QuickSpecs
Overview
1. Processor(s)
2. Three 5.25" Optical drive bays
3. On/Off Button
4. Hard disk drives
5. One full-length AGP 8x Slot
At A Glance
Up to two HP PA-8900 dual core processor modules (2-way standard; 4-way optional)
2 or 4-way 1.0 GHz PA-8900 with 3.0 MB L1 cache (1.5MB per core)
2 or 4-way 1.0 GHz PA-8900 with 3.0 MB L1 cache (1.5 MB per core) and 64 MB shared L2 cache
2 or 4-way 1.1 GHz PA-8900 with 3.0 MB L1 cache (1.5 MB per core) and 64 MB L2 cache
HP zx1 chipset with 400 MHz system bus
6.4 GB/s effective processor bandwidth
8.6 GB/s memory bandwidth
3.5 GB/s I/O bandwidth
80 ns memory access latency
Enterprise-class operating systems: HP-UX 11i v1
ECC PC2100 DDR-266 memory, expandable to 32 GB
Four Internal 3 1/2 inch drive bays; up to 1.2TB of SCSI or 160GB IDE hard drive storage
Integrated 10/100/1000 Mbps Base-T Ethernet
AGP 8X Pro 150 watts max power graphics interface
Six PCI slots*
Three external bays 5 1/4 inch drive bays
DVD-ROM, DVDRW or CD-RW Optical Drive
Full Independent Software Vendor (ISV) certification and support for leading technical applications
Protected by HP Services, including a one-year limited warranty. Certain restrictions and exclusions apply.
NOTE: Accessory card slots have various configurations. See details in "Standard Features" area.
DA - 12134 North America — Version 12 — May 25, 2007
6. Four full-length PCI
7. Two half-length PCI
8. 2-Way Motherboard
9. Power supply
10. Memory DIMMs
HP c8000 Workstation
Page 1

Advertisement

loading

Related Manuals for HP c8000

Summary of Contents for HP c8000

  • Page 1 DVD-ROM, DVDRW or CD-RW Optical Drive Full Independent Software Vendor (ISV) certification and support for leading technical applications Protected by HP Services, including a one-year limited warranty. Certain restrictions and exclusions apply. NOTE: Accessory card slots have various configurations. See details in "Standard Features" area.

  • Page 2: Standard Features

    HP c8000 Workstation Standard Features Processor Up to two 2-way (dual core) HP PA-8900 processor modules (1.0 or 1.1 Ghz) Operating System HP-UX 11i version 1 TCOE (Technical Computing Operating Environment) HP-UX 11i version 1 MTOE (Minimal Technical Operating Environment) Cache Memory 3.0 MB L1 on-chip cache (1.5 MB per processor core)
  • Page 3 ATI FireGL X3-256 (dual display) Audio 16-bit stereo full-duplex – uses half-length slot (optional card) Input Devices HP 104/105 key keyboard, available in 21 localized layouts HP three-button optical mouse HP three-button optical scroll mouse HP SpaceBall 3D Input Device...
  • Page 4 8 GB PC2100 DDR-266 SDRAM memory kit (2x4GB DIMMs) Monitors HP L1955 19-inch TFT Flat Panel Display - Analog/Digital HP LP2065 20-inch TFT Flat Panel Display - Analog/Digital HP LP2465 24-inch TFT Widescreen Flat Panel Display (1920x1200 resolution) Internal hard disks Ultra320 SCSI Drives (max. 4) (minimum 1)
  • Page 5 QuickSpecs HP c8000 Workstation Configure-to-order Options (custom configurations) Optical Drive 16X DVD-ROM Drive 16X DVDRW Drive 48X CD-RW Drive Rack and Tower Workstation Rack Kit Options Workstation Tower Kit (must order 1) DA - 12134 North America — Version 12 — May 25, 2007...
  • Page 6 QuickSpecs HP c8000 Workstation After-Market Options/Standalone Accessories Operating Systems HP-UX 11i version 1 TCOE (Technical Computing Operating Environment) B6821AA HP-UX 11i version 1 MTOE (Minimal Technical Operating Environment) B6845AA 2nd Processor 2-way 1.0 GHz PA-8900 with 3 MB L1 cache and 64 MB L2 cache AB675A 2-way 1.1 GHz PA-8900 with 3 MB L1 cache and 64 MB L2 cache...
  • Page 7 HP Ultrium 232 Tape Drive Internal DW064A HP Ultrium 232 Tape Drive External DW065A Communications 1000BaseTX PCI LAN Adapter for HP-UX (Available 0D1 only. For field add- A6825A on/standalone, use A6825A) 1000BaseSX (Fibre) PCI LAN Adapter for HP-UX A6847A PCIX 4-Port 1000 Base-TX LAN Adapter...
  • Page 8 (EMEA, APJ) HP LP2465 24-inch TFT Widescreen Flat Panel Display EF224A5 (Americas) EF224A4 (EMEA, APJ) NOTE: AssetControl features are accessible with HP workstations featuring Intelligent Manageability. DA - 12134 North America — Version 12 — May 25, 2007 Page 8...

  • Page 9: Maximum Memory

    QuickSpecs HP c8000 Workstation Memory ECC Registered PC2100 DDR-266 memory Memory must be installed in pairs of the same size. Memory upgrade kits come in pairs. This chart does not represent all possible memory configurations. Peak bandwidth: up to 8.5 GB/s.

  • Page 10: Drive Support

    QuickSpecs HP c8000 Workstation Storage Drive Bay Locations Drive Support Quantity Supported Position Supported Controller Optical Drives DVD-ROM Drive Up to 2 1, 2, 3 Integrated EIDE CD-RW Drive Up to 2 1, 2, 3 Integrated EIDE DVDRW Drive Up to 1...

  • Page 11: Technical Specifications

    QuickSpecs HP c8000 Workstation Technical Specifications System Unit Tower Dimensions Height 19.3 in (490.2 mm) Depth 22.5 in (571.4 mm) Chassis Width 8.0 in (203.2 mm) Pedestal Width 11.3 in (287.0 mm) Weight Minimum Tower 49.5 lb (22.5 kg) (tower configuration)
  • Page 12 QuickSpecs HP c8000 Workstation Technical Specifications - Controllers and Hard Drives Ultra320 Embedded Number of supported 15 per channel Dual Channel SCSI devices Controller Interface protocol Supports Fast, Ultra, Ultra2, Ultra160 and Ultra320 Host bus transfer rate Up to 320 MB/s...
  • Page 13 QuickSpecs HP c8000 Workstation Technical Specifications - Controllers and Hard Drives 300 GB Capacity 300,000,000,000 bytes Height 1.0 in (2.5 cm) Width 3.5 in (8.9 cm) Interface 68-pin LVD SCSI Synchronous Transfer 320 MB/s Rate (Maximum) Buffer 8 Mbytes Seek Time (typical Single Track 0.3 msec...

  • Page 14: Technical Specifications - Graphics

    Occupies 1 physical slot in the system Dimensions Single AGP/ATX card. 9.07 x 4.25 in (230.28 x 107.96 mm) Multi-monitor support DVI-I and DB-15 connectors support dual display, maximum HP-UX supported resolution of single display 1920 x 1200, maximum dual display 2560 x 1024 Additional product...
  • Page 15 Dimensions Single AGP/ATX card. 9.07 x 4.25 in (230.28 x 107.96 mm) Multi-monitor support Maximum HP-UX supported resolution of single display 1920 x 1200 analog or digital. Maximum dual display 3840 x 1200. Additional product 256-MB DDR SDRAM unified frame buffer, Z-buffer and Texture storage features 64-KB BIOS Serial Flash ROM, reprogrammable by SW, 3.3V only, no...
  • Page 16 QuickSpecs HP c8000 Workstation Technical Specifications - Monitors HP L1955 Flat Panel Panel Type Active matrix, thin film transistor (TFT) Monitor Viewable Image Area 19 in (48.25 cm) maximum viewable (diagonal) Screen Opening (WxH) 14.9 x 12.0 in (38.0 x 30.5 cm)
  • Page 17 Technical Specifications - Monitors User Programmable Yes, 15 Modes Anti-Glare Anti-Static AssetControl Yes (accessible on HP Compaq Business Desktops featuring Intelligent Manageability) Default Color Yes (6500k, 9300k, SRGB, Custom User) Temperature On Screen Display Buttons or Switches Power on/off; 3-button OSD; second level...
  • Page 18 (sold separately), and four USB ports for easy integration of third-party digital solutions. Sold separately; part number DK985A. For more information, refer to the HP Desktop Access Center QuickSpecs. HP Flat Panel Speaker Powered directly by the monitor, seamlessly...
  • Page 19 Ergo, UL Listed, VCCI Approvals, Microsoft® Windows® Certification Compatibility VESA Video Signal Standard (VSIS) Compliant video cards have been tested and proven compatible for use with the HP L1955 Flat Panel Monitor. Recommended for use with HP products. Service and Warranty Limited three-year parts and repair labor, service provider labor, and on- site service.
  • Page 20 (to half brightness) *All specifications are provided by the component manufacturers. Performance specifications represent the highest specification of all HP's component manufacturers' typical level specifications for performance. Actual performance may vary either higher or lower. On Screen Display Buttons or Switches...
  • Page 21 QuickSpecs HP c8000 Workstation Technical Specifications - Monitors Video Input Plug and Play Self Powered USB 2.0 One upstream, four downstream ports (cable included) Input Signal Two DVI-I connectors (dual VGA analog or dual digital input possible) Input Impedance 75 ohms ± 10% Sync Input Separate sync (HSYNC/VSYNC);...
  • Page 22 HP flat panel monitors. Features include dual speakers with full sound range and external jack for headphones. Sold separately. For more information, refer to the HP Silver Flat Panel Speaker Bar QuickSpec. Other Accessories Included VGA to DVI-I cable - connects the graphic card's VGA connector to the monitor's input #1 or 2 (DVI-I analog) connector.
  • Page 23 Replacement options include 2nd business day on- site service or next business day direct replacement. With direct replacement, HP will ship a replacement display product directly to you. Using the shipping labels provided, return your failed display to HP.
  • Page 24 QuickSpecs HP c8000 Workstation Technical Specifications - Monitors Signal Interface/ Horizontal Frequency 30 to 94 kHz (VGA input); 30 to 92 KHz (DVI Performance input) (for modes with pixel clock less than 157 MHz) Vertical Frequency 48 to 85 Hz (VGA and DVI input)
  • Page 25 Language support is available in English, Japanese, French, German, Spanish, Italian, and Traditional and Simplified Chinese. HP Display Assistant is a software utility that allows monitor adjustment, color calibration, and security/asset management using the Display Data Channel Command Interface (DDC/CI) protocol of the connected desktop DA - 12134 North America —...
  • Page 26 With direct replacement, HP will ship a replacement display product directly to you. Using the prepaid shipping labels provided, return your failed display to HP in the same packaging as the replacement. Certain restrictions and exclusions apply. For details see your product warranty or contact HP Customer Support.
  • Page 27 The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
