Echo SRM-265T Operator's Manual

Grass trimmer/brush cutter
Hide thumbs Also See for SRM-265T:
Table of Contents

Advertisement

Quick Links

Grass Trimmer/Brush Cutter
Operator's Manual
MODELS
Read rules for safe operation and instructions carefully. ECHO provides an
Operator's Manual and a Safety Manual. Both must be read and understood for
proper and safe operation. Failure to do so could result in serious injury.
X7502023801
SRM-265T
WARNING
X750009721
07/08

Advertisement

Table of Contents
loading

Related Manuals for Echo SRM-265T

Summary of Contents for Echo SRM-265T

  • Page 1 MODELS SRM-265T WARNING Read rules for safe operation and instructions carefully. ECHO provides an Operator's Manual and a Safety Manual. Both must be read and understood for proper and safe operation. Failure to do so could result in serious injury.

  • Page 2: Table Of Contents

    NTRODUCTION Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job dependability. Read and understand this manual and the SAFETY MANUAL you found in the same package. You will find both easy to use and full of helpful operating tips and SAFETY messages.

  • Page 3: Safety

    RASS RIMMER RUSH UTTER PERATOR ANUAL AFETY MANUAL SAFETY SYMBOLS AND IMPORTANT INFORMATION Throughout this manual and on the product itself, you will find safety alerts and helpful, informational messages preceded by symbols or key words. The following is an explanation of those symbols and key words and what they mean to you.
  • Page 4 Wear no-slip, heavy-duty work gloves to improve your grip on the handle. Gloves also reduce the transmission of machine vibration to your hands. Hearing Protection ECHO recommends wearing hearing protection whenever unit is used. Proper Clothing Wear snug fitting, durable clothing;...
  • Page 5 RASS RIMMER RUSH UTTER PERATOR ANUAL Repetitive Stress Injuries It is believed that overusing the muscles and tendons of the fingers, hands, arms, and shoulders may cause soreness, swelling, numbness, weakness, and extreme pain in those areas. Certain repetitive hand activities may put you at a high risk for developing a Repetitive Stress Injury (RSI).

  • Page 6: Equipment

    Use only ECHO approved attachments. Serious injury may result from the use of a non-approved attachment combination. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual and safety manual.

  • Page 7: Description

    Locate these safety decals on your unit. Make sure the decals are legible and that you understand and follow the instructions on them. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDER- ING instructions for specific information.
  • Page 8 POWER HEAD - Includes the Engine, Clutch, Fuel System, Ignition System and Recoil Starter. GRIP - Rear (right hand) handle. THROTTLE TRIGGER LOCKOUT - This lever must be held during starting. Operation of the throttle trigger is prevented unless throttle trigger lockout lever is engaged. STOP SWITCH - "SLIDE SWITCH"...

  • Page 9: Contents

    After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts.

  • Page 10: Nylon Head Installation

    NYLON LINE HEAD INSTALLATION Tools Required: Head Locking Tool. Parts Required: Nylon Line Head. CAUTION Wear Gloves or personal injury may result: • Cutoff knife is sharp. • Gearcase and surrounding area may be hot. 1. Be sure adapter plate (C) remains on PTO shaft. 2.

  • Page 11: Front Handle Installation

    RASS RIMMER RUSH UTTER PERATOR ANUAL FRONT HANDLE INSTALLATION SPACING NOTE Label shows minimum spacing for front handle location. Position front handle for comfortable operation and secure screws. PERATION WARNING Moving parts can amputate fingers or cause severe injuries. Keep hands, clothing and loose objects away from all openings.
  • Page 12 SRM/PAS/SB BLADE SET-UP GUIDE* Pro Maxi-Cut Rigid Plastic Metal Metal 80T Brush Blade TO USE Grass/Weed Tri-Cut Tri-Cut/8 Tooth Metal 22T Clearing Saw Blade THESE BLADES Plastic Cutters Grass/Weed Blade Grass/Weed Blade Loop Handle Loop Handle Loop Handle, w/or Handle w/Barrier Bar, w/Barrier Bar, U-Handle...
  • Page 13 RASS RIMMER RUSH UTTER PERATOR ANUAL Choosing the Correct Blade WARNING The type of Blade used MUST be matched to the type and size of material cut. An improper or dull blade can cause serious personal injury. Blades MUST be sharp. Dull blades increase the chance of kick out and injury to yourself and bystanders.

  • Page 14: Fuel

    Storage section of this manual. WARNING Alternative fuels, such as E-20 (20% ethanol), E-85 (85% ethanol) or any fuels not meeting ECHO requirements are NOT approved for use in ECHO 2-stroke gasoline engines. Use of alternative fuels may cause performance problems, loss of power, overheating, fuel vapor lock, and unintended machine operation, including, but not limited to, improper clutch engagement.
  • Page 15 RASS RIMMER RUSH UTTER PERATOR ANUAL Mixing Instructions Fill an approved fuel container with half of the required amount of gasoline. Add the proper amount of 2-stroke oil to gasoline. Close container and shake to mix oil with gasoline. Add remaining gasoline, close fuel container, and remix. o l l IMPORTANT Spilled fuel is a leading cause of hydrocarbon emissions.

  • Page 16: Starting Cold Engine

    STARTING COLD ENGINE WARNING The attachment will operate immediately when the engine starts and could result in loss of control and possible serious injury. Keep movable parts of the attachment off the ground and away from objects that could become entangled or thrown. Stop Switch Move stop switch button (A) forward away from the STOP position.

  • Page 17: Starting Warm Engine

    Move stop switch button (A) backward to STOP position. WARNING If engine does not stop when stop switch is moved to STOP position, close choke - COLD START position - to stall engine. Have your ECHO dealer repair stop switch before using trimmer again.

  • Page 18: Maintenance

    ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOUR- SELF or have the ECHO Dealer do it, each maintenance task has been graded. If the task is not listed, see your ECHO Dealer for repairs.

  • Page 19: Air Filter

    RASS RIMMER RUSH UTTER PERATOR ANUAL AIR FILTER Level 1. Tools required: 25 - 50 mm (1 - 2 in.) Cleaning Brush Parts required: Air & Fuel Filter REPOWER Close choke (Cold Start Position [ ]). This prevents dirt from entering the carburetor throat when the air filter is removed.

  • Page 20: Spark Plug

    SPARK PLUG Level 2. Tools required: T-Wrench, feeler gauge, soft metal brush Parts Required: REPOWER Tune-Up Kit IMPORTANT Use only NGK BPM-8Y spark plug (BPMR-8Y in Canada) other- wise severe engine damage may occur. Remove spark plug and check for fouling, worn and rounded center electrode.

  • Page 21: Exhaust System

    RASS RIMMER RUSH UTTER PERATOR ANUAL 1. Remove spark plug lead. Remove air cleaner cover. Remove muffler cover screw and muffler cover (A). Remove 2 engine cover screws and engine cover (B). IMPORTANT DO NOT use a metal scraper to remove dirt from the cylinder fins. Use brush to remove dirt from the cylinder fins.

  • Page 22: Carburetor Adjustment

    1,000 feet above mean sea level (MSL). To maintain proper engine operation above 1,000 feet MSL the carburetor must be adjusted by an authorized ECHO service dealer. IMPORTANT If the engine is adjusted for operation above 1,000 feet MSL, the carburetor must be re-adjusted when operating the engine below 1,000 feet MSL, otherwise severe engine damage can result.

  • Page 23: Lubrication

    Every unit is run at the factory and the carburetor is set in compli- ance with emission regulations. Carburetor adjustments, other than idle speed, must be performed by an authorized ECHO dealer. 1. Check idle speed and reset if necessary. If a tachometer is available, idle speed screw (A) should be set to the specifications found on page 29 "Specifications"...

  • Page 24: Nylon Line Replacement

    Flat edge of washers (D) must be against drive shaft. NYLON LINE REPLACEMENT Level 1. Parts Required: ECHO 0.095" Nylon Trimmer Line 6 m (20 ft.) long. 1. Shut engine off. Lay unit on the ground with head assembly up.
  • Page 25 RASS RIMMER RUSH UTTER PERATOR ANUAL 4. Hold the spool, opening toward you. Place index finger between the two strands and wind line, tightly and evenly, in direction of arrow (E) marked "CC". 5. Stop when approximately 15-20 cm (6-8 in.) line (C) remains and place ends of line in notches (F) in spool (B).

  • Page 26: Sharpening Metal Blades

    SHARPENING METAL BLADES Three styles of metal blades are approved for use on the ECHO Brush Cutter. The 8-tooth blade can be sharpened during normal maintenance. The clearing blade and 80 tooth blade require professional service. Before sharpening, CLOSELY inspect blade for cracks (look at the bottom of each tooth and the center mounting hole closely), missing teeth and bending.

  • Page 27: Troubleshooting

    RASS RIMMER RUSH UTTER PERATOR ANUAL ROUBLESHOOTING t l i l f f t l i t l i t l i t l i t r i t r i DANGER Fuel vapors are extremely flammable and may cause fire and/or explosion. Never test for ignition spark by ground- ing spark plug near cylinder plug hole, otherwise serious personal injury may result.

  • Page 28: Storage

    TORAGE Long Term Storage (over 30 days) WARNING During operation the muffler or catalytic muffler and surrounding cover become hot. Always keep exhaust area clear of flammable debris during transportation or when storing, otherwise serious property damage or personal injury may result.

  • Page 29: Specifications

    RUSH UTTER PERATOR ANUAL PECIFICATIONS MODEL ---------------------------------------------------- SRM-265T Length w/o cutter head ----------------------------------- 1810 mm (71.3 in.) Width -------------------------------------------------------- 245 mm (9.65 in.) Height ------------------------------------------------------- 340 mm (13.4 in.) Weight (dry) w/o Cutter Head --------------------------- 5.75 kg (12.8 lb.) Engine Type ------------------------------------------------ Air cooled, two-stroke, single cylinder gasoline engine Bore ---------------------------------------------------------- 34.0 mm (1.34 in.)
  • Page 30 NOTES...
  • Page 31 RASS RIMMER RUSH UTTER PERATOR ANUAL NOTES...

  • Page 32: Servicing Information

    • Purchasing from your Echo Dealer. • Manuals are available by sending a written request stating the model number and serial number of your Echo unit, part number of the manual, your name and address, and mail to the address below.
