 18 M2x4 Silver Fig. 18 Removing the Inverter Board NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 14... -
Page 15: Removing The Cpu
Keyboard) then perform the following steps: 1. Remove the screws retaining the Heat Plate as shown in Fig. 20 M2.5 x 5 Silver Fig. 20 Removing the screws retaining Heat Plate NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 15... - Page 16 M2.5x6.5 Silver Fig. 21 CPU Fan 3. Unscrew screws on CPU Heat Sink in descending order (3 2 1) as shown in Fig. 22 M2.5x4 Copper Fig. 22 CPU Heat Sink NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 16...
- Page 17 CPU die. When install heat sink, screws must be secured in ascending order (1 2 3). 4. Unlock the CPU from the CPU socket and lift up the CPU carefully. Fig. 23 Unlocking the CPU NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 17...
-
Page 18: Removing The Top Cover
Removing the LCD Module) then perform the following steps: 1. Remove all screws on the bottom of the base unit as shown in Fig. 24 M2.5x9 Silver Fig. 24 Bottom Cover NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 18... - Page 19 B=M2.5x6 Silver Fig. 25 Top Cover screws 3. Disconnect the Touch Pad Connector as shown in Fig. 26 Fig. 26 Touch Pad connection 4. Carefully lift up the Top Cover. NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 19...
-
Page 20: Removing The Touch Pad
1. Unscrew the screws on the Top Cover as shown in Fig. 27 M2x4 Silver Fig. 27 Touch Pad 2. Carefully separate the Touch Pad module from Top cover. NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 20... -
Page 21: Removing The Main Board
2. Unscrew those screws on HDD holder as shown in Fig. 29 and separate it carefully from Main Board. A = M2.5x5 Silver B = M2x8 Silver Fig. 29 HDD Holder NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 21... - Page 22 3. Disconnect Audio board from main board as shown in Fig. 30 Lifting up the audio board 4. Disconnect Speaker and Lid switch connectors from the Main board as shown in Fig. 31 Fig. 31 Connectors on Main Board NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 22...
- Page 23 A = M2.5x8 B = M2.5x5 Silver Fig. 32 Screws on Main Board 6. Lift up the Main Board as shown in Fig. 33 Fig. 33 Lifting up the Main Board NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 23...
-
Page 24: Removing The Speaker Assembly
1. Remove the screws holding Speaker Assembly as shown in Fig. 34 M2x7 Silver Fig. 34 Speaker Assembly 2. Carefully remove the Speaker assembly from Bottom Cover and place it aside. NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 24... -
Page 25: Dip Switch Settings
DIP Switch Settings Jumper Status Open Open Close Open Open Open Open Close Close Close Open Close Close Close Open Logo Setting JP consumer JP Commercial APAC HK/CN NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 25... -
Page 26: Screws
Screws M3x8 Silver M2.5x6.5 Silver M2.5x9 Silver M2.5x7 Silver M2.5x5 Silver M2x7 Silver M2.5x8 Silver M2x8 Silver M2.5x10 Silver M2x4 Silver M2.5x6 Silver M2.5x4 Copper NEC Versa E6000/PB Easy Note G5 Disassembly Manual Page 26... -
Page 27: Notice
This guide contains information protected by copyright. No part of this guide may be photocopied or reproduced in any form or by any means without prior written consent from NEC Computers International BV. NEC COMPUTERS INTERNATIONAL BV SHALL NOT BE LIABLE FOR TECHNICAL OR EDITORIAL ERRORS OR OMISSIONS CONTAINED HEREIN;...
