TurboChef i5 Ventless Submittal Information

TurboChef i5 Ventless Submittal Information

Ventless submittal
Hide thumbs Also See for i5:

Advertisement

Quick Links

Download this manual See also: Service Manual, Owner's Manual
TurboChef Technologies Inc.
i5 Ventless Submittal Information
Spec Sheet
UL Ventless Label
UL Listing
UL KNLZ Explained
Emissions Test Results
Emissions by Product
Fire and Smoke Statement
Energy Usage Estimate
County of Los Angeles Public Health Approval
© 2008–2013 TurboChef Technologies, Inc.
1.1
2.1
3.1
4.1
5.1
6.1
7.1
8.1
9.1
DOC-1340 / Rev E / May 2013

Advertisement

loading

Related Manuals for TurboChef i5

Summary of Contents for TurboChef i5

  • Page 1 TurboChef Technologies Inc. i5 Ventless Submittal Information Spec Sheet UL Ventless Label UL Listing UL KNLZ Explained Emissions Test Results Emissions by Product Fire and Smoke Statement Energy Usage Estimate County of Los Angeles Public Health Approval © 2008–2013 TurboChef Technologies, Inc.

  • Page 2: Interior Construction

    Variable rack positioning to rapidly cook food without compromising external air filtration quality, the i5 oven maximizes versatility with smart menu system capable of storing up to 200 recipes its large cavity size and ability to cook with Flash software updates via smart card most any metal pan.

  • Page 3: Shipping Information

    TurboChef recommends installing a type D circuit breaker for all installations. Minimum entry clearance required for box: 31.5” (800 mm) TurboChef reserves the right to substitute components or change specifications without notice. Minimum entry clearance required for crate: 35.5” (902 mm)
  • Page 4 Page 2.1...
  • Page 5 KNLZ.E151487 - Commercial Cooking Appliances with Integral Systems for Limiting the Emission of ... Page 3.1 KNLZ.E151487 Commercial Cooking Appliances with Integral Systems for Limiting the Emission of Grease-laden Air Commercial Cooking Appliances with Integral Systems for Limiting the Emission of Grease-laden Air TURBOCHEF TECHNOLOGIES INC Commercial microwave/convection ovens http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/showpage.html?name=KNLZ.E151487... 8/26/2008...
  • Page 6 KNLZ.GuideInfo - Commercial Cooking Appliances with Integral Systems for Limiting the Emission of... Page 4.1 KNLZ.GuideInfo Commercial Cooking Appliances with Integral Systems for Limiting the Emission of Grease-laden Air [Heaters and Heating Equipment] (Heaters, Cooking Appliances) Commercial Cooking Appliances with Integral Systems for Limiting the Emission of Grease- laden http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/showpage.html?&name=KNLZ.GuideI...
  • Page 7 KNLZ.GuideInfo - Commercial Cooking Appliances with Integral Systems for Limiting the Emission of... Page 4.2 http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/showpage.html?&name=KNLZ.GuideI... 8/28/2008...
  • Page 8 Page 5.1 File: E151487 Project: 08NK02927 Date: 1/23/2008 Client: Turbochef Model: Product Tested i5 Oven Pepperoni Pizza...
  • Page 9 Page 5.2 Project No. 08NK02927 File: E151487 Turbochef Model: i5 Oven Calculations needed for Nozzle Size 47.365 This number is calculated when device is calibrated % Oxygen 20.61 Oxygen inside stack during operation % Carbon %CO2 Carbon Dioxide inside stack during operation...
  • Page 10 Page 5.3 Project No. 08NK02927 File: E151487 Turbochef Model: i5 Oven Start Time: 9:05 Product Tested: Pepperoni Pizza Cook Time: End Time: 5:05 Barometric Pressure: 744.22 mmHg Recovery Time: Test Date: 01/23/08 Room Ambient: IMPINGER WEIGHT 0.65 Frit 150.92 152.03 Filter Paper Start of Test: 0.68...
  • Page 11 Page 5.4 Orafice Gas Meter Pump Traverse Sampling Pressure Velocity Stack Probe Temp Box Temp Impinger Gas Meter Reading Vaccum Point Time Differential Head ? P Temp °C °C °C Temp °C Outlet °C In.hg Number Hr/Sec 41.476 41.688 41.900 42.112 42.324 42.536...
  • Page 12 Project No. 08NK02927 File: E151487 Page 5.5 Turbochef Model: i5 Oven Start Time: 9:05 End Time: 5:05 Test Date: 01/23/08 Cook Time: 12:00 Product Tested: Pepperoni Pizza Recovery Time: 12:00 Barometric Pressure: 744.22 Post-Test Data Gas Meter Gas Meter Reading Reading initial 38.71 m...
  • Page 13 Page 6.1 UL (KNLZ) Emissions by Product 2.75 2.25 1.75 1.25 0.75 Pizza's Cooked Emissions 0.25 C3/C TurboChef Model...
  • Page 14 Re: Fire and smoke containment Dear Mr. Denny: The TurboChef ovens have been extensively tested and conform to UL 923 and UL KNLZ standards. The UL 923 standard is the electrical/product safety standard and the KNLZ is the low particulate matter emissions standard to which we conform.
  • Page 15 If you have any issues or specific questions regarding the above, please contact me directly. Best regards, James K. Pool III James K. Pool III Vice President Engineering, TurboChef Technologies, Inc., Ph: 214.379.6020 Email: james.pool@turbochef.com C:\Windows\Temp\Rar$DI00.000\Fire smoke and grease statement v2_11.doc...
  • Page 16 Page 8.1 i5 Energy Costs i5 (1-3 Phase) Changeable Parameters Operating Time Hours Energy Costs $0.11 kWHr Snooze Mode 0.00 Hours Cook Cycles/Day Cooks/Day Typical Cook Time Seconds Do Not Change the following values Power Power Time (min) Time (Hrs)
  • Page 17 Page 9.1...
  • Page 18 Page 9.2...
  • Page 19 Page 9.3...
